If the fuse blows, unplug the product from the outlet. Replace the fuse as per the user servicing instructions (follow
product marking for proper fuse rating) and check the product. If the replacement fuse blows, a short-circuit may
be present and the product should be discarded or returned to an authorized service facility for examination and
/or repair.
Warning:
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this
plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully into the electric receptacle,
reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to subvert this safety feature.
To Change the fuse
The following should ONLY be conducted by a qualified professional:
1. Grasp plug and remove from the electrical receptacle. Do not unplug by pulling on the cord.
2. Open the fuse cover by sliding the fuse access cover on the top of the plug toward the blades as shown in
the diagram below.
3. Remove fuse carefully. Push the fuse from the other side or turn fuse holder upside down to remove fuse.
4. Risk of fire. Replace the fuse only with 5 Amp, 125 Volt fuse.
5. Close fuse cover by sliding the fuse access cover on the top of the plug away from the blades.
6. Risk of fire. Do not replace the polarized plug as it contains a safety device that should not be removed.
Discard product if the polarized plug is damaged.
SAVE THESE INSTRUCTION
Structure and parts
1. Front grill
2. Blade fasten nut
3. Blade
4. Grill fasten nut
5. Back grill
6. Dam-board
7. Motor cover
8. Back control box
9. Control panel
10. Bolt
11. Power cable
12. top tube
13. Bolt
14. Bottom tube
15. Base
16. Gasket
17. L shape screw
