Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873
Telephone 855-486-2216
ADAPTER
SCREWS
BALLAST TRAY
HANDLE
REFLECTOR
ASSEMBLY
LENS DOOR
CAUTION
1. The electrical power must be disconnected from the fixture and pole before installing, servicing, or
relamping the fixture.
2. These directions must be read carefully and adhered to. Failure to do so may result in injury, damage to
the fixture, and voiding the warranty.
3. CF5T/CXF5 Hanging Fixture: This fixture must be hung from a Universal Fixture adapter, supplied with all
Hadco arms, or as a separate accessory to be mounted to a non-Hadco arm. See the instructions
supplied with the adapter for further information.
This fixture is intended for installation in accordance with the National Electrical Code and local code
specifications. Failure to adhere to these codes and instructions may result in serious injury and/or damage
to the ballast and void the warranty. These instructions do not purport to cover all details or variations in
equipment, nor to provide for every possible contingency related to installation, operation, maintenance,
or mounting situation. Should specific problems occur that are not addressed by these instructions, contact
your Sales Representative or distributor for assistance. Retain these instructions for future reference.
32001043, revision F
Signify Canada Ltd.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Telephone 800-668-9008
BALLAST
ASSEMBLY
(CF Series Shown)
INSTALLATION INSTRUCTIONS:
CF5T, CXF5 FIXTURES
UNIVERSAL FIXTURE
ADAPTER
FIXTURE SUPPLY
POWER SUPPLY
ARM WIRES
WIRES
DROP LENS IF 5V
OPTICS AND MOGUL
SOCKET. OTHERWISE
FLAT LENS.
page 1 of 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hadco CF5T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIGNIFY Hadco CF5T

  • Page 1: Installation Instructions

    INSTALLATION INSTRUCTIONS: CF5T, CXF5 FIXTURES Signify North America Corporation Signify Canada Ltd. 200 Franklin Square Drive 281 Hillmount Road, Somerset, NJ 08873 Markham, ON, Canada L6C 2S3 Telephone 855-486-2216 Telephone 800-668-9008 UNIVERSAL FIXTURE ADAPTER ADAPTER SCREWS POWER SUPPLY BALLAST ARM WIRES...
  • Page 2 TOOLS REQUIRED FOR INSTALLATION 1. Flat head screw driver - to open or close lens door. 2. Phillips head screw driver - to remove or re-install the reflector assembly and ballast assembly. 3. 5/16" Allen wrench - to assemble (2) piece clamp collar FOR RELAMPING: 1.
