- Page 1 Instruction Manual ECLIPSE CONVEYOR TOASTERS ET310 Version 4 ET315 Version 4 Includes International models ET313-GXX ET315-FXX ET315-MXX.
-
Page 2: Table Of Contents
CONTENTS Overseas model only PARTS INCLUDED Product Features Specifications Eclipse Toaster (appropriate model) ▪ Parts Included One Wire Rack Inlet Chute ▪ Safety Instructions One Solid Inlet Chute ▪ Cleaning & Maintenance Return Outlet Chute ▪ Installation Operation Step Adjustable Outlet Chute ▪... -
Page 3: Cleaning & Maintenance
Filter is located at This machine contains no user-serviceable parts. the rear control side of the Roband Australia, one of our agents, or a unit and is removed by similarly qualified person(s) should carry out sliding up. Filter must be repairs. -
Page 4: Operation
chute is resting along the upper crumb tray. If Front Panel Controls you are fitting the Solid Inlet Chute the crumb Item Description Function tray will need to be pulled out slightly first and Switches toaster on Main On/Off Switch then pushed back into position. - Page 5 TOASTING By keeping as close to full power as possible you will get the highest throughput of product Switch the power on by rotating the main on/off through the toaster. switch to the on position. FILTER REMOVAL Set the conveyor speed control initially to maximum, position 20.
-
Page 6: Troubleshooting
TROUBLESHOOTING If the Toaster does not function check the following points before calling for service. ✓ The machine is plugged in correctly and the power switched on. ✓ The power point is functioning correctly. ✓ The on/off switch is not in the OFF position. ✓... -
Page 7: Spare Parts
SPARE PARTS Common ET315 EC0531 Fotek SSR-10VA HC0104 Element - 320W 46V EC0535 500K "B" Potentiometer ES0387 Plug & Cord - 15 Amp EC0548 Fan 80X80X25 DC12V 60CFM ET313 EC0564 EMI Filter HC0234 Element - 366W 57.5V ES0009 Transformer c/w Terminals ES0387 Plug &... -
Page 8: Circuit Diagram
CIRCUIT DIAGRAM... -
Page 9: Notes
NOTES This page in intentionally left blank... -
Page 10: Notes
NOTES This page in intentionally left blank 20/01/2025... -
Page 11: Warranty
Tubular Heating Elements is not a warranty fault. Roband or any subsidiary company or Agent shall not be liable for loss of profit or damage to other equipment and property except where it is in breach of the guarantees provided in accordance with applicable legislation. - Page 12 © Copyright 2024 – Roband Australia Pty Ltd ® All rights reserved. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical, including photocopying or posting to a website, without the written permission of the publisher.
