Page 1: Pulizia Macine
manuale utente - user manual benutzerhandbuch - manual de usuario notice pour l’utilisateur... -
Page 2: Table Of Contents
2.0 User manual 1.0 Manuale utente 1.1 Targa dati 2.1 Identification plate 2.2 Coffee grinder accessories 1.2 Dotazione del macinacaffè 1.3 Avvertenze generali 2.3 General notes 2.4 Setting up for installation 1.4 Predisposizione installazione 1.5 Messa in funzione 2.5 Starting the grinder 1.6 Regolazioni 2.6 Adjustments 2.7 Burr cleaning... - Page 3 3.0 Benutzerhandbuch 4.0 Manual de usuario 5.0 Notice pour l’utilisateur 3.1 Typenschild 4.1 Placa de datos 5.1 Plaque d’immatriculation 3.2 Ausstattung der kaffeemühle 4.2 Dotación del molino de café 5.2 Accessoires fournis 3.3 Allgemeine hinweise 4.3 Advertencias generales 5.3 Généralités 3.4 Installationsvorbereitung 4.4 Predisposición para la instalación 5.4 Prédisposition en vue de l’installation...
-
Page 4: 2.0 User Manual
2.0 User manual 18 |... - Page 5 This espresso coffee grinder combines several innovative features, such as a revolutionary technology, an ergonomic design, the highest quality standard in materials and an extreme easiness of use. This manual is structured in order to be a useful tool for gaining a good knowledge of the machine and its use.
-
Page 6: Identification Plate
Identification plate 20 |... -
Page 7: Coffee Grinder Accessories
Coffee grinder accessories • User manual • Cleaning brush • Ground coffee container • Product for internal cleaning (sample for one cleaning cycle) | 21... -
Page 8: General Notes
General notes WARNING The appliance must be destined exclusively to the use it was designed for. Any other use shall be considered Please read carefully the instructions and warnings of this manual, since they provide important improper and therefore information about the use and functioning of the appliance. unreasonable. - Page 9 • The environment surrounding the appliance must have a temperature ranging from 5°C to 35°C. If the appliance is temporarily placed in an environment where the temperature is below 0°C, contact a local Technical Service authorized by the manufacturer. • In case of appliance breakdown and/or malfunctioning, switch it off and refrain from trying to repair it. Consult a local Technical Service that has been authorized by the manufacturer.
-
Page 10: Setting Up For Installation
Setting up for installation WARNING Installation must be carried out in compliance with laws in force, following the manufacturer’s instructions and by qualified You must place the grinder on a stable bearing surface (20 X 40 cm) next to the espresso machine at a personnel only. - Page 11 Grinder general description LEGEND Pic.1 Hopper lid Hopper for coffee beans Grind adjusting disk Control panel Coffee outlet Portafilter support Double dose feeler pin Grounds coffee tray Hopper-locking screw ON/OFF switch Single dose feeler pin Power cable | 25...
-
Page 12: Control Panel
Control panel Pic.2 Adjusting LEGEND ring nut Single dose light Double dose light Power light Reset button - used to reset remaining time Ring nut unlock button M1 Single dose adjusting knob M2 Double dose time adjusting knob Rotate M1 and M2 clockwise to increase grinding time of 0.1 sec per click; likewise, by rotating the knobs counterclockwise you will decrease the grinding time of 0.1 sec per click. -
Page 13: Starting The Grinder
Turn on the ON/OFF power supply switch (Pic.1). When the central warning light on the front is on (Pic.2), the grinder is ready for use. When you attach the portafilter to its support (Pic.1), Max will automatically recognize the dose to be poured (single/double). -
Page 14: Adjustments
Time adjustment When you have obtained the right grind, you can adjust the grinding time to let Max pour the right amount of ground coffee automatically. Adjust the grinding time by rotating the M1 knob for the single dose and the M2 knob for the double dose. -
Page 15: Burr Cleaning
Burr cleaning Carry out a periodic (at least weekly) cleaning cycle of the grinding chamber. You must carry out the cleaning cycle using a suitable cleaning product purchased exclusively from the coffee grinder installer. Remove all coffee beans from the hopper. WARNING Do not remove the hopper from the grinder. -
Page 16: Ordinary Maintenance
Ordinary maintenance WARNING If the coffee grinder is left unused for a few days, you will need to carry out a cleaning cycle before using it again Ordinary maintenance refers to the internal cleaning of the appliance that must be carried out every to prevent old coffee grounds from affecting the taste week through the above-mentioned cleaning cycle with a burr/grinding chamber cleaning product that...
