- Page 1 Installation Instructions 12in. & 16in. Deep Accessory Tower JLH-610, 610W, 611CH, 615, 618, 620, 620W, 623CH, 624, 625...
-
Page 2: Parts List
#8 1 in. (Flat) Allen wrench Tower Bracket Shelf mounting L-Clip Mushroom Cap REQUIRED TOOLS FOR INSTALLATION: The following tools will be needed to assemble and install your John Louis Home Solid Wood Accessory Tower: • Pencil • Tape Measure •... -
Page 3: Step 1: Tower Assembly
STEP 1: Tower Assembly Place tower sides down with grooves facing up. Insert cam bolts at tower bottom hole locations (Do not over tighten). Insert tower sides into tower bottom (24in. shelf with nameplate). Insert cam nuts into tower bottom shelf with arrow facing bolt hole. Secure by turning cam nuts clockwise to tighten. - Page 4 Note: The purpose of the Tower Stabilizer Bar is to hold the You will space 2 L-clips equidistant within the 24 in. level line. tower sides parallel prior to securing against back wall. It is (Install into wall studs when possible. If no stud is present, use wall installed in conjunction with the 2 middle tower brackets.
- Page 5 11. Install wall anchors at tower bracket hole locations if no stud is present. 12. Place tower back onto L-clip hardware and align with hole locations. 13. Double-check that tower is plumb. 14. Secure brackets to the wall using # 8 1 1/2 in. screws at all hole locations. 15.
