- Page 1 User Manual Artemis 7/11kW Charging System...
- Page 2 Legal Notice This document is an integral part of the “Charging Infrastructure" technical documentation and is protected by copyright. Without written consent, any use outside the strict limits of copyright law is prohibited. This also applies to files that are duplicated, translated, and photographed, and files that are stored and processed using electronic media.
- Page 3 Contents Contents 1 Introduction .......................................2 1.1 Function of this document ............................. 3 1.2 Target user.................................... 3 1.3 Version and revision history............................3 1.4 Disclaimer ....................................4 1.5 Copyright ....................................4 1.6 Supplier....................................5 1.6.1 Europe..................................5 1.6.2 APAC....................................5 1.6.3 Americas..................................5 2 Safety ........................................6 2.1 General safety..................................
- Page 4 Abbreviations Abbreviations Direct Current Electric Vehicle Electric Vehicle Supply Equipment Light Emitting Diode EVSE Radio Frequency Identification RFID V 1.0.2 Star Charge...
- Page 5 1 Introduction 1 Introduction 1.1 Function of this document Star charge equipment is intended exclusively for charging Electric Vehicles (EV) in both indoor and outdoor areas. To ensure proper usage of the charging station (hereinafter can be referred to as Electric Vehicle Supply Equipment/EVSE or the Charger), the instructions in this manual must always be complied with.
- Page 6 1 Introduction 1.4 Disclaimer This document has been subject to rigorous technical review before being published. It will subsequently be revised at regular intervals. ● The information in this manual is for informational purposes only. This manual, related manuals, and warnings do not replace your responsibility to use common ●...
- Page 7 1.6.2 APAC Star charge Energy Pte., Ltd. 1 Harbourfront Pl, 04-09; Singapore 098633 Customer servicehotline: +60 15 4600 0603 Global customer service E-mail: service.global@starcharge.com Homepage: www.starcharge.com 1.6.3 Americas Star Charge Americas Corp. 46571 Fremont Blvd, Fremont, California 94538...
- Page 8 2 Safety 2 Safety 2.1 General safety Before charging your EV, please read the safety rules and usage instructions in this chapter as failure to do so may result in safety hazards or device failure. During the installation and connection of the Charger, it is imperative to comply with the legal acts or regulations set forth by the respective country.
- Page 9 2 Safety 2.2 Safety symbols Electric hazard: This symbol indicates that there is a danger of electric shock. Symbols Meanings Failure to pay attention to the procedures, practices or improper implementation may cause injuries or death. Only perform operations with this symbol if you fully understand and meet all of the requirements.
- Page 10 2 Safety 2.3 Fire safety guidelines for construction sites Do not store flammable and explosive materials on the construction site. ● Flammable and explosive materials: Set up proper storage areas for these materials to prevent accidents. ○ Fire extinguishers: The construction site must have at least two fire extinguishers, such as carbon ○...
- Page 11 2 Safety If you cannot control the fire, report it to the government department in time for support. Cooperate with the fire brigade for rescue efforts. ○ Collect information about what happened before the fire, what the monitoring system showed, and what witnesses saw.
- Page 12 3 Product overview 3 Product overview 3.1 Nameplate Artemis 7kW Artemis 11kW Figure 3-1 Nameplates V 1.0.2 Star Charge...
- Page 13 3 Product overview 3.2 External view 3.2.1 Wall-mounted EVSE 280mm Cable winding groove RFID reader Emergency button (optional) QR code LED status indicator Charging connector unlocking button Charging connector holder V 1.0.2 Star Charge...
- Page 14 3 Product overview 280mm 3.2.2 Pole-mounted EVSE RFID reader Emergency button (optional) QR code LED status indicator Charging connector unlocking button Charging connector holder Mounting pole V 1.0.2 Star Charge...
- Page 15 3 Product overview 3.3 Charging connector type Star Charge can deliver EVSE with Type 2 connectors on the charging cables. (11kW only) (11kW only) The length of the charging cable outside of this EVSE is 5 m. 3.4 Status of the LED indicator Lighting effect Meaning Steady white...
- Page 16 3 Product overview 3.5 Emergency button (optional) In the event of an emergency, the user should press the emergency button immediately to cut off power output. Upon activation, the LED indicator will turn red. Please note that the EVSE cannot be remotely reset if the emergency button is pressed, contact our customer service center to solve any problem.
- Page 17 4 Using instructions 4 Using instructions 4.1 Prerequisites Before starting, make sure you have the following ready: Make sure you know all the safety and usage instructions in Chapter 2. ● Make sure the Artemis EVSE is working properly. ● Make sure your EV is in good condition and can be charged.
- Page 18 4 Using instructions 4.2.1 Charging with RFID card ● Start charging ② ① ③ ④ (1) Pull out the charging connector from the EVSE. (2) Connect the charging connector to the EV. The charging connector is correctly connected once the LED indicator on the EVSE is blue solid on.
- Page 19 4 Using instructions 4.2.2 Charging with QR code ● Start charging ① ② ③ ④ (1) Pull out the charging connector from the EVSE. (5) Connect the charging connector to the EV. The charging connector is correctly connected once the LED indicator on the EVSE is blue solid on.
- Page 20 4 Using instructions 4.2.3 Free charging ● Start charging ② ① ③ (1) Pull out the charging connector from the EVSE. (2) Connect the charging connector to the EV. The charging connector is correctly connected once the LED indicator on the EVSE is blue solid on. (3) The EVSE will start charging process when the blue is breathing.
- Page 21 Customer service Preparation: If you have any questions or problems, please contact the company responsible for performing the electrical installation.
