Appendix A: Specifications

General
Standards
Topology
Protocol
Data Transfer
Rate
Network Media
(Cable)
Number of Ports
LED indicators
Transfer Method
MAC Address
Learning
Frame Filter Rate
Frame Forward
Rate
IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T
Star
CSMA/CD
Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex)
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full
Duplex)
Gigabit Ethernet: 2000Mbps (Full Duplex)
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-TX: UTP category 5, 5e cable (maximum
100m)
EIA/TIA-568 100 STP (maximum 100m)
1000Base-T: UTP category 5e, 6 cable (maximum
100m)
EIA/TIA-568 100 STP (maximum 100m)
16/24 10/100/1000Mbps Auto-Negotiation RJ-45 ports
POWER, Link/Act, 1000Mbps
Store-and-Forward
Automatically learning, automatically aging
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
1000Base-T: 1488095pps/Port
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
1000Base-T: 1488095pps/Port
