Assa Abloy NORTON RIXSON HM27 Installation Instructions

HM27 Floor Closer
3/4" Offset Pivoted - Handed
Installation Instructions
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65warnings.ca.gov.
13/16
3/4
3/16 R.
Bevel Edge
of Door
1/8" in 2"
Jamb
2-1/16 R.
2-1/16
1-3/16
3/4
3/4
1-1/4
Right Hand Shown
Conversion from inches
to metric: inch x 25.4
Copyright © 2002, 2009, 2022, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
2700HM Rev 3 01/22
1/8 Min. Clearance Required
Between Door and Stop
Arm
3/4
Floor Plate
9-13/16 Cement Case
9-7/8 Floor Plate
Drill (3) 3/8" Dia. Clearance Holes
in Door for Arm Mounting Screws.
4"
2-3/8
1"
3 Holes for
2-1/8 x 1/4-20 RHMS
1/2
1-1/8
1"
3/8
5-7/8
Cement
Case
6-1/8
Floor
Plate
1-1/8
4-1/16
WITH THRESHOLD
Set Cement Case Flush
with Finished Floor
1-1/8
1/2
Cement Case
WITH FLOOR PLATE
Set Cement Case 1/8" Below
Surface of Finished Floor
4-1/2
.134
1/2
1-1/8
2-1/4
13/16
For Bevel Edge Doors Only
Offset Hinge 1-1/2
Pair Per Door
3/4
3/16
1/2" Threshold
3/4
3/16
Floor
Plate
NORTON
RIXSON
3°-30' or
1/8" in 2" Bevel
1/16
1/4 1/16
1-3/4
11/16 3/4
