  • Page 3 The Motion Systems, manufacturer of Qubic System, would like to thank you for choos- ing the QS-S25, an innovative product that helps you to develop highly reliable training and entertainment solutions that reproduce key immersive elements, such as surface textures, acceleration, engine vibrations and vehicle dynamics for multiple types of land, air or sea vehicles.
  • Page 4 QS-S25 SUPPORT Our experts are ready to assist you: MotionSystems.eu/Support SEARCH OUR TUTORIALS Everything you wish to know is here: QubicSystem.com/Tutorials SUPPORTED GAMES Racing games and professional simulation software: QubicSystem.com/Supported-Games DISCORD YOU ASK, WE ANSWER Join our discord server to ask questions: Discord.com/invite/tuAtybvTRn...

  • Page 5: Table Of Contents

    Contents 1 Safety precautions ........Health and Safety Instruction .
  • Page 6 QS-S25 Increasing safety level ....... 7.3.1 Assembling Motion Lock jumper ..... 7.3.2 Adding power-cut circuit with E-STOP button .

  • Page 7: Safety Precautions

    SAFETY PRECAUTIONS INFO Read all safety instructions before installing and using this product. Save this document for future reference. If ownership of this product is transferred, be sure to include this manual. WARNING The device is intended solely for individuals OVER THE AGE OF 16.
  • Page 8 QS-S25 WARNING DO NOT touch the actuators when the power is on. Use the QS-S25 only for its intended purpose, according to instructions. ■ Unplug the QS-S25 from the power supply if it is not used for an extended period ■...

  • Page 9: Health And Safety Instruction

    1.1. HEALTH AND SAFETY INSTRUCTION The safety of Qubic System users is top priority. To protect users and bystanders from injuries caused by mechanical parts movement and electric shock, the following in- structions MUST BE followed. WARNING As with any mechanical device, user is the one responsible for inspecting the condition of the machine before using it and ensuring safe working conditions.
  • Page 10 QS-S25 How to safely turn on and use the QS-S25: Ensure that everyone around is aware of cockpit’s rapid movements. ■ Ensure that no one stands in the range of the motion (minimum of 1.5 m [5 feet]). ■ WARNING In order to perform a start-up calibration QS-S25 will move automatically after turning it on.
  • Page 11 WARNING Motion Lock input is not SIL/PL (safety integrity level/performance level) rated DOES NOT guarantee safety. If you wish to achieve specific SIL/PL rank- ing, consider introducing a power cut-off device that is controlled by an external safety relay and cuts off the power to all Power Cabinets. Example application of the power cut-off contactor can be found in section 7.3.2 and 7.3.3 on pages 86 and 88.

  • Page 12: Product Description

    QS-S25 PRODUCT DESCRIPTION 2.1. COMPLETE VIEW QS-S25 basic setup overview: Actuators numbering and connections with power cabinets:...
  • Page 13 QS-S25 basic with all additional accessories overview: INFO Use only monitors compatible with VESA 100 x 100 32” type mounting.

  • Page 14: Dimensions

    QS-S25 2.2. DIMENSIONS QS-S25 basic setup dimensions: INFO QS-S25’s maximum heave is 108.3 mm (4.26 in) - ensure that the room in which the motion platform will operate has a high enough ceiling (including accessories + monitors).
  • Page 15 QS-S25 dimensions with accessories:...

  • Page 16: Components (Assembled Variant)

    QS-S25 2.3. COMPONENTS (ASSEMBLED VARIANT) QS-S25 (assembled) components: INFO For information on components in modularized variant go to section 3 on page...

  • Page 17: Labels And Warning Plates Placement

    2.4. LABELS AND WARNING PLATES PLACEMENT...

  • Page 18: Safe Distances

    QS-S25 2.5. SAFE DISTANCES Minimum safe distances from the QS-S25 edges are shown below: INFO Keep in mind that QS-S25 might move during simulation, occasionally check if the safe distances are kept to avoid damages by QS-S25 hitting for example wall or TV screen.

  • Page 19: Power Requirements

    2.7. POWER REQUIREMENTS Power Cabinet (QS-SB2) contains the power supply for connected actuators. If there is no certainty if fuses or entire electrical installation can handle QS-S25, contact qualified electrician. WARNING Always UNWIND THE CABLE COMPLETELY when using a cable reel and untangle an extension cord before connecting the device to the power supply.

  • Page 20: Grounding Requirements

    QS-S25 Voltage - 110V: Breaker Converter specification Power consumption specification Average Power Average Power Average Power Peak Power Peak Current (stress test) (typical game) [kVA] [kVA] [kW] [kW] 0.45 0.24 Be aware that with heavier payload, and/or more intensive simulation, average Power consumption may rise.
  • Page 21 WARNING The power supply for QS-S25 includes an electric cord with an equipment- grounding conductor and a grounding plug. The plug must be plugged into a matching socket that is correctly installed and grounded in accordance with ap- propriate local codes and ordinances. It is recommended to use multiple, sepa- rately fused wall sockets.

  • Page 22: Noise Emission

    QS-S25 2.10. NOISE EMISSION The QS-S25 was checked for noise level based on actual standards. Noise level during normal work condition is not over 80 dB. Measuring method is compliant with ISO 11202. Four measuring positions as shown on the picture are placed 160 cm from the floor level and 100 cm from the edge of the device.

  • Page 23: Qs-S25 Modularized Assembly

    QS-S25 MODULARIZED ASSEMBLY...
  • Page 24 QS-S25...

  • Page 26: Lower Frame Assembly

    QS-S25 3.1. LOWER FRAME ASSEMBLY Operation Tools Unpack the segments and connectors. Front side connector has ad- by hand ditional holes for mounting power switch box.
  • Page 27 Operation Tools Turn the connectors and segments upside down, connect the seg- 6 mm hex key, ments with connectors using bolts, nuts and washers as shown on 13 mm socket the illustration. wrench...
  • Page 28 QS-S25 Operation Tools Lay down the braided wires (grounding connections), M-BUS cables, by hand power supply cables as shown on the illustration. Cables will be connected to the power cabinets later on. Braided wires shall be connected to the switch box, power cabinets and cockpit frame.

  • Page 29: Mounting Actuators And Power Cabinets

    3.2. MOUNTING ACTUATORS AND POWER CABINETS Operation Tools Place the power cabinets and actuators according to the layout by hand shown below. Place the actuators as shown on the layout. Power supply and control cables from power cabinet to the actuator should cross each other.
  • Page 30 QS-S25 Operation Tools Configure the CFG switches according to the actuators layout. by hand...
  • Page 31 Operation Tools Bolt in the power cabinets with segments. Power cabinets has at- 5mm hex key, tached mounting brackets with vibro-isolators, place them on the 10mm socket segment and screw in using bolts and nuts for the connection. wrench Operation Tools Unbolt the marked bolt, connect and screw in the short braided wire 5mm hex key...
  • Page 32 QS-S25 Operation Tools Connect the actuators with the base frame segments. 6mm hex key, 13mm socket wrench...

  • Page 33: Mounting Cockpit Frame

    3.3. MOUNTING COCKPIT FRAME Operation Tools Connect the actuators with the cockpit frame. 5mm hex key, 10mm socket wrench...
  • Page 34 QS-S25 Operation Tools Optional - connect the wheels to the lower frame segments in order 19mm socket to move the device to the designated location. WARNING Do not use the device with attached transportation wheels. Wheels shall be at- tached only for transportation purposes.

  • Page 35: Mounting Lower Frame Accessories

    3.4. MOUNTING LOWER FRAME ACCESSORIES Operation Tools Connect the switch box, stairs and steel plate with lower frame con- 5mm hex key, nectors. 10mm socket wrench...
  • Page 36 QS-S25...

  • Page 37: Mounting Cockpit Accessories

    3.5. MOUNTING COCKPIT ACCESSORIES INFO Before mounting cockpit accessories power-up the device and check if the pitch and roll movements are correct. Run QubicManager → Tools and Diagnostic → Platform Diagnostic and check correctness of the movements. If any of the move- ment is incorrect then the actuators were installed in the wrong place.

  • Page 38: Seat Mover

    QS-S25 3.5.1 SEAT MOVER Operation Tools Connect the seat mover with cockpit. Slide in slot nuts into the seat 5mm hex key mover railings and screw it in from below of the frame.

  • Page 39: Keyboard Holder

    3.5.2 KEYBOARD HOLDER Operation Tools Connect the keyboard holder with the cockpit frame. 6mm hex key, 13mm socket wrench...

  • Page 40: Shifter/Handbrake Plate

    QS-S25 3.5.3 SHIFTER/HANDBRAKE PLATE Operation Tools Connect the shifter/handbrake plate with the cockpit frame. 6mm hex key, 13mm socket wrench...

  • Page 41: Vr Goggles Hanger

    3.5.4 VR GOGGLES HANGER Operation Tools Connect the VR goggles hanger with the cockpit frame. 5mm hex key...

  • Page 42: Steering Wheel Desk

    QS-S25 3.5.5 STEERING WHEEL DESK Operation Tools Assemble the steering wheel desk as shown on the illustrations. Do 4, 5, 6mm hex not mount the additional bracket if you wish to install the monitor holders.
  • Page 44 QS-S25...
  • Page 46 QS-S25...
  • Page 47 Operation Tools Connect right side bracket the same way as the left one. 4, 5, 6mm hex...
  • Page 48 QS-S25 Operation Tools Put in the plastic endings on the brackets. Connect the steering 5mm hex key wheel desk to the side brackets.

  • Page 49: Steering Wheel Bracket

    3.5.6 STEERING WHEEL BRACKET Operation Tools Optional Install the direct drive mounting bracket. 6mm hex...
  • Page 50 QS-S25...

  • Page 51: Pedals Bracket

    3.5.7 PEDALS BRACKET Operation Tools Put in the pedals mounting bracket as shown on illustration. Re- 4mm hex key move 6 bolts from the spacers.
  • Page 52 QS-S25 Operation Tools Attach the pedals set to the frame. 5mm hex...
  • Page 53 Operation Tools Put in the removed bolts through the holes in the cockpit frame and 4mm hex key use them to connect the pedals bracket with cockpit frame.

  • Page 54: Monitors Holders

    QS-S25 3.5.8 MONITORS HOLDERS Operation Tools Connect the monitors holder front bracket. 5mm hex key...
  • Page 55 Operation Tools Connect the monitors holder side bracket. 6mm hex key, 13mm socket wrench...
  • Page 56 QS-S25 Operation Tools Connect the monitors holder front bracket - pull rod. 6mm hex key, 13mm socket wrench...
  • Page 57 Operation Tools Connect the monitors holders top frame. 5mm hex key...
  • Page 58 QS-S25 Operation Tools Connect the monitors mounting brackets to the top frame 2.5, 3, 5mm hex...
  • Page 60 QS-S25 Operation Tools Connect the monitors frame to the mounting bracket 3mm hex key, & 10mm socket wrench...
  • Page 61 Operation Tools Connect the mounting brackets with the upper frame of the holders. 5mm hex key...

  • Page 62: Speaker Holders

    QS-S25 3.5.9 SPEAKER HOLDERS Operation Tools Connect the speakers mounting brackets and mount the speakers 3mm hex key, inside the cockpit frame. socket wrench INFO Dedicated set of speakers for the QS-S25 is Logitech Z906...

  • Page 63: Installation

    INSTALLATION WARNING Dangerous voltages level can be present in Power Cabinet and cables during the operation and for a few minutes after turning off the machine. Remember, even though possibilities with QS-S25 are broad, some things should be kept in mind when the place for the rig is chosen. Motion Systems DOES NOT approve exceeding or ignoring any of these points and...

  • Page 64: Attaching Wheel Modules

    QS-S25 4.1.1 ATTACHING WHEEL MODULES To roll the platform into designated place install wheel modules (x3) using included bolts and washers. Screw them in gradually to evenly lift the platform. WARNING After rolling the platform into designated place wheel modules MUST then be uninstalled.

  • Page 65: Lifting The Platform

    4.1.2 LIFTING THE PLATFORM WARNING To avoid damaging platform’s components with lifting straps - side monitor screens and right desk should be removed. The platform can be moved by lifting it from the ground. ONLY use lifting points shown below: WARNING Only a professional forklift operator can operate the forklift/hoist.

  • Page 66: Anchoring

    QS-S25 4.2. ANCHORING Depending on the floor surface, the platform may crawl in all directions during normal operation. It is recommended to anchor it to the ground. Anchor holes pattern dimensions: INFO It is suggested to use M12 wedge anchor bolts. Remove three triangular bottom plates from the platform using 5 mm hex key (4 bolts per plate).
  • Page 67 Install anchoring plates underneath the platform using bolts, nuts and washers included in the package, as shown in the illustration: Once the platform is in its designated place - install anchor bolts referring strictly to manufacturer’s anchor bolt manual. Reattach triangular plates back to the platform using 5mm hex key.

  • Page 68: Cfg Switch Configuration

    QS-S25 4.3. CFG SWITCH CONFIGURATION INFO All QS-SB2 Power Cabinets must be interconnected via Motion Lock interlink ■ cables. Order of connecting the cables is not important. Keep the CFG switches ■ setting according to the actuators numbering.

  • Page 69: Interconnections

    4.4. INTERCONNECTIONS...

  • Page 70: Motion Lock Connection With Other Qs Devices

    QS-S25 4.5. MOTION LOCK CONNECTION WITH OTHER QS DEVICES If you own more QubicSystem devices, we recommend including them in the Motion Lock circuit in order to create one e-stop button setup. Refer to diagrams below. WARNING All Motion Lock connections must be performed with power switched OFF. ■...

  • Page 71: Connecting Power Cords

    QS-S25, steering wheel (QS-DD-20) and a belt tensioner (QS-BT1): 4.6. CONNECTING POWER CORDS...

  • Page 72: Connecting Grounding Wires

    QS-S25 4.7. CONNECTING GROUNDING WIRES INFO Platform is equipped with a low resistance protective-earth bolt. It must be con- nected to the facility’s solid protective earth/grounding bolt in order to increase suppression level. It is recommended to use at least 10 mm copper wire.

  • Page 73: Connecting Building Earthing Wire

    4.7.1 CONNECTING BUILDING EARTHING WIRE...

  • Page 74: Software Installation

    QS-S25 4.8. SOFTWARE INSTALLATION INFO Note down the QS-S25 serial number before installation as it is needed to access software download page. The SERIAL NUMBER can be found on the M10 identification label in the XXXXXX-XXXXXX- XXXXX-XXXXXX format. This serial number is also used for activation of FSMI (Force- SeatMI) and MT (Motion Theater) licenses - check information on page 76.
  • Page 75 If Qubic Manager has recognized the QS-S25 correctly, the status of the machine visible in the lower left corner will change to Parked/Centered. Check Action Center on the right side panel for a list of actions that requires at- tention:...
  • Page 76 QS-S25 It is possible to solve them one by one or by pressing the Resolve All button. Firmware update may require additional confirmation in the dialogue box. Go to Tools and Diagnostics →Devices and select Configure. Choose one of the operation modes: INFO Q-MODE is unavailable for QS-S25...
  • Page 77 Close the configuration and return to the main application window. Choose the game and check profile details by clicking on the game tile. Adjust the motion effects intensity to your preferences in the game profile window, scroll down in the window to see all of the settings. You can adjust the settings during the game simulation by pressing ALT+TAB.
  • Page 78 QS-S25 Activate profile by clicking the Activate button. Launch the game by clicking the Run the game button.
  • Page 79 INFO If you need the serial number to activate other software licenses such as ForceSeatMI or ForceSeatDI, it can be found in the Qubic Manager. After connecting the QS-S25 go to Tools and Diagnostics →Devices: Serial number is visible under the device name: WARNING The software is provided ”as is”, without warranty of any kind, express or implied, including but not limited to the warranties of merchantability, fit-...

  • Page 80: Maintenance

    QS-S25 MAINTENANCE Cleaning To minimize the risk of abnormal heating that can result in system failure, keep the QS- S25 uncovered, clean and dust-free. Cleaning the unit should be performed with a soft, dry cloth. DO NOT use solvents or cleaners that may corrode or damage materials of parts used in the QS-S25 in any way.

  • Page 81: Troubleshooting

    TROUBLESHOOTING WARNING DO NOT attempt to do any repairs by yourself. It could be dangerous and will result in loss of warranty! Repairs should be consulted with technical support and then performed by a qualified technician. Before contacting technical support, try this: Check Action Center in QubicManager.

  • Page 82: Creating A Snapshot

    QS-S25 6.1. CREATING A SNAPSHOT A snapshot is the easiest and fastest way to diagnose a problem. If you send in the zip file generated in the snapshot menu along with a description of the problem, technical support receives the necessary information about the product and its configuration. It can be then analyzed to provide the best solution.
  • Page 83 Select data that will be included in the snapshot. Scroll down, consent to the technical support terms and conditions and select Create & Show: The snapshot has been created, click the OK button - the folder with the snapshot ZIP file will open. Attach the snapshot ZIP file to your support request.

  • Page 84: Discord Channel

    We strongly recommend joining our discord channel, where our growing community is sharing amazing tips and ideas of how to set up, use and tune the Qubic System products. You can also send questions for technical support or get answers directly from the community.

  • Page 85: Advanced Applications

    ADVANCED APPLICATIONS INFO Examples shown in this section describe optional application of external safety and power cut-off devices. If you wish to expand the functionality of your motion system, read the whole section to have a good understanding of how to apply and what functionality to expect.
  • Page 86 QS-S25 Example application of single-channel safety relay that controls ML and additional devices: Example wiring diagram of application of one-channel safety relay with E-STOP button:...

  • Page 87: Implementing The Working Zone Protection

    7.2. IMPLEMENTING THE WORKING ZONE PROTECTION To protect bystanders from accidental hit from moving parts of the platform, safety gate with opening sensor* can be connected to safety relay input for activating ML function. When the gate opens, the safety relay output activates the ML (Motion Lock) function and stops the motion of the platform.

  • Page 88: Increasing Safety Level

    QS-S25 7.3. INCREASING SAFETY LEVEL WARNING Modifications of the safety system, involving application of the power line con- tactors, shall be performed only by somebody competent. A competent person is a qualified and knowledgeable person, who because of their training and experi- ence has the knowledge required to apply those changes.

  • Page 89: Adding Power-Cut Circuit With E-Stop Button

    7.3.2 ADDING POWER-CUT CIRCUIT WITH E-STOP BUTTON If specific SIL/PL rated level needs to be achieved, it might be necessary to install a power cut-off device. Two contactors connected in series and controlled by safety relay can be used to provide or cut-off power line to QS-SB2 power cabinets. When safety function on safety relay input is triggered, a safety relay will switch off the contactors, thus cutting-off the power to the platform.
  • Page 90 QS-S25 Example wiring diagram of application of power line contactors and one-channel safety relay with E-STOP: INFO PE (protective grounding/earthing) connection is omitted for better transparency...

  • Page 91: Implementing The Working Zone Protection With Power-Cut Circuit

    7.3.3 IMPLEMENTING THE WORKING ZONE PROTECTION WITH POWER-CUT CIRCUIT In example application contactors connected in series provide power line to the QS-SB2 power cabinets. When safety function on safety relay input is triggered, a safety relay will switch off the power contactors, thus cutting-off the power to the platform. Example application of power line contactors with safety gate opening sensor: *Check your safety relay manual for list of applicable opening sensors INFO...

  • Page 92: Implementing Non-Factory Motion Lock Switch

    QS-S25 7.4. IMPLEMENTING NON-FACTORY MOTION LOCK SWITCH If you want to assemble custom Motion Lock switch or a button box setup (only Double Pole Single Throw switch compatible) using QubicSystem Motion Lock interlink cable, follow the diagrams below: For non-factory Motion Lock plug setup, you must assemble plug and connectors as shown below:...

  • Page 93: Environmental Impact And Disposal

    ENVIRONMENTAL IMPACT AND DISPOSAL DO NOT dispose of this product with standard house- hold waste but drop it off at a collection point for the disposal of Waste Electrical and Electronic Equip- ment for recycling. QS-S25 is shipped with wooden cases/cardboard boxes. If the packaging is no longer needed, it can be fully recycled.

  • Page 94: Warranty

    QS-S25 WARRANTY Motion Systems warrants to the consumer that this product shall be free from defects in materials and workmanship, for a warranty period which corresponds to the time limit to bring an action for concerning this product. For commercial customers, there is a one (1) year limited warranty, starting on the orig- inal date of purchase.

  • Page 95: Copyright

    COPYRIGHT Qubic System is a trademark of Motion Systems. All rights reserved. All the contents in this user manual are the intellectual property of Motion Systems. No part of this manual, including the products and software described in it, shall be modified or translated into any language without the prior written permission of Motion Systems.
