FRD Series
Inline Centrifugal Fans
PARTS IN THE BOX
Inline Fan FRD, 1 pc
Mounting Brackets, 4 pcs
Operation and Installation Manual, 1 pc
REGISTER* THIS PRODUCT TO
INCREASE YOUR PRODUCT
WARRANTY BY AN EXTRA YEAR
registration.fantech.app
United States
Tel.: 800 747 1762
Canada
Tel.: 800 565 3548
Latinoamérica
Tel.: +52 55 1328 7328
Installation and Operation Manual
* in USA only
Literature Item #: 400076
Rev Date: 2024-10-28
Systemair Inc.
certifies that the FRD
Series shown herein
is licensed to bear
the AMCA Seal. The
ratings shown are
based on tests and
procedures performed
in accordance with
AMCA Publication 211
and AMCA Publication
311 and comply with
the requirements of
the AMCA Certified
Ratings Program.
Advertisement
Related Manuals for SystemAir fantech FRD Series
Summary of Contents for SystemAir fantech FRD Series
- Page 1 Inline Centrifugal Fans PARTS IN THE BOX Inline Fan FRD, 1 pc Mounting Brackets, 4 pcs Operation and Installation Manual, 1 pc Systemair Inc. certifies that the FRD Series shown herein is licensed to bear the AMCA Seal. The ratings shown are...
- Page 2 Note Warning / Information Technical Practical tip Important information note WARNINGS DO NOT CONNECT POWER SUPPLY until fan is completely installed. Make 1. The compactness and adaptability of the FRD Series fans permit easy sure electrical service to the fan is in the locked “OFF” position. installation.
- Page 3 MOUNTING ILLUSTRATION 1 Please follow all applicable codes when installing this unit Please follow all applicable codes when installing this unit. 1. Determine the fan location and preferred mounting method. Suspended from 2. If needed, install the included mounting bracket on fan. Be sure to use structure with all four brackets and plug any unused holes.
-
Page 4: Dimensions And Wiring
DIMENSIONS AND WIRING Model Flange FRD 12-6 FRD 16-8 FRD 16-8XL FRD 20-10 FRD 24-14 120V FRD 12-6, FRD 16-8, FRD 16-8XL & FRD 20-10 FRD 24-14 Green/Yellow ( (Ground) Green/Yellow ( (Ground) Motor Blue Supply N (White) Motor Supply Brown L (Black) Leads... -
Page 5: Warranty
WARRANTY Make a scan of the QR code above to access Fantech’s warranty in English, French, or Spanish. Includes a 5y warranty. If additional support is needed to retrieve the war- ranty, visit fantech.net; call (800) 747–1762 (US), (800) 565–3548 (Canada), or +52 55 1328–7328 (Latin America);... - Page 6 NOTES...
- Page 7 NOTES...
- Page 8 Fantech reserves the right to make technical changes. For updated documentation please refer to www.fantech.net Fantech®...
