PROAIM DL-SPIN-01 Assembly Manual page 12

•
Use a 10mm Allen key to loosen the Allen
bolt on one side of the dolly's front section
and remove it.
•
Repeat the same process to remove the
Allen bolt on the opposite side.
•
Use a 6mm Allen key and a 17mm spanner
to loosen the bolt and hex nut from the
bottom side, then remove the steering rod.
NOTE: When the steering rod is removed, the
handle will be mounted on only one side.
•
Now, carefully de-attach the front section
of the dolly.
•
Now insert the wheel Axel on both side of
dolly.
•
Now attach the wheel to both sides of the
dolly.
•
Then insert the CSK bolt and tighten it using
a 5mm Allen key.
•
Your dolly's length
shortened.
is now properly
