- Page 1 ASSEMBLY INSTRUCTION STEIN QUEEN BED 82919 1595MM 300MM 2105MM Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt 82919...
-
Page 2: Pre-Assembly Preparation
PRE-ASSEMBLY PREPARATION Before you start: Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product Take care when lifting. Product should be assembled as near as possible to the point of use Ensure that you have all required contents for complete assembly Always read the assembly instructions carefully before beginning assembly. -
Page 3: Parts List
PARTS LIST HEADBOARD FOOTBOARD SIDE RAIL CENTER RAIL CENTER SUPPORT LEG BED LEG SLATS JCBB M8 x 16mm Allen Key M4 Allen Key M5 16xC Wood Screw JCBC M6 x 40mm JCBC M6 x 25mm M4 x 20mm Wood Screw M4 x 25mm 43xG 82919... - Page 4 STEP 1 : Attach (6) to (1) and (2) with (C) Using a Allen Key M5 (B) as shown 1&2 STEP 2 : Attach (5) to (4) with (D) Using a Allen Key M4 (A) as shown 82919...
- Page 5 STEP 3 : Attach Assembled Center Support to Assembled Bed with (F) using a Screwdriver as shown 1&2 STEP 4 : Attach Assembled Bed Slats to Assembled Bed Frame with (E) Using a Allen Key M4 (A) as shown. 82919...
- Page 6 STEP 5 : Attach Assembled Bed Slats to Assembled Bed Frame with (G) using a Screwdriver as shown. ASSEMBLY IS COMPLETE CAUTION: ALWAYS LIFT YOUR BED WHEN MOVING/RELOCATING - DO NOT DRAG. DRAGGING CAN CAUSE THE CENTRE SUPPORT LEGS TO BEND/BREAK 82919...
-
Page 7: Product Care
PRODUCT CARE: REGULAR CARE: Protect from direct sunlight • Vacuum regularly using low suction • • Do not place sharp materials (knife, fork, etc.) directly onto your furniture as sharp material may scrape and damage the finish. • Do not place material with high temperature directly onto the surface of your furniture. CLEANING: Protect from direct sunlight •...
