INSTALLATION, SERVICE & PARTS MANUAL
860 Church Rd Elgin, IL 60123
330 Mill Bay South Suite 1511
IL - (847) 841-7867
Distributed by Pump Supply Inc
CP4NC-SS
Illinois Location:
(847) 841-7867
Minnesota Location:
(651) 758-7867
Afton, MN 55001
PumpSupplyInc.com
Series:
CP4NC2834SS, CP4NC2844SS
CP4NC3724SS, CP4NC3734SS,
CP4NC3744SS, CP4NC3764SS,
CP4NC5024SS, CP4NC5034SS,
CP4NC5044SS, CP4NC5064SS
1750RPM, 60Hz
PumpSupplyInc.com
2.8, 3.7 & 5HP
Submersible Non-Clog
No: CPNC4_ss - 04/15
CP4NC2824SS
MN - (651) 758-7867
1
MN - (651) 758-7867
Advertisement
Table of Contents
Related Manuals for Champion Pump CP4NC-SS Series
Summary of Contents for Champion Pump CP4NC-SS Series
- Page 1 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 CP4NC-SS 2.8, 3.7 & 5HP Submersible Non-Clog No: CPNC4_ss - 04/15 INSTALLATION, SERVICE & PARTS MANUAL Series: CP4NC2824SS CP4NC2834SS, CP4NC2844SS CP4NC3724SS, CP4NC3734SS, CP4NC3744SS, CP4NC3764SS, CP4NC5024SS, CP4NC5034SS, CP4NC5044SS, CP4NC5064SS 1750RPM, 60Hz Illinois Location: (847) 841-7867...
-
Page 2: General Safety Information
Each Champion pump is Keep clear of suction working on a used pump or piping. Never individually factory tested to insure proper and discharge enter a basin after it has been used. - Page 3 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Specifi cations DISCHARGE 4” 125 lb., Flange Horizontal LIQUID TEMPERATURE 104°F MOTOR HOUSING Cast Iron, Class 30 VOLUTE Cast Iron, Class 30 2 vane open type with pump out vanes on back IMPELLER side, Dynamically balanced, ISO G6.3, Cast Iron, Class 30...
- Page 4 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Dimensions CP4NC2834SS, CP4NC2844SS NEMA FULL LOCKED CORD CORD CORD MODEL Volts/Ph START LOAD ROTOR SIZE TYPE O.D. CODE AMPS AMPS CP4NC2834SS 230/3 1750 35.0 10/4 0.75 CP4NC2844SS 460/3 1750 17.5...
- Page 5 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Dimensions CP4NC2824SS, CP4NC3724SS, CP4NC3734SS, CP4NC3744SS, CP4NC3764SS, CP4NC5024SS, CP4NC5034SS, CP4NC5044SS, CP4NC5064SS NEMA FULL LOCKED CORD CORD CORD MODEL Volts/Ph START LOAD ROTOR SIZE TYPE O.D. CODE AMPS AMPS CC4NC2824SS 230/1 1750...
- Page 6 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Performance Illinois Location: (847) 841-7867 860 Church Rd Elgin, IL 60123 Minnesota Location: (651) 758-7867 330 Mill Bay South Suite 1511 Afton, MN 55001 PumpSupplyInc.com IL - (847) 841-7867 PumpSupplyInc.com MN - (651) 758-7867...
-
Page 7: Receiving And Installation
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Receiving & Installation Receiving Inspection Installation Liquid Level Controls Upon receiving the pump, it should be These pumps are recommended for The level control(s) should be mounted inspected for damage or shortages. -
Page 8: Installation & Service
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Installation & Service IMPORTANT ! - The overload will then Kickback should always be in a a). Inspect motor chamber for oil level automatically reset and start the pump counter-clockwise direction as and contamination. - Page 9 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Service Pressure Test (If oil has been drained) Pressure builds up extremely 5. Remove washer (15) and v-gasket (16) Remove pipe plug (20) from housing (4). fast, increase pressure by and remove if damaged.
- Page 10 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Service Shaft Seal: 2. Press seal’s (6) stationary member 7. On Single phase units, connect firmly into seal plate (3), use a seal tool 13. Unscrew conduit bushing (29) from capacitor (34) to motor wires.
- Page 11 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Service Models - CP4NC2824SS, 3744SS, 3734SS, 3744SS, 3754SS, 3764SS, 5024SS, 5034SS, 5044SS, 5054SS, 5064SS 16. Pull wires through large opening in motor housing (4) an connect wires with cord (22) in Conduit box (33) per schematic in Figure 5.
-
Page 12: Repair Parts
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Repair Parts For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC2834SS, 2844SS Name Plate, and Part Description and Part Number as shown on Parts List. Figure 6 IL - (847) 841-7867 PumpSupplyInc.com... - Page 13 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Repair Parts For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC2834SS, 2844SS Name Plate, and Part Description and Part Number as shown on Parts List. Figure 7 IL - (847) 841-7867 PumpSupplyInc.com...
-
Page 14: Parts List
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Parts List For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC2834SS, 2844SS Name Plate, and Part Description and Part Number as shown on Parts List. Ref. - Page 15 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Repair Parts For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC2824SS, 3724SS, 3734SS, 3744SS, Name Plate, and Part Description and Part Number as shown on Parts List. 3764SS, 5024SS, 5034SS, 5044SS, 5064SS Figure 8 IL - (847) 841-7867...
- Page 16 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Parts List For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC2824SS, 3724SS, 5024SS Name Plate, and Part Description and Part Number as shown on Parts List. Figure 9 IL - (847) 841-7867 PumpSupplyInc.com...
- Page 17 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Parts List For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC2824SS, 3724SS, 5024SS Name Plate, and Part Description and Part Number as shown on Parts List. Ref.
- Page 18 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Parts List For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC3734SS, 3744SS, 3764SS, 5034SS, Name Plate, and Part Description and Part Number as shown on Parts List. 5044SS, 5064SS Figure 10 IL - (847) 841-7867...
- Page 19 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Parts List For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC3734SS, 3744SS, 3764SS, 5034SS, Name Plate, and Part Description and Part Number as shown on Parts List. 5044SS, 5064SS Ref.
- Page 20 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Parts List For Repair Part Please supply: Model Number and MFG Date as shown on CP4NC3734SS, 3744SS, 3764SS, 5034SS, Name Plate, and Part Description and Part Number as shown on Parts List. 5044SS, 5064SS Ref.
- Page 21 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Notes: Illinois Location: (847) 841-7867 860 Church Rd Elgin, IL 60123 Minnesota Location: (651) 758-7867 330 Mill Bay South Suite 1511 Afton, MN 55001 IL - (847) 841-7867 PumpSupplyInc.com MN - (651) 758-7867 PumpSupplyInc.com...
- Page 22 IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Notes: Illinois Location: (847) 841-7867 860 Church Rd Elgin, IL 60123 Minnesota Location: (651) 758-7867 330 Mill Bay South Suite 1511 Afton, MN 55001 IL - (847) 841-7867 MN - (651) 758-7867 PumpSupplyInc.com...
-
Page 23: Troubleshooting Chart
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 Trouble Shooting Chart Risk of electric shock. Always disconnect the pump from the power source before handling inspections or repairs. Symptom Possible Cause(s) Corrective Action 1. Poor electrical connection, blown fuse, tripped 1. -
Page 24: Limited Warranty
IL - (847) 841-7867 Distributed by Pump Supply Inc MN - (651) 758-7867 LIMITED WARRANTY Manufacturer warrants, to the immediate purchaser and subsequent initial owner during the warranty period, every new pump to be free from defects in material and workmanship under normal use and service, when properly used and maintained, for a period of eighteen (18) months from date of manufacture or twelve (12) months from date of installation (which ever comes fi rst). - Page 25 Start-Up Report / Warranty Registration Please fill out the following questions as completely and accurate as possible. Please mail to Champion Pump Company, Inc. – P. O. Box 528 – Ashland, OH 44805. REPORTS THAT ARE NOT RETURNED CAN DELAY OR VOID WARRANTY.
