- Page 1 User Manual Aurora AC Chargepoints...
- Page 3 In case of any doubt regarding a subject described or if you discover an error in this manual, please contact us at: Wanbang Digital Energy Co., Ltd. Address: No.39 Longhui Road, Wujin High-tech Industrial Development Zone, Changzhou, China Customer service: 400-800-2610 E-mail: service.global@starcharge.com Website: www.starcharge.com Wanbang Digital Energy Co., Ltd. reserves all rights. Aurora Charging Infrastructure...
-
Page 4: Table Of Contents
CONTENTS Contents 1 Copyright and Disclaimer 1.1 Disclaimer ......... . 1.2 Copyright . -
Page 5: Copyright And Disclaimer
Content of this document is compiled for information purposes only. • Although StarCharge has put its best efforts to keep the document as precise and up-to-date, StarCharge shall not assume any liability for defects and damage which may result from the use of information contained herein. - Page 6 1 COPYRIGHT AND DISCLAIMER Attention Extensive safety information is available in the relevant sections of this document. The safety instructions are intended to ensure proper practical usage. If the user does not comply with these safety regulations and instructions, the user may expose herself/himself to the risk of electric shock, fire and/or severe injuries.
-
Page 7: Safety And Usage Instructions
Vehicle Supply Equipment / EVSE or the Charger), the instructions in this manual must always be complied with. Installation, Commissioning, and Maintenance of this equip- ment shall only be performed by a qualified electrician (Starcharge certified partner ). Make sure the power cord connected to the charger is routed from the dedicated Type A RCBO or MCB+ Type A RCD in the distribution box.The Type A RCBO or MCB+ Type A... -
Page 8: Summary Of Safety Symbols On The Equipment
2 SAFETY AND USAGE INSTRUCTIONS 2.3 Summary of safety symbols on the equipment Symbols Meaning “Electric hazard”, which indicates danger. Failure to pay attention to the procedures, practices or improper implementation may cause injuries or death. Only after the conditions referred to are fully understood and fulfilled, can the operation accompanied by the "Electric hazard"... -
Page 9: Technical Parameters
3 TECHNICAL PARAMETERS 3 Technical Parameters • Suitable for all vehicles complying with IEC 62196-2. • Configurable output power setting. • The charging station has the following protection features: – Lightning protection – Overload protection – Short circuit protection – Leakage protection –... -
Page 10: Product Model
3 TECHNICAL PARAMETERS 3.1 Product Model Power Model No. Connector Remarks DH-AC0070XG70-Q CASE C DH-AC0070XG71-Q CASE B DH-AC0070XG70-R CASE C DH-AC0070XG71-R CASE B DH-AC0070XG71-S CASE B Emergency stop button(optional) DH-AC0070XG71-T CASE B French T2S socket (optional) DH-AC0070XG70-S CASE C MID meter(optional) DH-AC0070XG71-U CASE B DH-AC0070XG70-T... -
Page 11: Input Parameters
3 TECHNICAL PARAMETERS 3.2 Input Parameters Input Power 11kW 22kW Rating 6mm2 2.5mm2 6mm2 Cable Size 230Vac (±10%) 400Vac (±10%) 400Vac (±10%) Input Voltage 50/60Hz Frequency 1-phase 3-phase 3-phase Input Current (32 A max.) (16 A max./ phase) (32 A max./ phase ) Rating Pin terminal: Pin terminal:... -
Page 12: Output Parameters
3 TECHNICAL PARAMETERS 3.3 Output Parameters Output Power Rating 11kW 22kW 1 x type 2 socket, compliant with IEC62196-2 1 x type 2 socket with shutter compliant with Vehicle connection IEC62196-2 (French T2S) 1 x type 2 plug, compliant with IEC62196-2 230Vac (±10%) 400Vac (±10%) 400Vac (±10%) -
Page 13: Protection Parameters
3 TECHNICAL PARAMETERS 3.4 Protection Parameters AC 30mA + DC 6mA leakage current detection Residual current (compliance in accordance to IEC62955: 2018) protection Power switching Integrated in hardware circuit, simultaneous activation relay Integrated in firmware; Circuits shutdown at: Overcurrent 110% of output current rating after 5 seconds protection 125% of output current rating immediately Non 15118 version:... -
Page 14: User Interface & Communication
3 TECHNICAL PARAMETERS 3.5 User Interface & Communication Multicolor LED Ring Status Indicator Communication OCPP 1.6 (JSON) protocol (EVSE & Backend) Network Interface 4G / Ethernet / Wi-Fi / Bluetooth Standard Bluetooth 5.0 Bluetooth Frequency range 2402~2480MHz (Reserved) Output power +10dBm IEC14443A, IEC14443B, 15693, 18092 Card Type: Jewel, Mifare UL, NTAG203, Mifare UL C,... -
Page 15: Operating Environment And Mechanical Aspects
3 TECHNICAL PARAMETERS 3.6 Operating environment and Mechanical aspects -30℃ to +50℃ (Natural Cooling) Operating temperature -40℃ to +85℃ Storage temperature 5% to 95% (no condensation) Relative humidity 2000m Altitude ≤ Electrical safety class IP55 (Case C) / IP54 (Case B) Ingress Protection IK10 IK Rating... -
Page 16: Product Overview
Weight (without packaging) Case C: Approx. 6.5±0.5kg Case B: Approx. 7±0.5kg; Packaging (with accessories) Case C: Approx. 8.5±0.5kg RFID card Starcharge card x 2 Cable Length Charging cables: 5m Installation Wall mounting / Pole mounting (Optional) Ver 1.02 Wanbang Digital Energy Co.Ltd... -
Page 17: Appearance Overview
4 PRODUCT OVERVIEW 4.2 Appearance Overview 4.2.1 Case B type(T2S Version) A. RFID card reader B. Emergency stop button (Optional) C. LED status indicator Wall mounting D. Charging connector socket E. QR code for authentication F. Hinge(Optional) A. RFID card reader B. -
Page 18: Case B Type(T2 Version)
4 PRODUCT OVERVIEW 4.2.2 Case B type(T2 Version) A. RFID card reader B. Emergency stop button(Optional) C. LED status indicator Wall mounting D. Charging connector socket E. QR code for authentication F. Hinge(Optional) A. RFID card reader B. Emergency stop button(Optional) C. -
Page 19: Case C Type
4 PRODUCT OVERVIEW 4.2.3 Case C type A. Cable winding trough B. Emergency stop button(Optional) C. Charging connector unlock button D. RFID card reader Wall mounting E. LED status indicator F. Charging connector G. QR code for authentication H. Hinge(Optional) A. -
Page 20: Storage Of Charging Cable And Connector
4 PRODUCT OVERVIEW 4.3 Storage of charging cable and connector When the charging station is not used, the charging cable should be rolled up and put back into the cable winding trough in position [A] in Figure 1(a) or placed on the cable bracket [I] of the pole as indicated in Figure 1(b), and the charging connector should be inserted into the designated position [F] for safe storage. -
Page 21: Instructions For Charging
5 INSTRUCTIONS FOR CHARGING 5 Instructions for Charging Operation is divided into two parts: • Charging connection from EVSE to EV. • Starting and Ending the charging process. The user shall first connect the charging equipment to the vehicle and then the LED light will turn from green in standby to blue after the connection is completed. - Page 22 5 INSTRUCTIONS FOR CHARGING End charging N.B. Do not pull a mechanically-locked connector out of the socket plugged into the vehicle with any force. (1) To initiate or stop the charging process, simply place the RFID card in front of the reader.
-
Page 23: Led Status Indicators
5 INSTRUCTIONS FOR CHARGING 5.2 LED Status Indicators Aurora Series are equipped with a color LED to visualize the working status of the charging station. Lighting effects Meanings Subsequent operation Orange indicator Charger will enter chargeable Charger is starting up. is always on. -
Page 24: Troubleshooting
6 TROUBLESHOOTING 6 Troubleshooting The charging station’s potential failures and solutions are detailed in the table below. If a problem persists, please contact your local service partner or refer to the Customer Service section of the product manufacturer for further assistance. Failures Possible causes and troubleshooting methods No power supply... -
Page 25: Routine Maintenance
7 ROUTINE MAINTENANCE 7 Routine Maintenance The recommended maintenance cycle is outlined in the following table. It is impor- tant to ensure compliance with the standards and regulations of the country where the charging equipment is installed and operated, as this cycle may be subject to change. Check Item Cycle Handling... -
Page 26: Warranty
8 WARRANTY 8 Warranty 8.1 Warranty Clause (1) General information • Welcome to Wanbang Digital Energy Co., Ltd., where you can purchase our prod- ucts. • If you require anything beyond our standard warranty, please contact us at 400- 828-0768 to learn more about our available warranty upgrades and extension services. -
Page 27: Warranty Service Exemption Clause
• Please refer to the user manual for the maintenance of charging station. 8.2 Warranty service exemption clause Starcharge shall not be liable in any way for damage. All warranties on both the product and accessories shall become void under the following circumstances: •... -
Page 28: Information Registration
8 WARRANTY • The premature aging and failure of the operating components related to the mainte- nance actions caused by the maintenance of the charging station not in accordance with the maintenance requirements and cycles will be exempt from the warranty responsibility. -
Page 29: Appendix-Rfid Cards
9 APPENDIX-RFID CARDS 9 Appendix-RFID cards Frequency of Byte Size Card Type Description Operation Range IEC 14443 is an international standard for proximity cards and readers used in access control and identification systems. It specifies the radio IEC14443 frequency, modulation, coding, and 13.56 MHz 1K - 4K security features for communication... - Page 30 9 APPENDIX-RFID CARDS Frequency of Byte Size Card Type Description Operation Range MIFARE Ultralight C and MIFARE Ultralight EV1 (V) are contactless smart cards based on ISO/IEC 14443 A standard. Developed by NXP Semiconductors, they offer AES-128 bit encryption for better security. MIFARE Ultralight C has a 1Kbyte Mifare memory capacity with a 7-byte...
- Page 31 9 APPENDIX-RFID CARDS Frequency of Byte Size Card Type Description Operation Range MIFARE Plus 2K/4K S/X are contactless smart cards developed by NXP Semiconductors based on ISO/IEC 14443 A standard. They provide enhanced security with AES-128 bit encryption and a proprietary security protocol Mifare called "Crypto-1".
- Page 32 9 APPENDIX-RFID CARDS Frequency of Byte Size Card Type Description Operation Range Innovision Jewel is a contactless smart card technology developed by UK-based company Innovision Research and Technology Limited, specializing in RFID technologies. The Jewel is a small, low-cost, and low-power RFID transponder operating at 13.56 MHz and compliant with the ISO/IEC 14443A standard.
- Page 33 9 APPENDIX-RFID CARDS Frequency of Byte Size Card Type Description Operation Range FeliCa is a contactless RFID smart card technology developed by Sony Corporation primarily used in Japan and other parts of Asia for various applications such as electronic money, transportation, and access control systems.
- Page 34 9 APPENDIX-RFID CARDS Frequency of Byte Size Card Type Description Operation Range The FeliCa RC series is a contactless smart card line developed by Sony Corporation for various applications including electronic money, transportation, and access control Felica systems. The cards feature high-security 13.56 MHz RC880/RC measures such as mutual authentication and...
- Page 35 9 APPENDIX-RFID CARDS For the newest version of the document, please feel free to check www.starcharge.com Many thanks for your attention Ver 1.02 Wanbang Digital Energy Co.Ltd...
-
Page 36: Customer Service
Contact Company: Wanbang Digital Energy Co., Ltd. Address: No.39 Longhui Road, Wujin High-tech Industrial Development Zone, Changzhou, China Customer service: 400-800-2610 E-mail: service.global@starcharge.com Website: www.starcharge.com Installation Manual Installation Manual Wanbang Digital Energy Co.Ltd. Wanbang Digital Energy Co.Ltd.
