FS-HBP-MG6-BS&FS-HBP-R6A3-BS&FS-HBP-R6D-BS
USER MANUAL
USER MANUAL
Digital Proportional Radio
Control System
Copyright ©2024 Flysky Technology Co., Ltd.
This product is only for 15 years
old or above.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-HBP-MG6-BS and is the answer not in the manual?

Questions and answers

Summary of Contents for FlySky FS-HBP-MG6-BS

  • Page 1 FS-HBP-MG6-BS&FS-HBP-R6A3-BS&FS-HBP-R6D-BS USER MANUAL USER MANUAL Digital Proportional Radio Control System Copyright ©2024 Flysky Technology Co., Ltd. This product is only for 15 years old or above.
  • Page 2 Read the manual carefully to ensure your personal safety as well as the safety of your equipment. If you encounter any problems during using, please refer to this manual first. If the problem is still not resolved, please contact the local dealer directly or contact the customer service staff via the website below: www.flysky-cn.com...
  • Page 3: Table Of Contents

    Table of Contents 1.Safety ...................... 1 1.1 Safety Symbols ....................1 1.2 Safety Guide ....................1 2.Introduction ..................... 2 2.1 Transmitter Overview ..................2 2.2 FS-HBP-R6A3-BS Receiver Overview .............. 3 2.2.1 Receiver LED .............................. 3 2.2.2 Interface ..............................3 2.2.3 Antenna ..............................3 2.3 FS-HBP-R6D-BS Receiver Overview ...............
  • Page 4 8.3 LED Lights Control ..................22 8.4 Failsafe ......................23 9. Product Specifications ................24 9.1 FS-HBP-MG6-BS Transmitter Specifications ..........24 9.2 FS-HBP-R6A3-BS Receiver Specifications ............ 25 9.3 FS-HBP-R6D-BS Receiver Specifications ............26 9.4 FS- HBP-DB01 Car Light Control Board Specifications ........ 27 10.
  • Page 5: Safety

    1.Safety 1.1 Safety Symbols Pay close attention to the following symbols and their meanings. Failure to follow these warnings could cause damage, injury or death. Danger • Not following these instructions may lead to serious injuries or death. Warning • Not following these instructions may lead to major injuries.
  • Page 6: Introduction

    &FS-HBP-R6D-BS 2.Introduction This system adopts 2.4GHz 2A-BS protocol and consists of FS-HBP-MG6-BS transmitter, FS-HBP-R6A3-BS receiver and FS-HBP-R6D-BS receiver, featuring two-way transmission, six channels output, lightweight and compact in design and ergonomic. It supports ESC parameters setting and is compatible with RC crawler car.
  • Page 7: Fs-Hbp-R6A3-Bs Receiver Overview

    2.2 FS-HBP-R6A3-BS Receiver Overview [18] [10] [19] [11] [12] [20] [13] [14] [15] [16] [17] CH1 Connector [11] Battery Connector CH5 Connector [12] Motor Connector CH6 Connector [13] Turn Signal Left Light Connector Headlight Connector [14] Turn Signal Right Light Connector Turn Signal Right Light Connector [15] Fog Light Connector...
  • Page 8: Fs-Hbp-R6D-Bs Receiver Overview

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 2.3 FS-HBP-R6D-BS Receiver Overview [10] [11] [12] LED Lights Connector "-" (Cathode of CH Connector) "+" (Anode of CH Connector) [10] S (Signal Pin of CH Connector) [11] LED [12] Antenna 2.3.1 Receiver LED The LED status indicates the power supply state of the receiver and its working state.
  • Page 9: Getting Started

    3.Getting Started Before operation, install the battery and connect the system as instructed below. 3.1 Transmitter Antenna The transmitter has a built-in antenna. When the transmitter starts to work, the antenna automatically operate, without additional operations. 3.2 FS-HBP-R6A3-BS Receiver and Servo Installation Make sure that the receiver is mounted in an appropriate location within the model, to ensure a stable signal, maximum range and to mitigate external interference, follow these guidelines: Pay attention to the following when installing the receiver:...
  • Page 10: Fs-Hbp-R6D-Bs Receiver And Servo Installation

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 3.3 FS-HBP-R6D-BS Receiver and Servo Installation Make sure that the receiver is mounted in an appropriate location within the model, to ensure a stable signal, maximum range and to mitigate external interference, follow these guidelines: Pay attention to the following when installing the receiver: Make sure the receiver is not installed near motors or sources of electrical noise.
  • Page 11: Transmitter Battery Installation

    3.4 Transmitter Battery Installation Danger • Only use specified battery. Danger • Do not open, disassemble, or attempt to repair the battery. Danger • Do not crush/puncture the battery, or short the external contacts. Danger • Do not expose to excessive heat or liquids. Danger •...
  • Page 12: Instructions

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 4.Instructions After setting up, follow the instructions below to operate the system. 4.1 Powering ON Follow the steps below to turn on the transmitter: Check to make sure that the batteries are fully charged and installed correctly.
  • Page 13: Stick Calibration

    Once the binding is successful, the receiver LED and the G.LED of the transmitter will be solid on. Verify that the transmitter and the receiver are working properly. If you need to re-bind, repeat the above steps. 4.4 Stick Calibration Use this function to correct for the mechanical deviation of the throttle trigger, steering wheel and CH5 self- centering knob, for example, deviation occurred in the self-centering or maximum/minimum travel, the steps are as following:...
  • Page 14: System Functions

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 5.System Functions This section focuses on the functions and how to use them. 5.1 Channel Description The transmitter outputs a total of 6 channels, which are assigned as below, as well as the functions.
  • Page 15: Channel Reverse

    5.2 Channel Reverse This function reverses the servo motion direction of steering ST.REV Switch (ST.REV) channel, throttle channel, CH4 and CH5. The ST.REV and TH.REV switches are reverse setting switches of steering channel and throttle channel respectively. Switches 5 and 6 of the 6-bit DIP switch are the reverse setting switches of CH4 and CH5, respectively.
  • Page 16: D/R

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 5.4 D/R This function is used to adjust the rate of steering channel and TH.D/R Knob throttle channel, so that the servo actions tend to be sensitive. (TH.D/R) ST.D/R is used to adjust the steering channel rate. TH.D/ R is used to adjust the throttle channel rate.
  • Page 17 CH6 End Point Adjustment Adjust the end points of CH6 (the control of CH6 is CH6 Three-position Toggle Switch). Setup: In the power-on state, press BIND twice, then the transmitter enters the end point setting mode. At this time, G.LED will operate in two-flash-one-off mode repeatedly, and the buzzer will prompt with beeping twice cyclically.
  • Page 18: Esc Parameters Setting

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 5.6 ESC Parameters Setting 6-bit DIP Switch Sign Running Mode Battery Type Drag Brake Lipo 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6...
  • Page 19: Failsafe

    Drag Brake The drag brake means that when the throttle trigger moves from the forward or reverse area to neutral range, it will produce certain braking force to the motor, the larger the value is, the greater the drag brake force is. And this is applicable to decelerate into a turn and model crawler applications.
  • Page 20: Low Voltage Alarm

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 5.10 Low Voltage Alarm When the system detects a low voltage, it will give an alarm. Avoid accidents caused by long-term operation under low voltage. When the voltage is detected below 4.2V/7.0V (AA battery/LiPo battery), there is an alarm when low voltage is detected.
  • Page 21: Fs-Hbp-R6A3-Bs Function Instructions

    6. FS-HBP-R6A3-BS Function Instructions This chapter mainly introduces the precautions for using the FS-HBP-R6A3-BS receiver and the settings of the related function. 6.1 Attention • Make sure the product is installed and calibrated correctly, failure to do so may result in serious injury. •...
  • Page 22: Led Lights Control

    The state of all the LED lights is controlled by the corresponding controls of the FS-HBP-MG6-BS transmitter. The 6 groups of LED lights support 6 groups of operating modes. Short press the CH3 button on the transmitter to switch the LED light mode.
  • Page 23: Trouble Shooting

    6.6 Trouble Shooting Troubles Possible Causes Solutions Check whether there is any connection problem 1. The ESC has no operating voltage. between the battery and the ESC and whether there The motor cannot start is faulty welding of the relevant plug. and the LED is not on after power-on.
  • Page 24: Fs-Hbp-Db01 Function Instructions

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 7. FS-HBP-DB01 Function Instructions This chapter mainly introduces the function of FS-HBP-DB01 car light driver board. 7.1 FS-HBP-DB01 Overview [10] [11] [12] Turn Signal Left Light Connector "-" (Cathode of the LED Light Connector) Turn Signal Right Light Connector "+"...
  • Page 25: Fs-Hbp-R6D-Bs Function Instructions

    8. FS-HBP-R6D-BS Function Instructions This chapter mainly introduces the precautions for using the FS-HBP-R6D-BS receiver and the settings of the related function. 8.1 Attention • Make sure the product is installed and calibrated correctly, failure to do so may result in serious injury. •...
  • Page 26: Led Lights Control

    The state of all the LED lights is controlled by the corresponding controls of the FS-HBP-MG6-BS transmitter. The 6 groups of LED lights support 6 groups of operating modes. Short press the CH3 button on the transmitter to switch the LED light mode.
  • Page 27: Failsafe

    8.4 Failsafe The receiver supports the failsafe function, it needs to be set at the transmittter side, refer to 5.7 Failsafe for details.
  • Page 28: Product Specifications

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 9. Product Specifications This section contains the specifications of FS-HBP-MG6-BS transmitter, FS-HBP-R6A3-BS receiver, FS-HBP-R6D- BS receiver and FS-HBP-DB01 car light drive board. 9.1 FS-HBP-MG6-BS Transmitter Specifications Product Model FS-HBP-MG6-BS Compatible Receivers FS-HBP-R6A3-BS, FS-HBP-R6D-BS...
  • Page 29: Fs-Hbp-R6A3-Bs Receiver Specifications

    9.2 FS-HBP-R6A3-BS Receiver Specifications Product Model FS-HBP-R6A3-BS Compatible Transmitters FS-HBP-MG6-BS Compatible RC Models 1 /18 simulation cars, crawler cars Number of Channels Number of Car Lights 2.4GHz ISM RF Protocol 2A-BS Distance More than or equal to 150m (ground distance without interference)
  • Page 30: Fs-Hbp-R6D-Bs Receiver Specifications

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 9.3 FS-HBP-R6D-BS Receiver Specifications Product Model FS-HBP-R6D-BS Compatible Transmitters FS-HBP-MG6-BS Compatible RC Models Cars, boats, or robots Number of PWM Channels Number of Car Light Connectors 6 (LED light connector connects to the FS-HBP-DB01 car light drive board.) 2.4GHz ISM...
  • Page 31: Fs- Hbp-Db01 Car Light Control Board Specifications

    9.4 FS- HBP-DB01 Car Light Control Board Specifications Product Model FS-HBP-DB01 Compatible Receivers FS-HBP-R6D-BS Compatible RC Models Cars Number of Car Light Connectors Operating Voltage 3.5 ~ 8.4V/DC Temperature Range -10℃ ~ +60℃ Humidity Range 20% ~ 95% Waterproof PPX4 Dimensions 27.0mm*19.0mm*13.5mm Weight...
  • Page 32: Package Contents

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 10. Package Contents This section contains FS-HBP-MG6-BS transmitter packing contents. Number Name Quantity FS-HBP-MG6-BS Transmitter FS-HBP-R6A3-BS Receiver FS-HBP-R6D-BS Receiver FS-HBP-DB01 Car Light Drive Board...
  • Page 33: Certifications

    11. Certifications 11.1 DoC Declaration Hereby, [ShenZhen FLYSKY Technology Co., Ltd.] declares that the Radio Equipment [FS-HBP-MG6-BS&FS-HBP- R6A3-BS&FS-HBP-R6D-BS] is in compliance with RED 2014/53/EU. The full text of the EU DoC is available at the following internet address: www.flyskytech.com/info_detail/10.html 11.2 CE Warning The ce warns that the installation of the antenna used in this transmitter must be kept in distance from all the personnel and shall not be used or used with any other transmitter.
  • Page 34: Environmentally Friendly Disposal

    FS-HBP-MG6-BS&FS-HBP-R6A3-BS Digital Proportional Radio Control System &FS-HBP-R6D-BS 11.4 Environmentally friendly disposal Old electrical appliances must not be disposed of together with the residual waste, but have to be disposed of separately. The disposal at the communal collecting point via private persons is for free. The owner of old appliances is responsible to bring the appliances to these collecting points or to similar collection points.
  • Page 35 Copyright ©2024 Flysky Technology Co., Ltd. Release date: 2024-06-29 CE, FCC ID: 2A2UNMG110O FCCID: 2A2UNR6D01 FCCID: N4ZR4A31 Manufacturer: ShenZhen FLYSKY Technology Co., Ltd. Address: 16F, Huafeng Building, No. 6006 Shennan Road, Futian District, Shenzhen, Guangdong, China...
