For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3824T -VN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
Rev: 1 9 -0 1 - 16
Advertisement
Related Manuals for Furniture of America CM3824T-VN
Summary of Contents for Furniture of America CM3824T-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3824T -VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #1 x 1pc Bolt Ø5/16" x 1-1/4" Table Top #B x 4pcs #2 x 2pcs Bolt Ø5/16"...
- Page 4 Exploded View #C x 4pcs #F x 4pcs #G x 4pcs #J x 4pcs Align and hook the stretcher (#3) to the side panels (#2), then secure metal plates (#J) to stretcher (#3) and side panels (#2) by using bolts (#C) with washers (#G,F). Page 4 of 6...
- Page 5 Secure metal plates (#J) to stretcher (#3) by using bolts (#C) with washers (#G,F). #C x 4pcs # F x 4pcs # G x 4pcs #B x 4pcs Align mounting plates (#4) to the side #D x 4pcs panels (#2), then secure by using #E x 4pcs bolts (#B) with washers (#E,D).
- Page 6 #A x 8pcs #D x 8pcs #E x 8pcs Align side panels (#2) to the top (#1), then secure by using bolts (#A) with washers (#E,D). ASSEMBLY IS COMPLETED Page 6 of 6...
