  • Page 1 QSW-IM3216-8S8T User Guide Document version: 2 24/09/2024...

  • Page 2: Table Of Contents

    QSW-IM3216-8S8T User Guide Contents 1. Important Information Safety information............................3 2. Product Overview About the QSW-IM3216-8S8T........................6 Hardware specifications..........................6 Package contents............................8 Components..............................9 Front panel..............................9 Rear panel..............................10 Front panel LEDs............................11 3. Installation and Access Installation requirements..........................12 Setting up the switch............................12 Connecting the switch to a computer or network..................12...
  • Page 3 EU RoHS statement............................38 Laser compliance notice..........................38 UKCA notice..............................38...

  • Page 4: Important Information

    Please keep the original packaging and packaging materials. If you want to return the product or send it for repairs, please use the original packaging to avoid damage. QNAP reserves the right not to provide a refund or warranty service for products that are damaged due to improper packaging.
  • Page 5 QSW-IM3216-8S8T User Guide Power ⚠ WARNING To reduce the risk of fire or electric shock, ensure that you only connect the power cord to a properly grounded electrical outlet. To avoid serious injuries, a trained service technician must disconnect all PSU cords from the device before installing or replacing system components.
  • Page 6 QSW-IM3216-8S8T User Guide • Even used batteries may cause severe injury or death. • Call a local poison control center for treatment information. • For information on the type and voltage of the button battery in your device, please see the hardware specification table.

  • Page 7: Product Overview

    This chapter provides basic information about the QSW-IM3216-8S8T switch. About the QSW-IM3216-8S8T The QNAP QSW-IM3216-8S8T is a QSW managed switch designed for studio environments and AV over IP (Audio-Visual over Internet Protocol) applications. The switch offers sixteen 10 GbE ports, with eight ports utilizing RJ45 connections and the other eight ports offering SFP+ options for flexibility with fiber optic cabling.
  • Page 8 QSW-IM3216-8S8T User Guide Component QSW-IM3216-8S8T Network interfaces • 8 x 10G/5G/2.5G/1G/100M RJ45 ports • 8 x 10G/1G SFP+ ports • Relay port Management • Console ports: 1 x RJ45 port interfaces • Management ports: 1 x Marvell® 88E1512 1 GbE port...

  • Page 9: Package Contents

    QSW-IM3216-8S8T User Guide Component QSW-IM3216-8S8T Maximum power 47.463W consumption System battery 3V lithium coin cell battery, 200 mAh, 20 x 3.2 mm, Panasonic BR-2032/BN, BR2032, CCL and RoHS compliant Operating • Natural convection operating temperature: -30°C to 65°C (-22°F to temperature 149°F)

  • Page 10: Components

    QSW-IM3216-8S8T User Guide Item Quantity Rubber feet Quick Installation Guide (QIG) Components Front panel Component Component Management port 10 Gigabit Ethernet ports (SFP+) 10 Gigabit Ethernet ports (RJ45) Product Overview...

  • Page 11: Rear Panel

    QSW-IM3216-8S8T User Guide Rear panel Component Component Voltage input 3 positive terminal (VIN3 Voltage input 2 negative terminal (VIN2 Voltage input 3 negative terminal (VIN3 DC power jack (VIN1) Relay port terminal RELAYCOM Console port (Common) Relay port terminal RELAYNO (Normally...

  • Page 12: Front Panel Leds

    QSW-IM3216-8S8T User Guide Front panel LEDs Note For the 10 Gigabit SFP+ ports, the upward-facing LED arrows correspond to the ports on the top row, while the downward-facing LED arrows correspond to the ports on the bottom row. Component Component...

  • Page 13: Installation And Access

    QSW-IM3216-8S8T User Guide 3. Installation and Access This chapter provides specific hardware installation and switch access steps. Installation requirements Category Item Environment • Room temperature: • Natural convection operating temperature: -30°C to 65°C (-22°F to 149°F) • Non-natural convection operating temperature: -30°C to 45°C (-22°F to 113°F)

  • Page 14: Connecting The Switch To A Computer

    Connecting the switch to a computer Connecting the switch to a QNAP NAS allows you to expand storage capacity and back up data to another NAS through network cable connections to a host port on the switch. However, you must connect the switch to a computer to configure the settings.

  • Page 15: Connecting The Switch To A Network

    Optional: Connect the switch to the NAS. Important • The QSW-IM3216-8S8T is designed for industrial applications. Please ensure that you are using the correct type of connector for this device. • The device supports a DC input voltage range of 9-54V for voltage inputs VIN1, VIN2, and VIN3.

  • Page 16: Switch Access

    You can access the switch using any computer on the network if you know its IP address and the login credentials of a valid user account. QNAP switches support DHCP client configuration by default for IP assignment. When connected to a network, the switch automatically obtains an IP address from a DHCP server.

  • Page 17: Accessing The Switch Using Qfinder Pro

    To download Qfinder Pro, go to https://www.qnap.com/utilities. 2. Open Qfinder Pro. Qfinder Pro automatically searches for all QNAP devices on the network. 3. Locate the switch in the list, and then double-click the name or IP address. The login page appears.

  • Page 18: Basic Operations

    QSW-IM3216-8S8T User Guide 4. Basic Operations This chapter describes basic switch operations. LEDs LEDs indicate system status and related information when the switch is powered on. The following LED information applies only when the switch is connected to the network.
  • Page 19 QSW-IM3216-8S8T User Guide Status Description • The device is powered off. • The device is ready for password reset. • The device is ready for factory reset. Power Supply 1 (VIN1) LED Status Description Green The power supply from Voltage Input 1 (VIN1) is operating normally.
  • Page 20 QSW-IM3216-8S8T User Guide Locator LED Status Description Flashes amber The device is being located. Note The locator LED flashes for 30 minutes when the locator function is enabled. The locator function is disabled. Management RJ45 Speed LED Status Description Green The network connection is operating at 1 Gbps.

  • Page 21: Reset Button

    QSW-IM3216-8S8T User Guide Status Description Amber The network connection is operating at 100 Mbps, 1 Gbps, 2.5 Gbps, or 5 Gbps. Flashes The device is being accessed from a 100 Mbps, 1 Gbps, 2.5 Gbps, or 5 Gbps amber network.

  • Page 22: Relay Port

    QSW-IM3216-8S8T User Guide Operation User Action Result Advanced system Press and hold the button The default factory settings are restored. reset for 10 seconds. Relay port The relay port on the QSW managed switch provides an interface to control external electrical devices, such as alarms or bells, using a relay switch mechanism.
  • Page 23 QSW-IM3216-8S8T User Guide 3. Connect the negative terminal of the external power supply to the fire alarm. Basic Operations...

  • Page 24: Support And Other Resources

    QSW-IM3216-8S8T User Guide 5. Support and other resources QNAP provides the following resources: Resource Documentation https://download.qnap.com Service Portal https://service.qnap.com Downloads https://download.qnap.com Community Forum https://forum.qnap.com Support and other resources...

  • Page 25: Glossary Qfinder Pro

    QSW-IM3216-8S8T User Guide 6. Glossary Qfinder Pro QNAP utility that lets you locate and access QNAP devices in your local area network QNAP switch management operating system Glossary...

  • Page 26: Notices

    "QNAP"). No license, express or implied, by estoppels or otherwise, to any intellectual property rights is granted by this document. Except as provided in QNAP's terms and conditions of sale for such products, QNAP assumes no liability whatsoever, and QNAP disclaims any express or implied...

  • Page 27: Gnu General Public License

    QSW-IM3216-8S8T User Guide The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. Other company names and products mentioned herein are trademarks or registered trademarks of their respective holders.
  • Page 28 QSW-IM3216-8S8T User Guide Some devices are designed to deny users access to install or run modified versions of the software inside them, although the manufacturer can do so. This is fundamentally incompatible with the aim of protecting users' freedom to change the software. The systematic pattern of such abuse occurs in the area of products for individuals to use, which is precisely where it is most unacceptable.
  • Page 29 QSW-IM3216-8S8T User Guide part of that Major Component, and (b) serves only to enable use of the work with that Major Component, or to implement a Standard Interface for which an implementation is available to the public in source code form. A “Major Component”, in this context, means a major essential...
  • Page 30 QSW-IM3216-8S8T User Guide added in accord with section 7 apply to the code; keep intact all notices of the absence of any warranty; and give all recipients a copy of this License along with the Program. You may charge any price or no price for each copy that you convey, and you may offer support or warranty protection for a fee.
  • Page 31 QSW-IM3216-8S8T User Guide c. Convey individual copies of the object code with a copy of the written offer to provide the Corresponding Source. This alternative is allowed only occasionally and noncommercially, and only if you received the object code with such an offer, in accord with subsection 6b.
  • Page 32 QSW-IM3216-8S8T User Guide Corresponding Source conveyed, and Installation Information provided, in accord with this section must be in a format that is publicly documented (and with an implementation available to the public in source code form), and must require no special password or key for unpacking, reading or copying.
  • Page 33 QSW-IM3216-8S8T User Guide 9. Termination. You may not propagate or modify a covered work except as expressly provided under this License. Any attempt otherwise to propagate or modify it is void, and will automatically terminate your rights under this License (including any patent licenses granted under the third paragraph of section 11).
  • Page 34 QSW-IM3216-8S8T User Guide contributor version. For purposes of this definition, “control” includes the right to grant patent sublicenses in a manner consistent with the requirements of this License. Each contributor grants you a non-exclusive, worldwide, royalty-free patent license under the contributor's essential patent claims, to make, use, sell, offer for sale, import and otherwise run, modify and propagate the contents of its contributor version.
  • Page 35 QSW-IM3216-8S8T User Guide into a single combined work, and to convey the resulting work. The terms of this License will continue to apply to the part which is the covered work, but the special requirements of the GNU Affero General Public License, section 13, concerning interaction through a network will apply to the combination as such.

  • Page 36: Ce Notice

    Important Any modifications made to this device that are not approved by QNAP Systems, Inc. may void the authority granted to the user by the FCC to operate this equipment. Notices...

  • Page 37: Vcci Notice

    QSW-IM3216-8S8T User Guide VCCI notice この装置は、クラス A 情報技術装置です。この装置を家庭環境で使用する と電波妨害を引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう要求される ことがあります。 VCCI–A BSMI notice 警告：為避免電磁干擾，本產品不應安裝或使用於住宅環境。 SJ/T 11364-2006 本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的年限。本产 品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 Notices...

  • Page 38: Eu Directive 2002/96/Ec On Waste Electronic And Electrical Equipment (Weee)

    According to the requirement of the WEEE legislation the following user information is provided to customers for all branded QNAP Electronics products subject to the WEEE directive. This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste.

  • Page 39: Laser Compliance Notice

    QSW-IM3216-8S8T User Guide EU RoHS statement This equipment complies with the European Union RoHS Directive 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment. The directive applies to the use of lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl ethers (PBDE) in electrical and electronic equipment.
