QNAP QSW-IM3216-8S8T Quick Installation Manual page 2

Bracket screws
SP-EAR- SP-EAR-
QSWSTANDARDRACK-01 QSWSTANDARDRACK-02
Optional:
10GbE Network Card
QXG-10G2SF-X710 (SFP+ x2)
QXG-10G2T-X710 (RJ45 x2)
QXG-10G2T (RJ45 x2)
QXG-10G1T (RJ45 x1)
Optional:
SFP+ DAC cable
CAB-DAC15M-SFPP (1.5m)
CAB-DAC30M-SFPP (3m)
CAB-DAC50M-SFPP (5m)
Optional:
Industrial NAS
TS-i410X
QSW-IM3216-8S8T
Quick Installation Guide
快速安裝手冊 빠른 설치 설명서 Guía de Instalación Rápida
Hızlı Kurulum Kılavuzu
クイックインストールガイド
คู ่ ม ื อ การติ ด ตั ้ ง แบบเร็ ว Gyors telepítési útmutató
Instrukcja szybkiej instalacji Průvodce rychlou instalací
Kurzinstallationsanleitung 快速安装指南
Guida di installazione rapida Pika-asennusopas
Краткое руководство по установке
Snabbinstallationsguide Guia de Instalação Rápida
Hurtiginstallasjonsveiledning
Hurtig installationsvejledning
Pika-asennusopas Installatiegids
Snelle Installatiegids
Foot pads Power adapter QIG
Optional:
M.2 SSD/10GbE Expansion Card
QM2-2P410G2T (2 x RJ45 + 2 x M.2)
QM2-2P410G1T (1 x RJ45 + 2 x M.2)
QM2-2P10G1TB (1 x RJ45 + 2 x M.2)
Optional:
Transceiver module
(excluding optical ber)
TRX-10GITSFPP-SR (up to 300m)
TRX-10GSFPP-LR (up to 10km)
* Make sure the ber-optic Small
Form-factor Pluggable (SFP) module
complies with CNS 15016-2 or
IEC 60852-1 certi cations and Class 1
Laser speci cations.
