Dell - Latitude™ D620 - Printer-Friendly Format
10. Remove the LCD brackets from the LCD.
NOTE:
When replacing the LCD, you must migrate the two brackets to the replacement LCD.
11. Slide the LCD brackets from the LCD.
12. Reverse the previous steps to assemble the LCD.
Printed 2/22/2010 11:17:19 AM
Expires 2/23/2010 11:17:19 AM
https://dcse.dell.com/SelfStudy/Foundations_2007/Foundations_2007_Portables/Portable...
Latitude™ D620
LCD Disassembly
This document is Dell Confidential
For Dell Employees Only
Página 61 de 145
22/02/2010
