madbeanpedals Bonesaw Instruction Manual

Bonesaw Bonesaw
F
FUZZ OCTAVE
X Type:
Build Level: Beginner
Based On: Univox® Super Fuzz™
The Bonesaw is a faithful adaption of the ever-popular Univox® SuperFuzz™. It produces thick
fuzz with a pronounced analog octave-up. This is a gnarly sounding circuit and fit for any guitar
player who likes chaos now and then. Like most octave-up fuzz, when doing double stop bends a
third note is produced that dive-bombs with the strings.
• EXP: Fuzz/Gain control
• BAL: Ouput volume.
• TONE: Down position is "normal". Up position is heavily scooped.
• SCOOP: This dip switch changes the frequency center of the Tone control in the up position.
• OCT: This trimmer changes the tonality of the octave up sound. See Notes.
Further Reading: http://revolutiondeux.blogspot.com/2012/02/univox-super-fuzz.html
Terms of Use: You are free to use purchased Bonesaw circuit boards for both DIY and small commercial operations. You may not offer Bonesaw PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
Overview
Controls
madbeanpedals forum. Please go there rather than emailing me for personal assistance. This is because (1) I'm not always
Last Updated:
February 14, 2025 5:49 PM
