Epever VS BN Series User Manual

Epever VS BN Series User Manual

Solar charge controller
Hide thumbs Also See for VS BN Series:
Table of Contents

Advertisement

Quick Links

Download this manual
VS BN series
---Solar Charge Controller
User Manual
Models:
VS1024BN / VS2024BN
VS3024BN / VS6024BN
VS4548BN / VS6048BN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VS BN Series and is the answer not in the manual?

Questions and answers

Related Manuals for Epever VS BN Series

Summary of Contents for Epever VS BN Series

  • Page 1 VS BN series ---Solar Charge Controller User Manual Models: VS1024BN / VS2024BN VS3024BN / VS6024BN VS4548BN / VS6048BN...

  • Page 3: Table Of Contents

    Contents 1 Important Safety Instructions 2 General Information 2.1 Overview 2.2 Characteristics 2.3 Optional Accessories 3 Installation 3.1 Mounting 3.2 Wiring 4 Functions 4.1 PWM Technology (Series Pulse Width Modulation) 4.2 Battery Charging Stage 4.3 LCD 4.4 Settings 5 Others 5.1 Protection 5.2 Troubleshooting 5.3 Maintenance...

  • Page 4: Important Safety Instructions

    1 Important Safety Instructions Save These Instructions This manual contains important safety, installation and operating instructions. The following symbols are used throughout this manual to indicate potentially dangerous conditions or mark important safety instruction. WARNING: Indicates a potentially dangerous condition. Use extreme caution when performing this task.

  • Page 5: General Information

    2 General Information Thank you for selecting VS BN series solar charge controller. The controller adopts advanced digital control technology, LCD display and automatically operation. With the features of Pulse Width Modulation (PWM) battery charging and unique control technology, the controller will improve the long battery life efficiently.
  • Page 6 User-defined  Adopt temperature compensation and update charging and discharging parameters automatically to improve the battery lifetime  With the feature of input filter, the voltage spike could be restrained effectively  Actual Power Display and record function make convenience to check the datum every day, every month and every year ...

  • Page 7: Characteristics

    2.2 Characteristics VS1024BN / VS2024BN VS3024BN / VS4548BN / VS60**BN...
  • Page 8 1 – Local temperature sensor It is used to acquire ambient temperature to do temperature compensation for charging and discharging. 2 – Fault LED indicator An LED indicator that shows system faults 3 – Charging LED indicator An LED indicator that shows charging status 4 –...

  • Page 9: Optional Accessories

    2.3 Optional Accessories Acquisition of battery temperature for undertaking temperature compensation of control parameters, the standard length of the cable is 3m (length can be customized). The RTS300R47K3.81A connects to the port Remote Temperature Sensor ) on the controller. (RTS300R47K3.81A) NOTE: The temperature sensor short-circuited or damaged, the controller will be charging or discharging at the default temperature 25 º...
  • Page 10 MT50 can display various operating data and fault info the system. The Remote Meter information can be displayed on a backlit LCD screen, the buttons are MT50 easy-to-operate, and the numeric display is readable. After the controller is connected with the eBox-WIFI-01 through the WIFI Serial Adapter standard Ethernet cable (parallel cable), the operating status and related eBox-WIFI-01...
  • Page 11 WARNING: Do not use the standard twisted-net cable to connect the device and PC net interface, or the permanent damage will occur.

  • Page 12: Installation

    3 Installation 3.1 Mounting  Read through the entire installation section first before beginning installation.  Be very careful when working with batteries. Wear eye protection. Have fresh water available to wash and clean any contact with battery acid.  Uses insulated tools and avoid placing metal objects near the batteries.
  • Page 13 Step 1: Choose Mounting Location Locate the controller on a vertical surface protected from direct sun, high temperature, and water. And make sure good ventilation. Step 2: Check for clearance Place the controller in the location where it will be mounted. Verify sufficient room to run wires and sufficient room above and below the controller for air flow.

  • Page 14: Wiring

    3.2 Wiring NOTE: A recommended connection order has been provided for maximum safety during installation. NOTE: the controller is common negative one. CAUTION: Don’t connect the loads with surge power exceeding the ratings. CAUTION: Secure all wiring for mobile applications. Use cable clamps to prevent cables from swaying.
  • Page 15 It is suggested that positive pole or negative pole of battery and loads be connected to a safety device whose operation current is not twice lower than nominal charging or discharging current. Do not switch on the safety device while it is being installed.
  • Page 16 Step 1: Wiring and switching on After solar system is wired, check all wirings carefully to make it clear whether all 6 terminals are connected correctly and tightened. According to the order of switching on in the chart, battery first, loads second and solar module third successively to avoid nominal system voltage identification error.

  • Page 17: Functions

    4 Functions 4.1 PWM Technology (Series Pulse Width Modulation) The controller adopts the advanced series pulse width modulation (PWM) charging mode. With range of 0-100%, it can charge the battery quickly and stably under any condition of solar photovoltaic system. PWM charging mode use automatic conversion duty ratio pulses current to charge the battery.
  • Page 18 When the battery has recharged to the Boost voltage set point, constant- current regulation is used to prevent heating and excessive battery gassing. The Boost stage remains 120 minutes and then goes to Float Charge. Every time when the controller is powered on, if it detects neither over discharged nor overvoltage, the charging will enter into boost charging stage.
  • Page 19  Equalize Charge WARNING: Risk of explosion! Equalizing flooded battery can produce explosive gases, so well ventilation of battery box is necessary. NOTE: Equipment damage! Equalization may increase battery voltage to the level damaging to sensitive DC loads. Ensure that all load allowable input voltages are greater than the equalizing charging set point voltage.

  • Page 20: Lcd

    4.3 LCD Charging indicator Fault indicator WELCOME V2.35+V2.63 ！ ↑/ + ↓/ - ENTER/→ MENU/←  Buttons Cursor down / Number reduce button Cursor up / Number add button Menu / Cursor left button Enter / cursor right button  Charging indicator GREEN ON whenever sunlight is available for battery charging and the charging system is normal.
  • Page 21 Solar module: Over current, Measure error of voltage, Short of reverse-protection MOS-I, Short of charging MOS-C, MOS-I or MOS-C disconnection or MOS break in control section. Battery: Over voltage, Measure error of voltage, Over temp. Load: Over load, Short, Short of discharging MOS, Measure error of voltage. Device: Over temperature.

  • Page 22: Settings

    4.4 Settings  Load mode 1. Manual mode(default) This mode is to turn ON and OFF the load by press button. Parameter Detail Note The load will open automatically Press ENTER button to after the controller is initialized. control load at the standby Manual If the battery power is enough interface in the controller or...
  • Page 23 3. Light ON + Timer When solar module voltage goes below the point of NTTV (Night Time Threshold Voltage) at sunset; the solar controller will recognize the starting voltage and turn on the load after pre-set delay time. Working time 2 is the open time of load in the light mode before dawn.
  • Page 24 Time 2 light mode before dawn time period; the actual time of load-on is relative The controller calculated the with night time, working total length of the night by Night time time1 and working time2 self-learning. The time should be more than 3 hours 4.

  • Page 25: Initialization Interface

     Interfaces  Initialization Interface When controller is powered on, the following picture will be painted during the initialization: WELCOME V2.36 + V2.63  Main Menu Interface After controller is initialized, the monitoring interface will update automatically. Press button to enter the main menu 1 interface which displays the following contents: 1．Monitoring 2．Device Set...

  • Page 26: System Monitor Interface

     System Monitor Interface In the main menu interface, press , the inverse cursor moves between main menu 1 and main menu 2.When the inverse cursor points at 1．Monitoring in the main menu 1, press to enter into the system monitoring interface which displays contents as below.
  • Page 27 TEMP 25.6 ° C SOC: ▼ Load voltage and current Press to enter into the following interface which indicates actual voltage and current of loads. LOAD 12.5V 5.5A ▼ Real-time clock and imaging system status Press to enter into the following interface which indicates real-time clock and graphic system status.
  • Page 28 : OFF : ON ﹡ Icons indicating battery charging are dynamic effects. ▼ System status Press to enter into the following interface which indicates system status. PV : Disconnect BATT : NoCharge / Normal LOAD : On DEVICE : Normal PV status: Connect Disconnect...
  • Page 29 ﹡ When fault with inverse cursor above exists for 2 minutes along without any operation, it will jump into that page automatically. ▼ Charging energy statistics Char. Energy Day: 1.17KWh Mon: 25.35KWh Total: 98.74KWh ▼ Discharging energy statistics Disch. Energy Day: 0.75KWh Mon:...
  • Page 30 Device Set Device Set – 05 - 2011 Date : ID: 001 Time : 12 : 24 : 23 Backlight: 010 sec Device Set TempUnit： In the interface, press , the inverse cursor moves among every parameter. Pressing button could move the inverse cursor back to main menu.
  • Page 31 SAVE SUCCESS！ Press and hold both button for 3 seconds to enter factory mode in the main interface. The authority code to clear Energy Log is 102206 as default. The clear operation can’t be recalled, so take care! Device Set ID : Backlight : 060sec Energy Log : Clear...
  • Page 32 parameters in sequence. Press to modify temperature compensation coefficient. Parameter Set Temp Compensate Coeff -03.0mV / º C / 2V ▼ Control parameters interface 1 Press continuously and the inverse cursor will move to the control parameters interface. Press to modify the following control parameters.
  • Page 33 Parameter Set Value is none Equal Chrg : 14.6V when GEL Boost Chrg : 14.4V battery Float Chrg : 13.8V ▼ Control parameters interface 3 Parameter Set Boost V. Rect : 13.2V Under V. Rect :12.2V Under V. Warn:12.0V Press continuously and the inverse cursor will move to the control parameters interface.
  • Page 34 Parameter Set Low V. Rect : 12.6V Low V. Disc : 11.1V Discharg Lmt : 10.6V ▼ Control parameters interface 5 Press continuously and the inverse cursor will move to the control parameters interface. Press to modify the following control parameters. Parameter Set Range from 0 to 180 Equa.Time : 120Min...
  • Page 35 Press to choose save or cancel operation. When the modification is canceled, the interface will go back main menu. Parameter Set Under V. Warn : 12.0V Save Cancel Low V. Disc : 11.1V Discharg Lmt : 10.8V When save operation confirmed, the indication of successful saving will prompt as follows.
  • Page 36 ▼ Manual control interface When the inverse cursor rests on Manual in main menu 1, press enter manual load control interface with the following contents displayed. Manual Default Press to choose ON or OFF as default. After confirmation, press and the message-box below will prompt. When it is cancelled, the inverse cursor moves back to the main menu interface.
  • Page 37 control interface shown as below: Light On/Off Delay ：10 m On : 05.0 V Delay ：10 m Off : 06.0 V Press , the inverse cursor moves among each parameters in sequence. Press to modify the values. The below message box will be prompted after press .
  • Page 38 light control and time control interface. Light On + Timer On : 05.0 V Delay ：10 m Off : 06.0 V Delay ：10 m Night Time : 10 : 00 Light On + Timer Period 1: 01:00 Period 2: 01:00 Press to modify each parameter.
  • Page 39 Light On + Timer On : 06.0 V Delay ：10 m SAVE SUCCESS！ Off : 05.0 V Delay ：10 m Work Time : 10 : 00 : 00 NOTE: When the “OFF” time is later than local sunrise time, the controller will turn off the load output at the sunrise time, because light control’s priority level is higher! ▼...
  • Page 40 Time Control 2 On Time : : 30 : 00 Off Time : 06 : 00 : 00 Single Double * In the double time control mode, time1 and time2could not overlap. When choosing Single, only value of time1 can be modified. The interface is as follows: Time Control 2 On Time : -- : -- : --...
  • Page 41 When updating successfully, the prompt will show below and then move back to the main menu. Time Control 2 On Time : 19 : 20 : 00 SAVE SUCCESS！ Off Time : 07 : 00 : 00 Single Double  Nominal Parameter Interface Press , move inverse cursor to 5．Rated...
  • Page 42 Rated Value Batt : 12.0 V Save Cancel Load : 10.0A PV : 10.0A Type : Seal Flood When updating successfully, the prompt will show below and then move back to the main menu. Rated Value Batt : 12.0 V SAVE SUCCESS！...
  • Page 43 Password Ori. PSW: 000000 New PSW: 000000 If changing the value, press to submit and the following message will to select “save” to confirm update or prompt: Press cancel. After confirmed, the cursor will move back to the main menu. Time Control 2 Save Parameters On Time : 19 : 20 : 00...
  • Page 44 Batt Mng Mode V.C. If changing the value, press to submit and the following message will to select “save” to confirm update or prompt: Press cancel. After confirmed, the cursor will move back to the main menu. Time Control 2 Save Parameters On Time : 19 : 20 : 00 Save...
  • Page 45 Factory Reset If changing the value, press to submit and the following message will to select “save” to confirm update or prompt: Press cancel. After confirmed, the cursor will move back to the main menu. Factory Reset Cancel When updating successfully, the prompt will show below and then move back to the main menu.
  • Page 46 Reboot Device If needing to reboot the device, press to submit and the device will reboot at once.

  • Page 47: Others

    5 Others 5.1 Protection  PV Array Short Circuit If PV array short circuit occurs, clear it to resume normal charge automatically.  Load Overload If the load current exceeds the rated current of controller (≥1.05 times rated discharge current), the controller will disconnect the load. Overloading must be cleared up, then pressing the switch button.

  • Page 48: Troubleshooting

    discharging. When the temperature is below 75℃, the controller resumes work.  High Voltage Transients PV is protected against smaller high voltage surge. In lightning prone areas, additional external suppression is recommended. Note: The controller has daily automatic fault recovery function which will reduce the manual operation and can intelligently eliminate the fault caused by non-actual hardware failure.
  • Page 49 ote temperature reconnect input and output circuit. sensor) over temperature Charging and Battery voltage Please restart controller, if the discharging circuit is off sensor is fault still exists, cut off charging and monitor shows abnormal and discharging circuit Error. immediately and contact the supplier to make maintenance.
  • Page 50 Discharging circuit is off Load circuit is Please check carefully loads and the LOAD monitor short connection; It is reactivated after shows Short. delayed 5 seconds for the first time, 10 seconds for the second time, 15 seconds for the third time, 20 seconds for the fourth time and 25 seconds for the fifth time.

  • Page 51: Maintenance

    5.3 Maintenance The following inspections and maintenance tasks are recommended at least two times per year for best performance.  Check that the air flow and ventilation around the controller is not blocked. Clear all dirt or fragments on the heat sink. ...

  • Page 52: Technical Specifications

    6 Technical Specifications Model： 1024 2024 3024 6024 VS****BN Electrical Parameters 12 ∕ 24VDC Auto Nominal System Voltage Maximum Battery Voltage Maximum PV Voltage Rated Charge Current Rated Discharge Current Charge Circuit Voltage ≤0.69V Drop Discharge Circuit Voltage ≤0.17V Drop ≤15mA@12v;...
  • Page 53 Model： 4548 6048 VS****BN Electrical Parameters 12 ∕ 24 ∕ 36 ∕ 48VDC Auto Nominal System Voltage Maximum Battery Voltage Maximum PV Voltage Rated Charge Current Rated Discharge Current Charge Circuit Voltage Drop 0.53V Discharge Circuit Voltage Drop 0.16V ≤15mA@12v; ≤10mA@24v;...
  • Page 54 Battery Type Sealed Flooded User High Volt Disconnect 9~17V Charging limit voltage 9~17V Over Voltage 9~17V Reconnect —— Equalization voltage 14.6V 14.8V 9~17V Boost voltage 14.4V 14.2V 14.6V 9~17V Float voltage 13.8V 13.8V 13.8V 9~17V Boost return voltage 13.2V 13.2V 13.2V 9~17V Low voltage reconnect...
  • Page 55 Threshold voltage value 10V;20V∕24V; 30V∕36V; 40V∕48V Night Time Upper limit 1V; 2V∕24V; 3V∕36V;4V∕48V Threshold Voltage Low limit Default 6V/12V 10V; 20V∕24V;30V∕36V; 40V∕48V Time Upper limit 1V; 2V∕24V; 3V∕36V;4V∕48V Threshold Voltage Low limit Default 5V/12V Temperature compensate 0mV∕℃∕2V Temperature Upper limit -9mV∕℃∕2V compensate Low limit...
  • Page 56 Φ4. VS1024BN Dimensions in Millimeters [Inches] Φ4. VS2024BN Dimensions in Millimeters [Inches]...
  • Page 57 Φ4. VS3024BN Dimensions in Millimeters [Inches] Φ4. 204.8 VS4548BN Dimensions in Millimeters [Inches]...
  • Page 58 Φ4. 204.8 VS6024BN Dimensions in Millimeters [Inches]...
  • Page 59 Φ5 VS6048BN Dimensions in Millimeters [Inches] Any changes without prior notice! Version number: V2.2...
