SMC Networks 6709L2 - annexe 1 Installation Manual page 61

O
RDERING
TigerAccess EE Switch Products and Accessories
Product Number
SMC6709L2
SMC6709L2GSSC
SMC6709L2GLSC
SMC-EZ108FMSC
SMC-EZ108FMMT
SMC-EZ108FMST
SMC-EZ108FSSC
SMC-EZ108FSMT
A
I
NFORMATION
Description
8-port 10/100 Mbps Managed Switch with 2 media
expansion slots and one 10/100/1000 Mbps port
Gigabit multimode module with one 1000BASE-SX
port (SC connector)
Gigabit single-mode module with one
1000BASE-LX port (SC connector)
Fast Ethernet multimode module with one
100BASE-FX port (SC connector)
Fast Ethernet multimode module with one
100BASE-FX port (MTRJ connector)
Fast Ethernet multimode module with one
100BASE-FX port (ST connector)
Fast Ethernet single-mode module with one
100BASE-FX port (SC connector)
Fast Ethernet single-mode module with one
100BASE-FX port (MTRJ connector)
PPENDIX
D
D-1
