Item #1004 101 694, 1004 101 690
Model #5337WWHD, 5337GYHD
USE AND CARE GUIDE
FLOOR CABINET
Questions, problems, missing parts?
Before returning to the store, call Glacier Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-GLACIER
HOMEDEPOT.COM/GLACIERBAY
PARA INSTRUCCIONES EN ESPAÑOL, COMIENCE EN LA PÁGINA 19.
THANK YOU
We appreciate the trust and confidence you have placed in Glacier Bay through the purchase of this floor cabinet.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products
available for your home improvement needs. Thank you for choosing Glacier Bay!
