TOOLS REQUIRED
Claw hammer Safety goggles
Measuring
Wall hardware
tape
Door and Drawer Swap
1
BEFORE BEGINNING ASSEMBLY
□ Read directions thoroughly
□ Decide on right or left hand door configuration (30", 36"
and 48" models). If not swapping door / drawer positions,
proceed to step 8.
□ Perform door / drawer swap prior to vanity installation
2
DOOR SWAP INSTRUCTIONS
□ If swapping door and drawer locations, follow the instructions below. If
using standard configuration, go to the Installation Instructions on page 3.
□ Remove door from cabinet frame by using a #2 Phillips screwdriver to
remove screws holding hinges in place. Save screws for reinstallation
in a later step.
3
REMOVE DRAWERS
□ Remove both drawers by fully extending the drawer, then pushing
the black plastic lever down on the right and up on the left side.
While holding the levers in place, pull the drawer out of the cabinet.
Phillips
screwdriver
Power drill
Caulk/
Keyhole saw
sealant
A
L
A I
T
E
D
. 3
L E
A
C
S
A
Model # HAWHT30D
Model # HAWHT36D
Model # HAWHT48D
Model # HAWHT60D2
Model # HASSR30D
Model # HASSR36D
Model # HASSR48D
Model # HASSR60D4
Model # HACYN30D
Model # HACYN36D
Model # HACYN48D
Model # HACYN60D4
Use and Care Guide
HARDWARE INCLUDED
Wood
shims
30"
36"
48"
60" 4 Drawers
Level
60" 2 Drawers
B
Item #
1012365957
Item #
1012365966
Item #
1012365956
Item #
1012365959
Item #
1012365960
Item #
1012365964
Item #
1012365967
Item #
1012365962
Item #
1012365965
Item #
1012365963
Item #
1012365958
Item #
1012365961
AA -
BB -
CC - Door
Knob
Handle
Screw
x 2
x 4
x 1
x 2
x 4
x 1
x 4
x 4
x 2
x 4
x 8
x 2
x 8
x 4
x 4
Reversible Door & Drawers
Please contact 1-888-774-8062 for further assistance.
Vanity
DD - Drawer
Screw
x 4
x 4
x 4
x 8
x 4
