Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose during shipment. Identify and count all items and compare with the parts list shown
below. It is recommended to have two people during assembling and to remove the back and base of the
furniture out from the box.
Please follow the drawings below to assemble the item
ITEM
A
SEAT
BACKREST
B
C
LEFT SIDE FACING (LSF) ARM
D
RIGHT SIDE FACING (RSF) ARM
WEIGHT CAPACITY (PER SEAT)
HARDWARE DIMENSIONS
VERIFICATION TOOL
ASSEMBLY INSTRUCTION
U1816-13 WILLOW GLIDER RECLINER
PARTS LIST
DESCRIPTION
inches
1
2
SKETCH
350 LBS
3
MADE IN MALAYSIA
QTY
1 PC
1 PC
1 PC
1 PC
4
PAGE 1 OF 3
Advertisement
Related Manuals for New Classic Furniture WILLOW U1816-13
Summary of Contents for New Classic Furniture WILLOW U1816-13
- Page 1 ASSEMBLY INSTRUCTION U1816-13 WILLOW GLIDER RECLINER Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 2 STEP 1: Cut the ties on the frame at the bottom of the STEP 2: Locate the metal bracket at the back of seat (A). seat with scissors STEP 3: Install the backrest (B) by align and insert the STEP 4: Install the arms by sliding the metal bracket on the metal bracket on the backrest (B) to the metal LSF arm (C) and RSF arm (D) into the metal bracket of the seat (A).
- Page 3 STEP 5: Press the Velcro strip on the backrest (B) to the STEP 6: Open the footrest by pulling the handle Velcro strip on the bottom of seat (A). Velcro STEP 7: Complete ASSEMBLY COMPLETED MADE IN MALAYSIA PAGE 3 OF 3...
