3.4 Technical data
3.4.1 Charger
Table 1: Identification
Type/Model
Serial Number Unit
The maximum power rating of the charger is 40 kW (I
Input voltage: 3 x 400 V
Output voltage: 100–1000 V
Table 2: General data
Dimensions
Depth [mm]
Width [mm]
Height [mm]
Case material
Cabinet color
Carriage color
Operating temperature [°C]
Storage temperature [°C]
Protection class
Weight [kg]
Maximum floor loading [kg/m²]
Environment
Operational noise level at 2 m distance [dB(A)]
Table 3: Electrical data
Maximum rated output power (P
DC output voltage range (V
DC output current range (I
Ripple current at full load [%]
Current and voltage precision at constant setpoint [%]
Power factor
Efficiency at full load [%]
Input connections
AC input voltage range (VAC) main power [Hz]s
Maximum input current (A), main power [A]
Input current limit values [A]*
Dielectric withstand (V RMS)
Maximum short-circuit current [kA]
¹ A power selector switch can be used to set this limit.
+ N + PE
AC
DC
) [kW]
DC
) [V]
DC
) [A]
DC
40kW mobile CCS charger
HE9818004-01-YYWWXX
= 66.66 A @ 600 V )
max DC
500 mm
500 mm
900 mm
steel
RAL 7022
RAL 1023
-20 to +40
> 5
IP54 / IK10
124
300
indoor and outdoor
< 55
40
100-1000
66.66
< 2
< +/- 1 (IEC 61851-23)
> 0.94
> 94
3P + PE (fixed installations) + N
3 X 400 VAC (50-60)
63
16 / 32 / 63
3000
10
