Thank you for purchasing this quality product. Be sure to check all packing materials
carefully for small parts, which may have come loose during shipment. Identify and count
all items and compare with the parts list shown below. It is recommended to have two
people during assembling and to remove the back and base of the furniture out from the box.
Please follow the drawings below to assemble the item
NO.
A
Seat
B
Backrest
C
Left Side Facing (LSF) Wing
D
Right Side Facing (RSF) Wing
ASSEMBLY INSTRUCTIONS
DESCRIPTION : ENZO GLIDER RECLINER
Parts List
DESCRIPTION
All images shown are for illustration purpose only.
Actual product may vary due to product enhancement.
Page 1 of 2
ENZO COLLECTION
ITEM#: U2506-13
SKETCH
Q'TY
1 PC
1 PC
1 PC
1 PC
Advertisement
Related Manuals for New Classic Furniture ENZO COLLECTION U2506-13
Summary of Contents for New Classic Furniture ENZO COLLECTION U2506-13
- Page 1 ASSEMBLY INSTRUCTIONS ENZO COLLECTION ITEM#: U2506-13 DESCRIPTION : ENZO GLIDER RECLINER Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below. It is recommended to have two people during assembling and to remove the back and base of the furniture out from the box.
- Page 2 ASSEMBLY INSTRUCTIONS ENZO COLLECTION ITEM#: U2506-13 DESCRIPTION : ENZO GLIDER RECLINER Step 1: Step 2: Attach Backrest (B) to the Seat (A). Attach the LSF wing (C) and RSF wing (D) to the Backrest (B). Step 3: Open the footrest by pulling the handle. ON-PULL All images shown are for illustration purpose only.
-
Page 3: Parts List
ASSEMBLY INSTRUCTIONS ENZO COLLECTION ITEM#: U2506-25 DESCRIPTION : ENZO CONSOLE LOVESEAT W/ DUAL RECLINERS Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below. - Page 4 ASSEMBLY INSTRUCTIONS ENZO COLLECTION ITEM#: U2506-25 DESCRIPTION : ENZO CONSOLE LOVESEAT W/ DUAL RECLINERS Step 1: Step 2: Take the Console Backrest (C) out of the Console Attach the LSF Wing (E) to LSF Backrest (B) Base part of the Seat (A). Attach the LSF/Console/ and RSF Wing (F) to RSF Backrest (D).
- Page 5 ASSEMBLY INSTRUCTIONS ENZO COLLECTION ITEM#: U2506-30 DESCRIPTION : ENZO SOFA W/DUAL RECLINER Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose during shipment. Identify and count all items and compare with the parts list shown below.
- Page 6 ASSEMBLY INSTRUCTIONS ENZO COLLECTION ITEM#: U2506-30 DESCRIPTION : ENZO SOFA W/DUAL RECLINER Step 1: Step 2: Attach the LSF/Middle/RSF backrests Attach the LSF Wing (E) to LSF Backrest (B) (B/C/D) to the Seat (A). and RSF Wing (F) to RSF Backrest (D). Step 3: Open the footrest by pulling the handle ON-PULL...
