Paccar PACMOBILE 40X User Manual page 15

4.6 Reset the charger after an emergency stop
Procedure
1. Turn the emergency stop button clockwise to reset the emergency stop button.
4.7 How to Hard reset the charger
Procedure
1. If the CCS plug is connected to the vehicle, disconnect the CCS plug.
2. Disconnect the AC cable from the mains.
3. Wait until all the LED ring does not show any light.
Refer to Charging indicators (LED) on page 10.
4. Connect the AC cable to the mains. The charger begins the start up phase.
Note:
The LED ring shows the status of the charger.
Refer to Charging indicators (LED) on page 10.
Caution:
If the charger does not start up, there is a serious fault.
Refer to How to Soft reset the charger on page 15.
4.8 How to Soft reset the charger
• Do this procedure if the LED ring of the charger shows that a fault has been present for more
than 1 minute. Refer to Charging indicators (LED) on page 10.
If the charger does not start up after a soft reset, refer to How to Hard reset the charger on
•
page 15.
Procedure
1. Make sure that the AC input cable is connected to the mains power supply.
2. Use the emergency stop button. Refer to Use of the emergency stop button on page 14.
3. Release the emergency stop button, by turning it clockwise.
The charger should begin the start up phase.
Note:
The LED ring shows the status of the charger.
Refer to Charging indicators (LED) on page 10.
Caution:
If the charger does not start up, there is a serious fault. The charger needs a
service. Refer to Service-line structure on page 16.
4.9 Fan operation
The charger has a built-in fan at the front (refer to Components and connections of the charger on
page 10) of the cabinet. After a stop of the charging process, the fan operates for an additional
minute. This enables additional cooling of the charger. When the emergency button is pressed, the
fan stops spinning immediately to prevent any risks.
15
