Specifications
General Specifications
Standard IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE802.1p
Protocol CSMA/CD
16/24 10/100/1000 Mbps RJ45 Ports
Interface
Auto-Negotiation/Auto MDI/MDIX
10Base-T:
2-pair UTP/STP of Cat. 3 or above (maximum 100 m)
100Base-TX:
Network Media (Cable)
2-pair UTP/STP of Cat. 5 or above (maximum 100 m)
1000Base-T:
4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
LS1016G: 32 Gbps
Switching Capacity
LS1024G: 48 Gbps
Transfer Method
Store-and-Forward
MAC Address Learning Automatically learning, automatically aging
10Base-T: 14881 pps/Port
Frame Forwarding Rate
100Base-X: 148810 pps/Port
1000Base-T: 1488095 pps/Port
Safety Precautions
To avoid any device damage and bodily injury caused by improper use, you should observe the following rules.
Keep the power off during the installation.
Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good skin contact and is well
grounded.
Use only the power cord provided with the switch.
Make sure that the supply voltage matches the specifications indicated on the rear panel of the switch.
Ensure that the switch is installed in a well-ventilated environment and its ventilation hole is not blocked.
Do not open or remove the cover of the switch.
Before cleaning the device, cut off the power supply. Do not clean it by the waterish cloth, and never use any
other liquid cleaning method.
Place the device with its bottom surface downward.
Lightning Protection
Extremely high voltage currents can be produced instantly when lightning occurs and the air in the electric
discharge path can be instantly heated up to 20,000 °C. As this instant current is strong enough to damage
electronic devices, more effective lightning protection measures should be taken. Ensure that the rack and
the device are well earthed.
Make sure the power socket has a good contact with the ground.
Keep a reasonable cabling system and avoid induced lightning.
Use the signal SPD (Surge Protective Device) when wiring outdoor.
Note:
For detailed lightning protection measures, refer to the Lightning Protection Guide:
https://www.tp-link.com/us/configuration-guides/lightning_protection_guide
Installation Site
When installing the device on a rack or a flat workbench, attach much importance to the following
items:
The rack or workbench is flat, stable, and sturdy enough to support the weight of 5.5 kg at least.
The rack or workbench has a good ventilation system. The equipment room is well ventilated.
The rack is well grounded. Keep the device less than 1.5 meters away from the power socket.
Environmental and Physical Specifications
Certification FCC, CE, RoHS
Operating Temperature 0˚C to 50˚C (32˚F to 122˚F) (For LS1016G)
0˚C to 45˚C (32˚F to 113˚F) (For LS1024G)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Operating Humidity 10% to 90%RH non-condensing
Storage Humidity 5% to 90%RH non-condensing
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce.
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of
the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
Frequently Asked Questions (FAQ)
Q1. The Power LED is not lit.
The Power LED should be lit when the power system is working normally. If the Power LED is not lit, check as
follows:
A1: Make sure the power adapter is connected to the switch with power source properly.
A2: Make sure the voltage of the power supply meets the requirements of the input voltage of the switch.
A3: Make sure the power source is ON.
Q2. The Link/Act LED is not lit when a device is connected to the
corresponding port.
It is recommended that you check the following items:
A1: Make sure that the cable connectors are firmly plugged into the switch and the device.
A2: Make sure the connected device is turned on and works normally.
A3: The cable must be less than 100 meters long (328 feet).
Q3. Why does the switch fail to detect and block a loop from occurring in
the network topology when Loop Prevention is enabled?
A: When this switch is connected to other non-terminal devices, such as switches of other brands, and the
device is incapable of correctly processing or forwarding loop detection packets, the Loop Prevention
function will be limited. It is recommended to connect the terminal devices directly to this switch or
connect non-terminal devices with complete forwarding capability to this switch.
Site Requirements
Temperature/Humidity
Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little
humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion.
High temperatures may accelerate aging of the insulation materials, significantly shortening the service life
of the device. To find out the best temperature and humidity conditions for the device, check the following
table.
Environment Temperature Humidity
Operating 0 °C to 50 °C (For LS1016G) 10% to 90%RH Non-condensing
0 °C to 45 °C (For LS1024G)
Storage -40 °C to 70 °C 5% to 90%RH Non-condensing
Clearness
The dust accumulated on the switch can be absorbed by static electricity and result in poor contact of
metal contact points. Some measures have been taken for the device to prevent static electricity, but too
strong static electricity can cause deadly damage to the electronic elements on the internal circuit board.
To avoid the effect of static electricity on the operation of the switch, attach much importance to the
following items:
Dust the device regularly, and keep the indoor air clean.
Keep the device well grounded and ensure that the static electricity has been transferred.
Electromagnetic Interference
Electronic elements including capacitance and inductance on the device can be affected by external
interferences, such as conducted emission by capacitance coupling, inductance coupling, and impedance
coupling. To decrease the interferences, make sure to take the following measures:
Use the power supply that can effectively filter interference from the power grid.
Keep the device far from high-frequency and strong-current devices such as radio transmitting station.
Use electromagnetic shielding when necessary.
To ask questions, find answers, and communicate with TP-Link users or
engineers, please join TP-Link Community.
For technical support and other information, please visit
https://www.tp-link.com/support/?type=smb, or simply scan the QR code.
Safety Information
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
Place the device with its bottom surface downward.
The plug on the power supply cord is used as the disconnect device, the socket-outlet shall be easily accessible.
The socket-outlet shall be installed near the equipment and shall be easily accessible
Plug the product into the wall outlets with earthing connection through the power supply cord.
Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents
or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk.
