madbeanpedals BigBottoms Manual

BigBottoms BigBottoms
F
OCTAVE
X Type:
Build Level: Intermediate
Based On: EHX® Octave Multiplexer™
The BigBottoms is based on the vintage 3-knob EHX® Octave Multiplexer™. It creates a monophonic
octave down and sounds excellent with guitar and bass. The BigBottoms adds an additional output
gain stage with level control for extra flexibility.
• LOW: Sets the amount of low end present in the octave down voice. This control is disabled when
the Sub switch is off (left).
• HI: Sets the amount of high end available to the octave down voice.
• BLEND: CCW: clean signal, 50% equal amounts of clean and octave down, CW: octave down
only.
• LEVEL: Output control.
• SUB: In the off position (left) the Sub switch deactivates the LOW control. In on position (right) the
LOW control becomes active and allows for additional tone chaping of the octave down.
Terms of Use: You are free to use purchased BigBottoms circuit boards for both DIY and small commercial operations. You may not offer BigBottoms PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
Overview
Controls
madbeanpedals forum. Please go there rather than emailing me for personal assistance. This is because (1) I'm not always
Last Updated:
November 22, 2024 6:11 PM
