PLEASE RETAIN Erin Eco Boiler Stove INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.
All warranty claims must be reported to the Waterford Stanley Service Department and must be submitted with the prod- uct serial number (located on the front casting), date of purchase, proof of purchase (if requested) and details of the specific nature of the problem.
INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a minimum of 1.8 metres (6 feet) of 150mm (6”) flue pipe. 3. The horizontal flue run should not exceed 150mm (6”) 4.
IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley Solid Fuel Stove is installed and no doubt you are looking forward to many comforts it will provide, we would like to give you some tips on how to get the best results from your stove.
Heating Systems in Buildings. method for to determine what regulations are in force. Save calculation of the design heat load. these instructions for future reference. Your Erin stove is supplied with the following items: Please note that it is a legal requirement under • Legs England &...
Page 8
Fig.5 Fig.2 (H) Repeat step (F) for fitting of rear legs. See Fig.6 Fig.6 (E) Manoeuvre the stove so that it overlaps the pal let by no more than 80mm. (F) Remove the two transport screws from the front leg positions and fit the legs using the M10 x 20mm hex head bolts.
CONTROL ROD ASSEMBLY DOOR HANDLE ASSEMBLY Note: It is recommended that the installation is Attach the short timber handle to the ashpit door complete prior to fitting the thermostat control rod using the M8 x 70mm long round head screw and knob and the spring washer.
BAFFLE FITTING INSTRUCTIONS Lift the top edge of the baffle plate and place the baffle support on the boiler cross tank Remove the inner top by removing the 4 with the pointed end facing up. Push the bolts. See Fig.14. support down which will push the baffle back into position.
The stove must be connected to a chimney with a FLUE EXIT (TOP & REAR) minimum continuous draught of 0.06 w.g. Poor The stove is designed to allow the chimney be draught conditions will result in poor performance. cleaned through the stove. If the chimney cannot be cleaned through the stove it is necessary to provide All register plates, restricter plates, damper etc., a soot box/access door in the flue for cleaning.
REAR FLUE EXIT Fig.22 Fit the top cover plate to the stove with the two screws holding on the rear exit cover plate making sure that the sealing rope is properly seated on the stove flue outlet. Tighten screws. See Fig.21. Fig.21 Direction of wind Pressure zone...
All materials used in the manufacture of air vents Especially Airtight Properties:- should be such that the vent is dimensionally stable, corrosion resistant, and no provision for closure. If the stove is being fitted in a property where the design air permeability is less than 5m / (h.m ) (nor- The effective free area of any vent should be ascer-...
See Fig. 24 LOCATION There are several conditions to be considered in selecting a location for your Stanley Erin Stove. a. Position in the area to be heated, central locations are usually best.
Fig.24 GRAVITY CIRCUIT The gravity circuit consists of the domestic hot water 8” 8” tank of 135 litres indirect cylinder, fixed in an upright position, recommended for hot water storage and it should be connected to the boiler by 28mm diameter flow and return piping.
WATER CIRCUIT TEMPERATURE FLUE & WATER PIPE LOCATIONS The return water temperature should be maintained Flue outlet to suit 152mm (6”) internal diameter flue at not less than 40°C so as to avoid condensation on pipe. the boiler and return piping. Fitting a pipe thermo- stat to the flow pipe of the gravity circuit and wiring it Water outlets 25mm (1”) B.S.P.
STOVE DIMENSIONS Fig.29 Fig.30 WARNING: DO NOT OBSTRUCT PRIMARY AIR SUPPLY TO THE STOVE Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. COMMISSION AND HANDOVER AIR CONTROLS The stove has two independent air controls: On completion of the installation allow a suitable The thermostat knob (See Fig.
RECOMMENDED FUELS Fig.32 All fuels should be stored under cover and kept as dry as possible prior to use. This appliance has been tested using seasoned manufactured briquetted smokeless fuel (Ancit) for closed appliances, sized between 20g and 140g. Other fuels are commercially avail- able and may give similar results.
Model Class to Room to Water Index Fuel Output Net Efficiency Erin Eco 69.2 Anthracite 11.8 79.2 USER INSTRUCTIONS LIGHTING THE STOVE Before lighting the stove check with the installer that the installation work and commissioning checks described in the installation instructions have been carried out correctly and that the chimney has been swept clean, is sound and free from any obstructions.
RE-FUELLING Before opening the door, turn the thermostat knob Fig.35 fully clockwise as this will help to eliminate any smoke or fly ash resident in the combustion cham- ber. Use Glove supplied. Riddle the fire using the poker Add fuel to fire, close the fire door and reset Ashpan the thermostat knob to the required setting.
Fig.37 Cleaning Firebox Chamber GLASS CLEANING The stove glass will self-clean when there is suffi- cient heat generated by the burning fuel i.e. when the unit is operated at the maximum air settings. If a build-up of creosote occurs on the glass it may be due to low draft conditions, poor quality fuel or oper- ating the stove at the minimum air settings for long periods of time.
FIRE SAFETY CO ALARM To provide reasonable fire safety, the following should be given serious consideration. The fitting of CO Alarms in the same room as the 1. Do not over fire the stove. appliance is a compulsory requirement under cur- 2.
