Skope SK1300 Operating And Service Manual

2 door top mounted vertical cooler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SKOPE SK1300
2 DOOR
Top Mounted Vertical Cooler
Operating
and
Service Manual
December 2001 Edition
MAN7976

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK1300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skope SK1300

Summary of Contents for Skope SK1300

  • Page 1 SKOPE SK1300 2 DOOR Top Mounted Vertical Cooler Operating Service Manual December 2001 Edition MAN7976...
  • Page 3 E-mail: enquiry@skope.co.nz AUCKLAND PO Box 12-996, Penrose Auckland Freephone: 0800 947 5673 Fax: (09) 525 3994 SKOPE AUSTRALIA PTY LIMITED A.C.N. 000 384 270 PO Box 6493, Wetherill Park NSW 2164 Australia Freephone: 1800 121 535 Fax: 1800 121 533 E-mail: enquiry@skope.co.nz...
  • Page 4 S K O P E Copyright © 2001 SKOPE Industries Limited All Rights Reserved December 2001 edition MAN7976 SKOPE is the registered trademark of SKOPE Industries Limited Christchurch, New Zealand SKOPE Industries Limited is accredited to the International Quality Assurance System ISO 9002...

  • Page 5: Table Of Contents

    T A B L E O F C O N T E N T S SPECIFICATIONS Cabinet and Refrigeration Unit ..........7 INSTALLATION Assembly .

  • Page 7: Cabinet Construction

    REFRIGERATION SYSTEM Integral top mounted, SKOPE Cyclone refrigeration unit. ® Induced draught condenser and evaporator coils. Nominal capacity: 820 Watts Compressor: Danfoss SC21G Refrigerant: R134a Charge: 720 grams SKOPE Industries Limited reserve the right to alter specifications without notice. SKOPE SK1300...

  • Page 8: Installation

    I N S T A L L A T I O N ASSEMBLY INSTRUCTIONS POSITIONING OF MACHINE If the SKOPE SK1300 cabinet has been sup- The mains flex exits below the rear panel be- plied with the SKOPE Cyclone® unit and hind the SKOPE Cyclone®...

  • Page 9: Operation

    When using any electrical appliance, basic Plug in machine and check operation of safety precautions should always be ob- SKOPE Cyclone® unit and lights. Com- served. READ THESE INSTRUCTIONS pressor, evaporator and condenser fans CAREFULLY. Do not use this appliance for should all operate initially.

  • Page 10: Service Instructions

    SKOPE CYCLONE UNIT ing. The SKOPE Cyclone® unit is a self-con- The preventative maintenance recommen- tained refrigeration module which aligns dation is to clean the condenser at 1 to 6 with ‘port holes’...

  • Page 11: Thermostat Setting

    Procedures • Reseal the flex hole in the evaporator box carefully on replacement. SKOPE recommend the SKOPE Cyclone® demountability and exchangeability philoso- Thermostat phy, which in essence means:The customer This is pre-set to give an internal air temper- must not be inconvenienced during system ature of 2°C to 4°C and in normal circum-...
  • Page 12 • Clean work practices are essential. The Cyclone® must be fully evacuated and • SKOPE recommend brazing the system charged to the volume of refrigerant indicat- closed after service; as valves are prone to ed on the Cyclone®...

  • Page 13: Interior Lights

    Compress the centre pillar at the top. Unclip 5ft Centre Pillar Light and 'peel' off the plastic cover from top to Figure 4 bottom. The fluorescent tube may be re- moved by revolving it until the pin position allows withdrawal. SKOPE SK1300...
  • Page 14 Glass Door Identification Square Door Radiused Frame Door Frame SKOPE glass doors fitted to the SK1300 have either the Mk. 2 - square door frame Glass Glass profile (see figure 6), or the new Mk. 3 - ra- diused door frame profile (see figure 7).

  • Page 15: Gasket Replacement

    Split Pin holes 3. Remove existing capstan and bush from old torsion bar. 4. Thread the capstan, complete with the Door Torsion Bar bush, over the ‘round hook’ end of the new torsion bar (see figure 8). Figure 8 SKOPE SK1300...

  • Page 16: Pressure Temperature Chart

    12.2 14.0 15.8 17.6 19.4 21.2 23.0 24.8 26.6 28.4 30.2 32.0 33.8 35.6 37.4 39.2 41.0 42.8 44.6 46.8 48.2 50.0 53.6 57.2 60.8 64.4 68.0 77.0 1154 86.0 1327 95.0 1518 104.0 1728 113.0 1060 1957 SKOPE SK1300...

  • Page 17: Trouble Shooting

    Check power input watts. Possible overcharge, insufficient condenser cooling, or non- condenible gasses. Compressor motor has Replace compressor if faulty. winding open or shorted. Check continuity and resistance. Internal mechanical trouble in Replace compressor. compressor (tight). May be lubrication. SKOPE SK1300...

  • Page 18: Cabinet

    Evaporator coil iced. Defrost evaporator, check refrigeration. Restriction in refrigeration Determine location and clear system. restriction. Flush with dry nitrogen. Replace component if blockage will not clear. Dirty condenser. Clean condenser. Advise client how to regularly clean condenser. SKOPE SK1300...
  • Page 19 Overcharge of refrigerant Correct charge. capillary systems. 10. Unit noisy. Loose parts or mountings. Find and tighten. Tubing rattle. Reform to be free of contact. Bent fan blade causing Replace blade. vibration. Fan motor bearings worn. Replace motor. SKOPE SK1300...
  • Page 20 P A R T S I D E N T I F I C A T I O N CABINET ASSEMBLY - 3 inch wall Model: SK1300 SKOPE SK1300...

  • Page 21: Item Description

    Cabinet with Ducts & Shelf Support Strips C1200/291 Sign Unit Assembly (Mk.3) C1200/680 Sign Back C1200/181 Sign Sides V5000/182 SKOPE Cyclone® Refrigeration Unit * V8020/375 Top Hinge Assembly: Type ‘SB’ (R/H) C1200/388-99 Top Hinge Assembly: Type ‘SB’ (L/H) C1200/389-99 Control Panel C1200/789...
  • Page 22 P A R T S I D E N T I F I C A T I O N CABINET ASSEMBLY - 2 inch wall Model: SK1300/2 SKOPE SK1300...
  • Page 23 Cabinet with Ducts & Shelf Support Strips V1200/291 Sign Unit Assembly (Mk.4) C1200/C19 Sign Back C1200/181 Sign Sides V5000/182 SKOPE Cyclone® Refrigeration Unit * V8020/375 Top Hinge Assembly: Type ‘SB’ (R/H) V5301/388-99 Top Hinge Assembly: Type ‘SB’ (L/H) V5301/389-99 Control Panel C1200/789...
  • Page 24 P A R T S I D E N T I F I C A T I O N CABINET ASSEMBLY - Mk. 1 Side Light (SL) Model: SK1300SL SKOPE SK1300...
  • Page 25 Cabinet with Ducts & Shelf Support Strips V1200/291 Sign Unit Assembly (Mk.4) C1200/C19 Sign Back C1200/181 Sign Sides V5000/182 SKOPE Cyclone® Refrigeration Unit * V8020/375 Top Hinge Assembly: Type ‘SB’ (R/H) V5301/388-99 Top Hinge Assembly: Type ‘SB’ (L/H) V5301/389-99 Control Panel C1200/789...
  • Page 26 P A R T S I D E N T I F I C A T I O N CABINET ASSEMBLY - Mk. 2 Side Light (XL) Model: SK1300XL SKOPE SK1300...
  • Page 27 Cabinet with Ducts & Shelf Support Strips V1200/291 Sign Unit Assembly (Mk.4) C1200/C19 Sign Back C1200/181 Sign Sides V5000/182 SKOPE Cyclone® Refrigeration Unit * V8020/375 Top Hinge Assembly: Type ‘SB’ (R/H) V5301/388-99 Top Hinge Assembly: Type ‘SB’ (L/H) V5301/389-99 Control Panel C1200/789...
  • Page 28 P A R T S I D E N T I F I C A T I O N FLAT SIGN UNIT ASSEMBLY - Mk. 3 Part Number: C1200/680 SKOPE SK1300...
  • Page 29 40 Watt Ballast ELZ1251 Starter ELZ2840 Fused Connector Block ELZ6461 Fuse Holder ELZ6462 3.0 Amp Ceramic Fuse ELZ6467 Lampholder ELZ6270 Lampholder / Starter Holder ELZ6271 ‘Ensto’ Sign Supply Flex V5000/934 ‘Ensto’ Plug ELZ6458 Sign Panel Joining Strip C1300/686 SKOPE SK1300...
  • Page 30 P A R T S I D E N T I F I C A T I O N FLAT SIGN UNIT ASSEMBLY - Mk. 4 Part Number: C1200/C19 SKOPE SK1300...
  • Page 31 36 Watt Fluorescent Tube (C55/10 6000K) ELL5063 40 Watt Ballast ELZ1251 Starter ELZ2840 Fused Connector Block ELZ6461 Fuse Holder ELZ6462 3.0 Amp Ceramic Fuse ELZ6467 Lampholder ELZ6270 Lampholder / Starter Holder ELZ6271 ‘Ensto’ Sign Supply Flex C1250/934 ‘Ensto’ Plug ELZ6458 SKOPE SK1300...
  • Page 32 P A R T S I D E N T I F I C A T I O N CURVED SIGN UNIT ASSEMBLY Part Number: C1200/S21 SKOPE SK1300...
  • Page 33 36 Watt Fluorescent Tube (C55/10 6000K) ELL5063 40 Watt Ballast ELZ1251 Starter ELZ2840 Fused Connector Block ELZ6461 Fuse Holder ELZ6462 3.0 Amp Ceramic Fuse ELZ6467 Lampholder ELZ6270 Lampholder / Starter Holder ELZ6271 ‘Ensto’ Sign Supply Flex C1250/934 ‘Ensto’ Plug ELZ6458 SKOPE SK1300...
  • Page 34 P A R T S I D E N T I F I C A T I O N 4 ft PILLAR LIGHT ASSEMBLY Part Number: C1200/670 SKOPE SK1300...
  • Page 35 36 Watt Fluorescent Tube (C55/10 6000K) ELL5063 40 Watt Ballast ELZ1251 Starter ELZ2840 Fused Connector Block ELZ6461 Fuse Holder ELZ6462 3.0 Amp Ceramic Fuse ELZ6467 Lampholder ELZ6270 Lampholder / Starter Holder ELZ6271 ‘Ensto’ Sign Supply Flex C1250/934 ‘Ensto’ Plug ELZ6458 SKOPE SK1300...
  • Page 36 P A R T S I D E N T I F I C A T I O N 5 ft PILLAR LIGHT ASSEMBLY Part Number: V1200/L40 SKOPE SK1300...
  • Page 37 Lamp Holder / Starter Holder ELZ6271 58 Watt Fluorescent Tube (L58W/21 4000K) ELL6267 Starter ELZ2840 65 Watt Ballast (fitted behind control panel) ELZ8103 Fused Connector Block ELZ6461 Fuse Holder ELZ6462 3.0 Amp Ceramic Fuse ELZ6467 Centre Pillar Strip V5000/82 SKOPE SK1300...
  • Page 38 P A R T S I D E N T I F I C A T I O N SOLID CENTRE PILLAR ASSEMBLY Part Number: C1200/L43 SKOPE SK1300...
  • Page 39 Pillar Cover and Element Assembly V5060/L44 Centre Pillar Cover PLE4471BK-1560 Centre Pillar Element ELE2611 Metal Strip - sides V5000/82 Metal Strip - centre V7000/82 Rubber Inseal (1560 x 60mm) RUE5120 Fused Connector Block ELZ6461 Fuse Holder ELZ6462 3.0 Amp Ceramic Fuse ELZ6467 SKOPE SK1300...

  • Page 40: Side Light Assembly

    P A R T S I D E N T I F I C A T I O N SIDE LIGHT ASSEMBLY (SL) Part Number: V1200/L95 SKOPE SK1300...
  • Page 41 V1200/L92R-32 Side Light Cover V1200/L94 58 Watt 5ft Fluorescent Tube (L58W/21 4000K) ELL6267 Starter ELZ2840 Lamp Holder ELZ6270 Lamp Holder / Starter Holder ELZ6271 Plastic Bush PLM2775 Tube Protector End Cap PLM5155 Tube Protector PLM6268 Rubber Inseal RUE5874 SKOPE SK1300...
  • Page 42 P A R T S I D E N T I F I C A T I O N EXTRUDED SIDE LIGHT ASSEMBLY (XL) Part Number: V5060/670 SKOPE SK1300...
  • Page 43 Extruded Side Light Assembly (R/H) V5060/670R-32 Side Light Channel (L/H) V5060/671L-32 Side Light Channel (R/H) V5060/671R-32 Side Light Diffuser V5060/E71 58 Watt 5ft Fluorescent Tube (L58W/21 4000K) ELL6267 Starter ELZ2840 Lamp Holder ELZ6270 Lamp Holder / Starter Holder ELZ6271 SKOPE SK1300...

  • Page 44: Glass Door Assembly

    P A R T S I D E N T I F I C A T I O N GLASS DOOR ASSEMBLY Part Numbers: V6000/741 or V6000/D02 SKOPE SK1300...
  • Page 45 Model: Mk. 3 (Radiused door profile) Item Description Part No. Glass with Frame V6000/D02 Gasket GKT4775 Thermal Break (long) V5000/765 Thermal Break (short) V6000/766 Torsion Bar REF5014 Torsion Bar Set (items: 3, 4 & 5) REF4295 Bush PLM5075 Capstan TUR5100 Cotter Pin FAS5076 SKOPE SK1300...
  • Page 46 P A R T S I D E N T I F I C A T I O N SKOPE CYCLONE® REFRIGERATION UNIT Model: SK1500-C Part Number: V8020/375 SKOPE SK1300...
  • Page 47 P A R T S I D E N T I F I C A T I O N SKOPE CYCLONE® REFRIGERATION UNIT Model: SK1500-C Part Number: V8020/375 Item Description Part No. SKOPE Cyclone® Refrigeration Unit Assembly V8020/375 Compressor - Danfoss SC21G CPR6021 Electrics Kit (complete) ELZ4818...
  • Page 48 W I R I N G D I A G R A M S 4 ft CENTRE PILLAR LIGHT SKOPE SK1300...

  • Page 49: Wiring Diagrams

    4 ft CENTRE PILLAR LIGHT Item Part Description Mains Flex Sign Box Assembly 30Watt Fluorescent Tube 30Watt Ballast Starter 2.5Amp Fuse (2) SKOPE Cyclone® Refrigeration Unit Compressor Compressor Electrics Box Relay Run Capacitor Start Capacitor Compressor Terminal Block Control Box Thermostat...
  • Page 50 W I R I N G D I A G R A M S 5 ft CENTRE PILLAR LIGHT SKOPE SK1300...
  • Page 51 Item Part Description Mains Flex Sign Box Assembly 36Watt Fluorescent Tube 40Watt Ballast Starter 3.0Amp Fuse (2) SKOPE Cyclone® Refrigeration Unit Compressor Compressor Electrics Box Relay Run Capacitor Start Capacitor Compressor Terminal Block Control Box R.F.I. Suppression Capacitor (when fitted)

  • Page 52: Adjustable Feet

    The switch is inside 8.10) the cabinet on the centre pillar. • Fit the Fixed Kick Panel to the cabinet front base with self taping screws. • Fit Adjustable Kick Panel to the outside SKOPE SK1300...

  • Page 53: Optional Parts

    • Loosen the M4 screw to align the Adjust- able Panels suitable to the floor level. Temperature Indicators The Dial Thermometer is fitted as standard and is located inside the cabinet. Part No. V5000/95A. There are two kinds of optional temperature indicators: SKOPE SK1300...

  • Page 54: Cabinet Assembly

    O P T I O N A L P A R T S CABINET ASSEMBLY SKOPE SK1300...
  • Page 55 Solid Door Bottom Hinge (L/H) C1300/D55L Solid Door Bottom Stay V7000.044 Deep Shelf for Solid Doors R1200/161-99 Passivated Evaporator Coil CLS4801P-99 ‘Rotorua’ SKOPE Cyclone® Refrigeration Unit V8020R-102EZ Front Locking Castor SXX4539 Adjustable Castor* SXX6181 Adjustable Front Locking Castor* SXX6182 Castor Plate*...

  • Page 56: Solid Door Assembly

    O P T I O N A L P A R T S SOLID DOOR ASSEMBLY Mk. 1 & Mk. 2 Full Length Handle Mk. 3 Plastic Handle SKOPE SK1300...
  • Page 57 Solid Door Assembly (R/H) V6500/D40-32 Solid Door Assembly (L/H) V6500/D41-32 Solid Door Foamed V6500/D42 - includes handle and gasket retainers Magnetic Door Gasket GKT7883 Plastic Handle PLM7823 Hinge Mechanism - includes spring & fastenings HIN5780 Mount Bush C1300/D56 SKOPE SK1300...

  • Page 58: Adjustable Bottom Kick Panel

    O P T I O N A L P A R T S ADJUSTABLE KICK PANEL SKOPE SK1300...
  • Page 59 Note: Diagram on following page, shows Kick Panel for Adjustable Castors. Adjustable Foot Kick Panel Kit Item Description Part No. Adjustable Foot Kick Panel Kit C1200/128 Fixed Kick Panel C1200/A54 Adjustable Kick Panel C1200/A55 Fixed Side Panel V5000/A57 Adjustable Foot Side Panel V5000/A59 Side Panel Fixing Bracket V5000/A58 SKOPE SK1300...

  • Page 60: Cabinet Assembly

    Y1100/162 Adjustable Shelf Bracket (R/H) R1101/598L Adjustable Shelf Bracket (L/H) R1101/598R Cabinet Wiring Junction Box Ass’y Y1100/G29 (1) SKOPE Name Badge NAM8016-GY/SV Neon/Switch Encapsulated Label LAB0088 Swivel Castor - Mounting Plate SXX6180 (4) Adjustable Swivel Castor - Standard SXX6181 (2)
  • Page 61 Centre Pillar Light Assembly n.a. Centre Pillar Channel Assemly (R/H) n.a. Centre Pillar Channel Assemly (L/H) n.a. Light Diffuser Y1100/E71 58 Watt Fluorescent Tube (5ft): L58W/21-840 4000K ‘Coolwhite’ ELL6267 L58W/11-860 6000K ‘Daylight’ ELL9390 Starter ELZ2840 Lamp Holder ELZ6270 Starter Holder ELZ6271 SKOPE SK1300...

  • Page 62: Optional Parts

    18 Watt Fluorescent Tube ELL5065 3 Amp Ceramic Fuse ELZ6467 Fused Connector Block ELZ6461 Fuse Holder ELZ6462NC SHELVING Shelf Frame Y1101/162/1 Shelf Divider Spares available on request. Acrylic Front Spares available on request. ‘Speedfeed’ Matts Spares available on request. SKOPE SK1300...

  • Page 63: Refrigeration Unit

    Drier - Service DRY6110 Condenser Fan Blade FAN4100 Evaporator Fan Assembly YC2100/484Z Condenser Fan Motor YC1100/404B Evaporator Fan Capacitor YC2100/X27 R.F.I. Suppression Capacitor B3100/E65 Unit Wiring Diagram Label (Type 1 Controller) LAB0054 Unit Wiring Diagram Label (Type 2 Controller) LAB0056 SKOPE SK1300...
