Installation Instructions
Ford Bronco® 4 Door Defender Platform Mounting Kit
Part # S/BF01
For Technical Support / Warranty Information please call 800-776-0767
Smittybilt, 400 W Artesia, Compton, CA 90220
Ford Bronco® 4 Door Defender Platform Mounting Kit
Rev 11/28/2022
Part # S/BF01

Advertisement

loading
Need help?

Need help?

Do you have a question about the SBF01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smittybilt SBF01

Summary of Contents for Smittybilt SBF01

  • Page 1 Ford Bronco® 4 Door Defender Platform Mounting Kit Part # S/BF01 For Technical Support / Warranty Information please call 800-776-0767 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...
  • Page 2 Introduction Thank you for choosing Smittybilt accessories for your Ford Bronco®. If you would like to view our full range of available accessories, please visit us at www.smittybilt.com Ford®, Bronco®. are registered trademarks of Ford Motor Company. Important Notes Before Starting Carefully read through this entire instruction manual thoroughly before attempting to install this part.

  • Page 3: Box Contents

    Rear mounting bracket clamp Rear mounting bracket Rear mounting bracket clamp (large) For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...
  • Page 4 M6 flat washers. Leave them loose for now. (c) For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...

  • Page 5: Installation Instructions

    M6 bolt plate. (f) Leave them loose for now. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...
  • Page 6 3. Middle support bracket 4. Front mounting bracket shim For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...
  • Page 7 (foam pad facing down) For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...
  • Page 8 Step 10: Square the roof platform and tight al the M6 hardware. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022...
  • Page 9 For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022...
  • Page 10 LED light bar and tight the light bar mounting brackets For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022 Part # S/BF01...
  • Page 11 Torque all hardware to spec refer to torque chart on page # 13 Your installation is now complete. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022...

  • Page 12: Bolt Torque Specifications

    Use this only as a guide for hardware without a called out torque specification in the instruction manual. For Technical Support / Warranty Information please call 800-776-0767 EXT 1317 Smittybilt, 400 W Artesia, Compton, CA 90220 Ford Bronco® 4 Door Defender Platform Mounting Kit Rev 11/28/2022...
  • Page 13 5-YEAR FINISH WARRANTY Smittybilt Automotive Products, LLC (SAP) warrants to the original purchaser that (a) the physical components (e.g., metal com- ponents, welds, etc.) of any SAP Ford Bronco® Defender Platform Mounting Kit will be free of defects in material and work- manship for the lifetime of the product from the date of purchase of the Defender Rack Mounting Kit, and (b) the finish will be free of defects in material and workmanship for a period of 5-years from the original date of purchase.
