Resetting and Initializing the System

Resetting and Initializing the System

Resetting the System

To reset the system:
If the system's RS-232 connection uses twisted pair cable, before resetting do one of the following:
• Make sure the RS-232 cable is connected at both ends (i.e., PC and CPU).
• If the RS-232 cable is disconnected from the PC, be sure the cable is also disconnected from the CPU.
1. Briefly press (tap) the Reset Switch on the Main Equipment Cabinet.
• The power LED will flash green, and then "flutter" blue as the system boots.
• After about 45 seconds, the LED will wink off blue continuously and the system will be operational.
• Resetting the system does not erase system programming.
44 ◆ Installation
Important
Figure 26: Resetting the System
1
DSX-40 Hardware Manual
