OPERATING INSTRUCTIONS
These instructions cover the models of ROBAND
listed above. Although there are slight variances between them, the
installation, operation, care and maintenance procedure is the same
for all.
MANUFACTURED BY
ROBAND AUSTRALIA PTY LTD
BOILING HOT PLATES
Models: 11, 12, 12-UK & 13
VERSION 1 UNITS
Special Features:
Mulitple Heat Settings
Stainless Steel Construction
High Speed Revovery
Boiling Hot Plates
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ROBAND 11
Summary of Contents for ROBAND 11
-
Page 1: Operating Instructions
MANUFACTURED BY ROBAND AUSTRALIA PTY LTD OPERATING INSTRUCTIONS BOILING HOT PLATES Models: 11, 12, 12-UK & 13 VERSION 1 UNITS Special Features: Mulitple Heat Settings Stainless Steel Construction High Speed Revovery These instructions cover the models of ROBAND Boiling Hot Plates ®... - Page 2 NOAW Meat Slicers, RYNO Stainless Benching, Robalec Soup/Rice warmers and Dito Food Processors. In addition to a vast range of machines, Roband Australia has its own line ® of commercial cookware and cutlery under the Robinox brand name. For a complete set of brochures please contact your nearest authorised dealer or contact Roband directly at our head office.
-
Page 3: Table Of Contents
INSTALLATION ................6 OPERATION .................7 : ................7 WITCH ETTINGS GENERAL SAFETY..............8 CLEANING, CARE & MAINTENANCE ........9 TROUBLESHOOTING ..............10 CIRCUIT DIAGRAM* ..............11 Models: 11 & 13 ....................11 Model: 12 ......................12 APPENDIX A................13 EC DECLARATION OF CONFORMITY ........14 Warranty............15 Page 3... -
Page 4: Introduction
Always be careful when near an operating Boiling Plate, and ensure that any risk to unwary customers or staff is minimised with additional signage if necessary. Due to the obvious heat hazard Roband recommends that these units be kept out of reach of children. Do not allow children to play with these units. -
Page 5: Packaging
PACKAGING All care is taken when packing and Roband ensures that every unit is functional and undamaged at the time of packaging. The Package of these Boiling Hot Plates should include: One Boiling Hot Plate (appropriate model) This Manual Packaging Materials... -
Page 6: Installation
INSTALLATION Remove all the packaging materials and tape, as well as any protective plastic from the machine. Clean off any glue residue left over from the protective plastic. Place the Boiling Hot Plate on a firm, level surface in the required position. Before connecting the unit to the power supply ensure that all the controls are in the “OFF”... -
Page 7: Operation
OPERATION Before using for the first time, turn on the heat switch to the highest setting for 3 to 5 minutes to harden the protective coating. The cooking utensil used should have a bottom which is as solid and as even as possible and which, at a diameter of about 200mm, has a concavity of less than 1mm. -
Page 8: General Safety
SAFETY GENERAL SAFETY This machine contains no user-serviceable parts. Roband Australia, one of our agents, or a similarly qualified person(s) should carry out any and all repairs. Any repair person(s) should be instructed to read the Safety warnings within this manual before commencing work on these units. -
Page 9: Cleaning, Care & Maintenance
CLEANING, CARE & MAINTENANCE Attention to regular care and maintenance will ensure long and trouble free operation of your boiling hot plate. Although scheduled servicing is not required we do recommend you adopt a program of regular maintenance to ensure that the hot plate is clean and functional and to avoid inadvertently damaging the unit. -
Page 10: Troubleshooting
TROUBLESHOOTING If the Boiling Hot Plate does not heat up check the following points before calling for service. The unit is plugged in correctly and the power is switched on. The power point is not faulty. The heat switch has been turned to the appropriate setting. The heat switch is not loose or broken, rendering the thermostat inoperable. -
Page 11: Circuit Diagram
CIRCUIT DIAGRAM* Models: 11 & 13 * This circuit diagram has been provided for reference and to assist qualified service and repair agents only. Under no circumstances should person’s not suitably qualified attempt repairs to any electrical equipment. Page 11... -
Page 12: Model: 12
CIRCUIT DIAGRAM* Model: 12 *This circuit diagram has been provided for reference and to assist qualified service and repair agents only. Under no circumstances should person’s not suitably qualified attempt repairs to any electrical equipment. Page 12... -
Page 13: Appendix A
30-60 minutes, after which time the elements should have dried out and the machine should function normally. If you are unable to locate a circuit without an RCD please contact your supplier or contact Roband or our Agent for alternative suggestions. Page 13... -
Page 14: Ec Declaration Of Conformity
I hereby declare under our sole responsibility that the product mentioned above to which this declaration relates complies with the above-mentioned standard(s). Roband Australia has appointed Valera Ltd as our EU Authorised Representative of : 5-7 The Glade Business Centre, Eastern Ave, West Thurrock, Essex, RM203FH , UK. -
Page 15: Warranty
Under no circumstances shall Roband Australia Pty Ltd or any subsidiary company or Agent be liable for loss of profit or damage to other equipment and property. - Page 16 ALSO AVAILABLE AT YOUR ROBAND DISTRIBUTOR MALAVASI FOOD STEAMER ROBINOX PROCESSORS KITCHEN &TABLEWARE TWIN DRINK VERTICAL TOASTER HIGH SPEED CONTACT GRILL MIXER VITA-MIX ECO-RAY AUTOMATIC BLENDERS HOT WATER URNS TOASTERS AND GRILLERS Manufactured/Imported in Australia by ROBAND AUSTRALIA PTY LTD...
