Getting Started:
MiniMACS6-AMP4
with ApossIDE / ApossC / SDK
Date
Document number
Document index
Specific use
Content
1
2
3
4
5
6
7
MiniMACS6-AMP4_GettingStarted_11645158-01.docx
Printed: 2025-01-20 10:51:57 Document: 11645158/en/01/Released/Public
10. September 2024
11645158
01
Document for external use
zub machine control AG
Buzibachstrasse 31
6023 Rothenburg
Schweiz
Telefon +41 (0)41 541 50 40
info@zub.ch
www.zub.ch
2
3
6
7
10
15
16
Page 1/16
