Assa Abloy h.e.s. 5200 Series Installation Instructions

5200 Series
Electric Strike
Installation Instructions
Product Components
A
5200 Electric Strike Body
B
Trim Enhancer & Screws (#4-40 x 1/8")
C
12 & 24 Volt Plug In Connectors
Electrical Specifications
Electrical Ratings
for Solenoid Continuous Duty
Voltage 12 VDC
Resistance in Ohms 50
Amps .24
Solenoids are rated at +/– 10% indicated value.
8
* 10% max duty cycle (2 min. max on time)
For inductive kickback protection, consider using with the HES 2005M3 SMART Pac
or 2001M Plug-in Bridge Rectifier with built-in MOV (not evaluated by UL294/UL1034).
D
Minimum Wire Gauge Requirements
Voltage
200 feet or less
200–300 feet
300–400 feet
Lengths based on round trip.
C
UL1034 Performance Levels
Static Strength
Dynamic Impact
Endurance
Suitable for outdoor use.
B
UL294 Performance Levels*
Destructive Attack
Line Security
Endurance
Standby Power
*Monitor options were not evaluated to UL294/UL1034. Indoor use.
A
8
Intermittent Duty*
24 VDC 12–16 VAC 24 VAC
200 50 200
.12 .24–.32 .12
7
®
5200 Electric Strike Body
12 VDC 24 VDC
18 gauge 20 gauge
16 gauge 18 gauge
14 gauge 16 gauge
1,500 lbs
70 ft–lbs
250,000 cycles
Level I (No attack test)
Level I (No line security)
Level IV (100,000 cycles)
Level I (No secondary power source)
7
8
D
C
B
6 5
III
A
8
6 5
7 6
5200 Electric Strike Body
A
4
3
Trim Enhancer
B
7 6
C
12-Volt and 24-Volt Pigtail
Default
4
CONFIGURATION
5
2
5
LEGACY ID
1
