ARC-ACEM
INSTALLATION INSTRUCTION
SELF-DIAGNOSTICS/SELF-TESTING OPTION
SAVE THESE INSTRUCTIONS
1. When AC power is supplied to fixture, the unit will automatically initiate a self-test and self-diagnostic
test as follows:
(1) Verifies battery disconnection, charger board failure at every 4 seconds.
(2) One-minute self-testing every month.
(3) 90 minutes self-testing on the 12th month of the year after installation.
2. Dual color LED lamp indicator shows the following status:
(1) Green color: ON/ Ready
Blinking: Testing
(2) Red color (Service Alert)
(3) Service Alert LED Code (Red color LED lamp indicator)
One blink ON/pause
Two blinks ON/pause (4 seconds)
Three blinks ON/pause (4 seconds)
Four blinks ON/pause (4 seconds)
Five blinks ON/pause (4 seconds)
CAUTION:
After solving the fault of emergency equipment, Please press test button for 2 seconds then release to reset.
LED indicator will show green.
3. For manual test, press test button as follows:
Press test button once
Press test button twice
Press test button 3 times (within 2 seconds)
Press test button 4 times (within 2 seconds)
© 2023 Signify Holding. All rights reserved. The information provided herein is subject to change, without notice. Signify does not give any representation or
warranty as to the accuracy or completeness of the information included herein and shall not be liable for any action in reliance thereon. The information
presented in this document is not intended as any commercial offer and does not form part of any quotation or contract, unless otherwise agreed by Signify
(4 seconds)
(within 2 seconds)
(within 2 seconds)
page 4 of 5 F.1
Battery is not connected
Battery is shorted or battery voltage drops below acceptable level
Charger board circuit fault
Transfer function failure
Emergency lamp fault
30 seconds discharge test
3 minutes discharge test
30 minutes discharge test
90 minutes discharge test
