  • Page 1 VERSO STANDARD USER MANUAL...

  • Page 3: Table Of Contents

    5.2.2. Outdoor compensated ventilation (OCV) ..................................26 5.2.3. Minimum temperature control (MTC)....................................26 5.2.4. Summer night cooling (SNC) ........................................26 5.2.5. Override function (OVR) ..........................................26 UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 4 7.6. Water heater/cooler ..............................................35 7.7. Direct evaporation cooler/heater (DX) ......................................... 35 7.8. Electrical heater ................................................35 8. TROUBLESHOOTING ................................................36 ANNEX 1. Filter inspection and replacement ........................................39 UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 5: Introduction

    An air handling unit is a device designed to ensure good ventilation in the premises. An air handling unit removes indoor air containing carbon dioxide, various allergens or dust and replaces it with filtered fresh outdoor air. VERSO Standard air handling units are intended for ventilation of medium-sized spaces (eg.

  • Page 6: Air Handling Unit Functions

    Room air temperature is measured by an integrated exhaust air temperature sensor. For information on how to select a temperature control method see Chapter “Control and Settings”. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 7: Air Quality Control (Aqc)

    Sensor type is selected during ordering. Later, the sensor type may be changed in the control panel menu “Settings”. For information on how to activate this function and set a critical air quality value see Chapter “Control and Settings”. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 8: Summer Night Cooling Function (Snc)

    25 °C. Water flow sensor may also be used as an additional frost protection (see Chapter “Water Flow Monitoring Function”). UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 9: Optional Functions

    For information on how to activate this function and set a desired temperature value see Chapter “Control and Settings”. Only in CF units. Sold separately. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 10: Multi-Level Frost Prevention

    This feature is pre-ordered and configured at the factory. Later, settings of this function may only be changed by a service representative. Only for VERSO CF 2300 U/H/V, VERSO CF 3500 U/H/V and VERSO CF 5000V units. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 11: Water Flow Monitoring Function

    C5.1 panel has a colour touchscreen. If the unit is connected to the mains, the control panel will display the home screen or screen saver that you can switch off with a single tap. 16:30 21,9 °C 21,3 °C Temperature ECONOMY 1 Sold separately. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 12 Holiday operation mode Fan operation „Override“ mode Air flow increasing by activated function Alarm signal (see chapter Functions) Air flow decreasing by activated function (see chapter Functions) UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 13: Parameter Overview

    During the first minute of starting the unit, the unit automation checks the settings, automation components and opens air dampers. Later, a signal is released to fans and a heat exchanger, and the unit starts operating at a selected ventilation mode. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 14: Calibration Of The Cf Heat Exchanger During Commissioning

    SPECIAL Supply flow 680 m3/h Setpoint 21 °C Heating Cooling Humidifying Reset settings Only in CF units. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 15: Scheduling Window And Ventilation Schedule Settings

    COMFORT 1 COMFORT 2 Standby mode is optional. The device will only operate at a set time. The unit will automatically stop during unspecified periods. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 16: Overview Window

    Reset air heater 873 h 873 h operation counter? Exhaust fan Exhaust fan 875 h 875 h Recovered energy Recovered energy 1440 kWh 1440 kWh UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 17: Functions

    Grey box: function is activated but not working. In the settings of each function you can activate the function and alter operating conditions. Only in CF units. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 18 Setting two indoor temperatures for the function to start running and stop. Summer night cooling Enable Start when indoor 25 °C Stop when indoor 20 °C Reset settings UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 19 In this window you can set a desired supply air temperature for an individual ventilation zone. 1st additional zone c... Enable Setpoint 22.0 °C Reset settings This function only runs when optional additional zone modules are connected. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 20: Settings

    Extract Room Balance • Flow control The user can select a desired air flow control method (see Chapter “Air Flow Control”). Flow control VAV Double UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 21 The measured temperature may be adjusted within ± 5 ° C and the humidity within ± 10% range. Panel sensor calibration Temperature correction Humidity correction Temperature correction 5,0 °C 10,0%RH °C Humidity correction 0,0%RH 0,0°C -5,0 °C -10,0%RH UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 22: Customization

    Enable Brightness Panel temperature Row 1 Panel humidity Time Row 2 100% Supply temperature Panel temperature Row 3 Extract temperature Panel humidity 1 / 2 UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 23 (see Chapter “Control and settings. Computer”). Panel lock • Touch sounds You can turn on/off touch sounds. Two types of touch sounds are available. Touch sound Click Beep UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 24: Control And Settings. Computer

    If You forgot a changed password, it can be reset to the initial “user” from the control panel (Settings→Air handling unit→Reset settings). Displayed unit diagram depends on the unit type and ordered components. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 25: Flow Control Modes

    If the unit operates in a different ventilation mode than the one set, air quality control function will be disabled automatically. AIR QUALITY CONTROL (AQC) Enable Setpoint 1 Mode 1 Economy1 Setpoint 2 1200 Mode 2 Comfort1 UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 26: Outdoor Compensated Ventilation (Ocv)

    5.2.6. Operation on demand (OOD) Setting a critical air quality sensor value. The unit starts as soon as this value is exceeded. OPERATION ON DEMAND (OOD) Enable Setpoint UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 27: Humidity Control (Hum)

    AHU will be stopped. WATER HEATER/COOLER Water heater Water cooler Displayed only when this function is pre-ordered. This function only works when optional additional zone modules are connected. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 28: Alarms/Status

    2227 kWh Reset 5.3.4. Efficiency status EFFICIENCY STATUS Heat exchanger thermal efficiency Heat exchanger recovery 8.6 W Thermal energy saving 100 % CF exchanger calibration Calibrated UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 29: Vav Status

    For detailed performance analysis, you may download a device logbook (Log) which contains weekly operation data. To open a logbook you will need a “Log plotter” app that you can download on the “Komfovent” website. This data can be useful in the event of a failure and may facilitate repair procedures, therefore, we recommend downloading an operation logbook and handing it over to the authorised service personnel.

  • Page 30: Holidays

    If one computer is used to control several air handling units, we recommend nam- ing every unit differently. This will facilitate distinguishing the units. USER INTERFACE Language English Flow units m³/h AHU name Komfovent UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 31: Log-In Password

    6. CONTROL VIA A SMARTPHONE “Komfovent C5” app is necessary for controlling your air handling unit via your mobile phone. The unit can be controlled in a local network via mobile phone. Controlling the air handling unit with your mobile device is almost the same as with a C5.1 control panel. Screens and settings are so similar that you can follow the chapter “C5.1 Control Panel”...

  • Page 32: Periodic Maintenance

    Locations of all the mentioned device components and notes indicated in the “Installation Manual”. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 33 The inside of the air handling unit can be cleaned with a vacuum cleaner and/or a damp cloth. When cleaning, prevent water from enter- ing electrical components of the unit. Make sure all surfaces are completely dry before starting the unit. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 34: Housing

    (see Fig. 2). As soon as the differential pressure reaches the set limit, filter contamination message is displayed. Once the filters are replaced, clear the contaminated filter message on a control panel or computer. In units with pocket filters. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 35: Fans

    Tubes must be cleaned with a damp cloth or compressed air. Wait for the tubes to dry completely before turning on the device. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 36: Troubleshooting

    Check whether the sensor is connected. If a sensor needs to 3A, 4A Extract air temp. sensor failure sensor. be replaced, contact an authorized service representative. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 37 Check whether the sensor is connected. If a sensor needs to 41A,42A Supply air temp. sensor failure inside the unit, measuring supply air temperature be replaced, contact an authorized service representative. downstream the heat exchanger. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 38 1. Check connection of external devices or contact the 126A Controller failure devices. representative of the installer. 2. Faulty C5 controller. 2. Contact authorised service. UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...

  • Page 39: Annex 1. Filter Inspection And Replacement

    Layout of filters and compo- nents presented in the “Installation Manual”. VERSO R 1000 U/H/V - 1300 U/H/V - 1500 U/H/V VERSO R 1000 F UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 40 VERSO R 1000 FSA VERSO R 1300 F VERSO R 1500 F UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 41 VERSO R 1700 U/H/V - 2000 U/H/V VERSO R 2000 F VERSO R 2500 V UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 42 VERSO R 2500 H - 5000 H VERSO R 3000 U/H/V - 4000 U/H/V VERSO R 3000 F UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 43 VERSO R 5000 V VERSO R 7000 H UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 44 VERSO R 7000 V VERSO CF 1000 U/H/V - 1300 U/H/V - 1700 U/H/V VERSO CF 1000 F - 1300 F - 1500 F UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 45 VERSO CF 2000 F VERSO CF 2300 U/H/V VERSO CF 2500 F UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
  • Page 46 VERSO CF 3500 U/H/V VERSO CF 5000 V VERSO CF 5000 H UAB KOMFOVENT we reserve the right to make changes without prior notice Verso Standard_user manual_25-01...
