Summary of Contents for Yardworks 267-1545
- Page 1 Corded Hedge Trimmer 267-1545 OPERATOR’S MANUAL TOLL-FREE HELPLINE: 1-888-497-7273 Read this operator manual before using this product. Failure to do so can result in serious injury. SAVE THIS MANUAL - 01 -...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................03 INTENDED USE ........................03 FUNCTION DESCRIPTION ....................03 NOTES ON SAFETY ......................03 KNOW YOUR TOOL ......................07 OPERATION ........................08 MAINTENANCE/CLEANING ....................09 DISPOSAL .........................10 TROUBLE SHOOTING ......................11 - 02 -... -
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your new device. With it, you have chosen a high quality product. During production, this equipment has been checked for quality and subjected to a final inspection. The functional- ity of your equipment is therefore guaranteed. It cannot be ruled out that residual quantities of lubricants will remain on or in the equipment in isolated cases. - Page 4 Symbols in the manual SYMBOL DESCRIPTION SYMBOL DESCRIPTION Warning symbols with information on Machines are not to be place with damage and injury prevention. domestic waste. Instruction symbols with information Pull out the power plug before carrying on preventing damage. out any work on the equipment.
-
Page 5: General Safety Directions For Power Tools
General Safety Directions for Power Tools WARNING! Read all safety notices, instructions, illustrations and technical data that have been provided with this power tool. Omissions in the compliance with safety directions and instructions can cause electrical shock, fi re and/or severe injuries. Retain all safety directions and instructions for future use. -
Page 6: Hedge Trimmer Safety Warnings
4) POWER TOOL USE AND CARE a. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b. -
Page 7: Additional Safety Instructions
Additional safety instructions ● Connect the appliance to a power socket with a residual current circuit breaker of rated residual current no more than 30 mA. ● If the replacement of the supply cord is necessary, this has to be done by the manufacturer or his agent in order to avoid a safety hazard. -
Page 8: Technical Data
TECHNICAL DATA 267-1545 Item EGTACHT001 Input voltage 120V~,60Hz No load speed: 1700rpm Input power (power 5A±10% Max. cutting dia 5/8 inch(16mm) consumption) (P) Safety class Blade 65Mn Laser Cut Blade length 18inch(450 mm) Cable length 0.25M Noise and vibration values have been determined according to the standards and regulations mentioned in the declaration of conformity. -
Page 9: Cutting Techniques
● Avoid overstraining the equipment during work. Pull out the power plug immediately if the cable is damaged, badly twisted or has been complete- ly cut through. There is a risk of injury from electric shock! Cutting Techniques ● Cut thick branches beforehand using a branch clippers. ●... -
Page 10: Wall Bracket
Cleaning and servicing the blade knife bar Clean the cutter bar carefully after each use. After using the equipment, it is imperative to: Clean the blade (with an oily cloth); Oil the blade shaft with an oil can or spray. Storage ●... -
Page 11: Trouble Shooting
TROUBLE SHOOTING Problem Possible Cause Fault correction Check plug socket, cable, line and Mains voltage not on plug,where appropriate, have repaired through electrical specialist Device does not start On/Off switch or deadman switch defective Repair by Service Centre Worn carbon brushes Defective motor Check the cable and have it Power cable is damaged... - Page 12 SKU# 267-1545 YARDWORKS WARRANTY POLICY ● Two (2) year limited warranty on all Yardworks C o r d e d power tools from date of purchase when used for personal, household, or family use. ● Warranty voided if used for commercial or industrial purposes or any other improper use as determined by Yardworks.
- Page 13 - 13 -...
- Page 14 - 14 -...
