SMC Networks GS501 Datasheet

SMCGS501/SMCGS801
EZ Switch 10/100/1000
TM
5-/8-port Unmanaged Gigabit Ethernet Desktop Switches
Product Overview
The EZ Switches 10/100/1000 SMCGS501/SMCGS801, 5-/8-port
Gigabit Ethernet switches, are the perfect solution for bottlenecks
on your home or SOHO network. Bottlenecks are the inevitable
result of data-intensive applications like home movies or digitial
images and more computers being connected. The switches
provide a seamless migration to higher-speed networking while
solving bandwidth issues. They are designed to allow
simultaneous transmission of multiple packets via high-speed data
channels. Environmentally friendly they consume less power than
non-Green Ethernet switches without reducing network
performance. IEEE 802.1p data prioritization, Auto-MDIX on all
ports and a fan-less design make these Gigabit desktop switches
ideal for home and small office network environments.
Key Features and Benefits
Green Ethernet Support
Environmentally friendly these switches allow
significant power saving compared to non-Green
switches.
Support for Quality of Service
When the switches receive a frame tagged with an
802.1p priority tag, they will place it into a priority
queue. Priority queuing is useful in implementations
where time-sensitive data such as voice and video
are streamed across the network.
Application Diagram
Auto MDI/MDI-X on each port
Support from Auto-MDIX means that no cross-
over cables are required. Simply plug and play.
Metal chassis, fan-less design
The compact, rack mountable metal chassis is
ideal for desktop or rack mounting applications. In
addition, the lack of fans ensures silent operation.
