Huawei UPS5000-E-120K-FM Quick Manual

UPS5000-E-120K-FM
(30 kVA Power Modules)
Quick Guide
Issue: 04
Date: 2025-01-15
Copyright © Huawei Digital Power Technologies Co., Ltd. 2025. All rights reserved.
Installation Preparation
• Before installing the equipment, read the product documentation carefully to get familiar with
product information and safety precautions. Equipment damage caused by failure to abide by
the storage, transportation, installation, and operation guidelines specified in the product
documentation is not covered by the product warranty. Log in to the technical support website
to view the product documentation and safety precautions.
• The information in this document is subject to change without notice. Every effort has been
made in the preparation of this document to ensure accuracy of the contents, but all
statements, information, and recommendations in this document do not constitute a warranty
of any kind, express or implied.
• Only qualified personnel are allowed to perform operations on the equipment. Operation
personnel should understand the system, its working principles, and relevant national/regional
standards.
• Wear dedicated personal protective equipment during operations. Use dedicated insulated tools
during electrical operations.
Environment requirements
310 kg
Operating Relative humidity
Floor and support
The equipment
temperature 0%–95% RH
load capacity
room is airtight.
0–40°C (non-condensing)
Heat source, Dust or
Water source,
inflammable or Direct sunlight conductive
water vapor
explosive article metal dust
Clearance
Unit: mm
Recommended Circuit Breaker Specifications for
a 380 V AC/400 V AC/415 V AC Voltage System
When the Short-circuit Current Going Through the Device
Capacity
120 kVA
90 kVA
60 kVA
30 kVA
Recommended Cable Specifications for
a 380 V AC/400 V AC/415 V AC Voltage System (mm
Capacity Mains Input
L1: 95
L2: 95
120 kVA L3: 95
N: 95
PE: 50
L1: 70
L2: 70
90 kVA L3: 70
N: 70
PE: 35
L1: 35
Excessive
L2: 35
salt content
60 kVA L3: 35
N: 35
PE: 25
L1: 10
L2: 10
Volatile or
30 kVA L3: 10
corrosive
substance N: 10
PE: 10
Is Less than 36 kA
Mains Input Bypass Input Output
250 A/3P 250 A/3P 250 A/3P
200 A/3P 200 A/3P 200 A/3P
125 A/3P 125 A/3P 125 A/3P
63 A/3P 63 A/3P 63 A/3P
2
)
Bypass Input Output Battery Input
L1: 70 U: 70
+: 95
L2: 70 V: 70
N: 95
L3: 70 W: 70
-: 95
N: 70 N: 70
PE: 50
PE: 50 PE: 50
L1: 50 U: 50
+: 70
L2: 50 V: 50
N: 70
L3: 50 W: 50
-: 70
N: 50 N: 50
PE: 35
PE: 35 PE: 35
L1: 25 U: 25
+: 50
L2: 25 V: 25
N: 50
L3: 25 W: 25
-: 50
N: 25 N: 25
PE: 25
PE: 25 PE: 25
L1: 10 U: 10
+: 16
L2: 10 V: 10
N: 16
L3: 10 W: 10
-: 16
N: 10 N: 10
PE: 10
PE: 10 PE: 10
1
Installing a Cabinet
Secured Installation
1 Determine the UPS cabinet installation position. Draw mounting holes in the
installation position according to the drawing.
Unit: mm
2
Drill holes in the mounting holes using a hammer drill, and install expansion bolts
in the holes.
M12 bolt
Spring washer
Flat washer
Concrete floor
Expansion sleeve
Expansion nut
3
Move the cabinet to the installation position. Remove the rear panel of the
cabinet, and then open the front door.
