Summary of Contents for Deco Gear DGVIEW330B
- Page 1 29.5”CURVED 2560x1080 200Hz Gaming Monitor MODEL: DGVIEW330B...
- Page 3 ● Keep the monitor away from water sources or damp places, such as bath rooms, kitchens, basements and swimming pools. ● Make sure the monitor is placed on a at surface. lf the monitor falls down, it may cause human injury or device damage.
-
Page 4: Product Introduction
Product introduction Packing list ● Please check that the package of the monitor contains all parts. If any part is lost, please contact the distributor. ● The color and shape of parts may vary with models. Figures in this User Manual are for reference only. -
Page 5: Installation Of Base
Installation Installation of base 1. Open the carton package, take out the upper and lower foam covers and put them at onthe table top. Upper foam covers Lower foam covers 2. Remove the upper styrofoam and the inner bag protection bag, and place the lower styrofoam on the desktop, and the machine should not leave the lower styrofoam. - Page 6 4. Tighten the bracket and base together with a screw lock as shown in the gure below. Screws x 1 （Fixed base） Stand Base 5. Snap the installed base assembly back into place. base assembly 6. Simply hold the stand with hand to stand the monitor upright. Note: During standing of the whole monitor, do not press the liquid crystal screen with hand to avoid damage to the screen.
- Page 7 Installation of mount 1. Open the carton package, take out the upper and lower foam covers and put them at onthe table top. Upper foam covers Lower foam covers 2. Remove the upper styrofoam and the inner bag protection bag, and place the lower styrofoam on the desktop, and the machine should not leave the lower styrofoam.
- Page 8 4. During padlocking of the monitor, do not pinch the screen with the hands to avoid damaging the screen. Install the mount to the mount stud by referring to the user manual of the mount (purchased separately). Tips: The mounting hole distance of the mount for the product is 75x75mm. Mount (not supplied) Notes: To prevent the monitor on the mount from failing, please install it firmly and protect it fully.
-
Page 9: Adjusting The Monitor
Adjusting the monitor -5.0° +20° Tilting angle -5.0°(±2.0°)- +20°(±2.0°) -
Page 10: Description Of Buttons
Usage Description of buttons Button Function Power button: Press to turn on/o the monitor. Exit/hot key: Press to return to the previous menu/quickly switch the color format. Down button: Press to move down in the menu/quickly enter the LED light e ect. Menu button: Press to enter sub-menus/ quickly enter the main menu. -
Page 11: Cable Connection
Cable connection *The bottom interface con guration at the back of the monitor varies with products. *Note: lf the power cable or signal cable is damaged, you must replace it with special soft cables or special components purchased from the manufacture or maintenance department. HDMI interface Use the HDMl cable to connect the HDMI Use the HDMI-DVl cable (not included) to... -
Page 12: Menu Description
OSD menu Menu description ● The color and shape of the OSD menu of the actual computer may be slightly different from them shown in the figure. ● Specifications of the OSD menu may change with improvements of functions without prior notice. - Page 13 HDMI1(2.0) HDMI2(1.4) HDMI3(1.4) MPRT DP/HDMI1/HDMI2/HDMI3 DP/HDMI1/HDMI2/HDMI3...
-
Page 14: Specification
Specification Product Name Liquid Crystal Display Product model DGVIEW330B Screen Size 29.5” (75cm) Aspect Ratio 21:9 Viewing Angle 178°(H) / 178°(V) Pixel pitch 0.2697 (H) x 0.2697 (V) mm Contrast ratio 3000:1（TYP） Colors 16.7M Resolution 2560 x 1080 Maximum refresh rate... - Page 15 Supported resolution and refrech rate 1280x1080@60Hz 1280x1080@60Hz 2560x1080@60Hz 2560x1080@60Hz 2560x1080@120Hz 2560x1080@120Hz 2560x1080@144Hz 2560x1080@180Hz 2560x1080@200Hz 1152x864@75Hz-VESASTD 1440x1080@60Hz-VESASTD...
- Page 16 HDMI2[1.4] HDMI3[1.4] 2560x1080@60Hz 2560x1080@60Hz 2560x1080@75Hz 2560x1080@75Hz 1440x1080@60Hz-VESASTD 1440x1080@60Hz-VESASTD...
- Page 20 108.007.xxxxx DGVIEW330B 30A3M DECO GEAR 说明书 2022-06-01 1 4 0 x210mm 120G铜版纸，封面封底过光膜，彩色印刷，骑马钉 唐喜阳 备注:如不够页数，可以在封面封底的内面插入空白页.
