1000BASE-T Pin Assignments
1000BASE-T ports switch support automatic MDI/MDI-X operation, so
you can use straight-through cables for all network connections to PCs or
servers, or to other switches or hubs.
The table below shows the 1000BASE-T MDI and MDI-X port pinouts.
These ports require that all four pairs of wires be connected. Note that for
1000BASE-T operation, all four pairs of wires are used for both transmit
and receive.
Use 100-ohm Category 5, 5e or 6 unshielded twisted-pair (UTP) or
shielded twisted-pair (STP) cable for 1000BASE-T connections. Also be
sure that the length of any twisted-pair connection does not exceed 100
meters (328 ft).
Pin MDI Signal Name
1 Transmit Data plus (TD1+)
2 Receive Data minus (RD1-)
3 Transmit Data plus (TD2+)
4 Transmit Data plus (TD3+)
5 Receive Data minus (RD3-)
6 Receive Data minus (RD2-)
7 Transmit Data plus (TD4+)
8 Receive Data minus (RD4-)
B-4
MDI-X Signal Name
Transmit Data plus (TD2 +)
Receive Data minus (RD2-)
Transmit Data plus (TD1+)
Transmit Data plus (TD4+)
Receive Data minus (RD4-)
Receive Data minus (RD1-)
Transmit Data plus (TD3+)
Receive Data minus (RD3-)
