ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3824PC-2PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
Page 1 of 5
(Included)
(Not Included)
Rev: 18-05-31
