LED
PWR
BC STM
CPU

Optional Media Extender Modules

Caution:

Optional 1000BASE-SX Module - SMC6709L2GSSC

Figure 1-2. Single-Port 1000BASE-SX Multimode Module
Using multimode fiber optic cable, the 1000BASE-SX port can be
connected to a remote site up to 550 m (1805 ft) away. The 1000BASE-SX
Gigabit module operates at 1 Gbps, with support for full-duplex mode and
flow control. This module is fitted with an SC connector, but you can
attach an ST plug to the switch using the SC-ST Converter (Part Number:
99-012034-091).
Condition
On
Flashing
Off
On
Flashing
The media expansion modules are not hot-swappable. Be sure
you power off the switch before installing any of these modules.
1000BASE-SX Multimode Module
SMC6709L2GSSC
System Status LEDs
Switch is receiving power.
Switch has detected a network broadcast storm.
Switch detects normal network activity.
System is in normal operation mode.
System is running its power-on self-test.
TX RX
D
ESCRIPTION OF
Status
H
ARDWARE
1-5
