Medela Symphony Manual

Symphony Breastpump Kit Parts
®
1a
1b
3
2
4
5
6
Item
1a. PersonalFit Breastshield, Standard (24mm) ...................87073
™
1b. PersonalFit Breastshield Connector .................................87071
2. Valve and White Membrane .........................................8000001
3. Valve .............................................................................8100475
4. Membrane .....................................................................8207013
5. Collection Connector ....................................................8117009
6. Solid Container Lid ......................................................8107183
7. Tubing ...........................................................................8007213
8. Membrane Cap .............................................................8100667
9. Protective Membrane ...................................................8200094
7
8
9
Order Number
www.medela.com
Medela, Inc., P.O. Box 660, 1101 Corporate Drive,
McHenry, IL 60051-0660
Phone: (800) 435-8316 or (815) 363-1166
Fax: (815) 363-1246
Email: customer.service@medela.com
Medela and Symphony are registered trademarks
and PersonalFit, Quick Clean, Micro-Steam and
#1 Choice of Hospitals & Mothers are trademarks
of Medela, Inc.
1908095 C 0210 © 2010 Medela, Inc.
Printed in the U.S.A.
Cleaning and Sterilization
Follow these directions unless instructed otherwise by
your healthcare provider.
IMPORTANT
This product's kit is a single-user item unless
properly sterilized between users. Use by more than
one user without adequate sterilization may pose
a health risk and voids the warranty.
Hygiene
Wash hands before touching
breasts or containers, and avoid
touching the inside of containers
or lids.
First Use
Before first use, disassemble all kit parts and
sanitize by boiling for 10 minutes.
*67099S - has been sterilized and does not require
cleaning before first use.
After First Use
Follow these cleaning instructions unless you are
told otherwise by your healthcare professional. Prior
to cleaning, take apart all parts of your breastpump
accessory kit. Be especially sure to remove the valve
from the breastshield and separate the membrane from
the valve prior to cleaning.
To Sterilize in the Hospital:
All disassembled parts can be autoclaved to a
maximum of 272° F for 3 minutes at 29 PSIG or 250° F
for 15-20 minutes at 15 PSIG.
To avoid damage during and immediately after
sterilization:
Sterilize parts without applying external pressure to
n
them.
Symphony Double Pumping Kit Instructions
®
1 2
Make sure breast- Snap white
shield and connector are membrane onto yellow
securely attached. valve.
6 7
Insert the yellow Insert pale yellow
end of tubing into port on end of tubing into opening
membrane cap. in connector.
11 Switch the pump on 12 Center breastshield
to begin Stimulation/ over your nipple and
let-down phase by start pumping.
pressing the power button.
Allow parts to cool before applying external pressure.
n
If gas sterilization is used, residual testing is
recommended to determine the proper length
of aeration.
To Sanitize at Home:
Disassemble all parts that come in contact with breast
and milk.
After each use:
Disassemble and wash all parts that come in contact
n
with the breast and milk in warm soapy water.
Rinse in clear water.
n
Air-dry on clean towel and cover parts when not in
n
use.
All parts may also be washed in top rack of dishwasher.
For Quicker Cleaning:
Medela offers Quick Clean Micro-Steam
™
daily kit disinfection.
Tubing Care
Inspect tubing after each pumping session for
condensation and/or milk.
If condensation appears in tubing:
To eliminate condensation after you have completed
pumping, continue running the pump with the tubing
attached for another 1-2 minutes or until dry.
If milk appears in tubing:
1. Turn off the pump and unplug from power source.
2. Remove and disassemble the tubing, pump
connector, piston, cylinder, membranes and membrane
caps (parts vary by pump used). Wash in soapy water,
then rinse in clear cold water.
3. Shake water droplets out of tubing and hang to air-
dry. For faster drying, attach tubing to pump and run
pump 1-2 minutes or until dry, or pour a small amount
of isopropyl alcohol through the tubing to dry.
3 4
Screw collection
Push yellow valve
into place on breastshield container onto
connector. breastshield.
8 9
To unlock lid, press Push membrane/
cap into place on pumping
the oval release button
mechanism. A "click" will
on top of the Symphony
®
be heard once properly
Breastpump. Keeping
seated. To ensure proper
button depressed, lift up
fit, be sure to center the
on the handle to open
membrane caps' tube
case and access pumping
ports directly over the
mechanisms.
crevice on the pump
housing.
13 If your let-down
occurs before the
Expression phase begins,
you may pump more
efficiently by pressing
the button to begin the
Expression phase.
Bags for
™
5
Assemble protective
membrane and membrane
cap.
10
Close lid securely
before pumping. If lid
does not close properly
membrane caps may not
be completely seated or
may require adjustment.
