For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
CM3824PT -VN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
(Not Included)
Rev: 1 9 -0 1 - 16
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3824PT-VN
Summary of Contents for Furniture of America CM3824PT-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3824PT -VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Bolt Ø5/16" x 1-1/4" Table Top #B x 8pcs #2 x 1pc Bolt Ø5/16"...
- Page 4 #K x 10pcs #I x 1pc Allen Wrench M4 Screw #3.5 x 15mm #J x 4pcs L Metal Plate Page 4 of 8...
- Page 5 DO NOT FULLY TIGHTEN ALL BOLTS UNTIL THE FULL ASSEMBLY OF TABLE IS COMPLETED. #C x 4pcs # F x 4pcs # G x 4pcs #J x 4pcs Hook stretcher (#4) to the latch of left and right side panels (#2,3), then align brackets (#J) to the holes of the stretcher (#4) and side panels (#2,3).
- Page 6 Align connection panels (#5) to the side panels (#2,3), then secure by using bolts (#B) with washers (#E,D). #B x 8pcs #D x 8pcs #E x 8pcs Align drawer (#6) to the drawer rails. Make sure that the alignment of drawer (#6) is correctly centered to the side panels (#2,3), because there will be no pre-drilled holes.
- Page 7 Extend drawer (#6), then secure drawer (#6) to drawer rails by using screws (#K). #K x 6pcs #A x 8pcs #D x 8pcs #E x 8pcs Align connection panels (#5) to the holes of the table top (#1), then secure by using bolts (#A) with washers (#E,D).
- Page 8 Extend drawer (#6), then place drawer win racks (#7,8) inside drawer (#6). ASSEMBLY IS COMPLETED Page 8 of 8...
