  • Page 1 Application Guide M‑2270B Adapter Panel A proud member of the Hubbell family.
  • Page 2 TRADEMARKS All brand or product names referenced in this document may be trademarks or registered trademarks of their respective holders. The content of this Instruction Book is provided for informational use only and is subject to change without notice. Beckwith Electric has approved only the English version of this document.
  • Page 3 CONTROLS Adapter Panel M‑2270B Adapts M‑2001 Series Digital Tapchanger Control s a General Replacement for Transformer and Regulator Controls • Provides mounting adaptable to several different configurations • Provides built-in CT shorting protection when the M-2001 Series Digital Tapchanger Control is removed •...
  • Page 4 M-2270B Adapter Panel M-2270B Adapter Panel The M‑2270B is an adapter panel which, when combined with the M‑2001 Series Digital Tapchanger Control, can be customized to fit as a replacement for a variety of manufacturers’ LTC transformers and regulator controls. Interface Interface External connections are made to two terminal blocks located on the rear of the adapter panel.

  • Page 5: Warranty

    M-2270B Adapter Panel M-2270B Adapter Panel Size with 19" Rack Mount Adapter Panel and M‑2001 Series Digital Tapchanger Control: Size with 19" Rack Mount Adapter Panel and M‑2001 Series Digital Tapchanger Control: 13.96" high x 19" wide x 4.22" deep (35.46 cm x 48.26 cm x 10.72 cm).
  • Page 6 ISO 9001:2015 ISO 9001:2015 A proud member of the Hubbell family. © 1993 Beckwith Electric. All Rights Reserved. © 1993 Beckwith Electric. All Rights Reserved. M M ‑ ‑ 2270B 2270B‑ ‑ SP SP‑ ‑ 04...
  • Page 7 WARNING DANGEROUS VOLTAGES, capable of causing death or serious injury, are present on the external terminals and inside the equipment. Use extreme caution and follow all safety rules when handling, testing or adjusting the equipment. However, these internal voltage levels are no greater than the voltages applied to the external terminals.

  • Page 8: Product Cautions

    PRODUCT CAUTIONS Before attempting any test, calibration, or maintenance procedure, personnel must be completely familiar with the particular circuitry of this unit, and have an adequate understanding of field effect devices. If a component is found to be defective, always follow replacement procedures carefully to that assure safety features are maintained.

  • Page 9: Table Of Contents

    Table of Contents Table of Contents TABLE OF CONTENTS M‑2270B Adapter Panel Application Guide Introduction ......................... 1 Description ........................... 1 Standard Features ......................1 Control Switches ......................... 1 Binding Posts ........................2 Status Indicators ......................... 2 Fuses ..........................2 Optional Features ....................... 2 Application ...........................
  • Page 10 M‑2270B Application Guide M‑2270B Application Guide M‑2001 Tapchanger Control Software Settings .............. 14 M‑0329 LTC Backup Control Settings................14 Bench Test (M‑2001 Connected to M‑2270B) ..............14 Test Equipment ......................... 14 Setup ..........................14 Table 2 Initial Settings ....................14 Figure 10 M-2270B Test Procedure External Connections ........

  • Page 11: Introduction

    M‑2270B Application Guide Introduction The Beckwith Electric M‑2270B Adapter Panel, used in conjunction with the M‑2001 Tapchanger Control, uses modern electronic digital design and digital processing circuitry to achieve an overall stability and resolution unattainable with electromechanical and analog design tapchanger controls. CMOS semiconductors are used throughout the design.

  • Page 12: Binding Posts

    M‑2270B Application Guide Binding Posts Binding Posts VOLTAGE IN VOLTAGE IN binding posts on the front panel allow application of a 120 V rms nominal voltage to the unit for test procedures. MOTOR PWR IN MOTOR PWR IN binding posts on the front panel allow application of a 120 or 240 V rms nominal voltage to the unit for test procedures.

  • Page 13: Neutral Light Circuit

    M‑2270B Application Guide The external connections for the M‑2270B are made to terminal blocks TB1 and TB2. Auxiliary external connections, if needed, are made to terminal blocks TB1 and TB2 on the printed circuit board at the base of the adapter panel. The wiring harness and external connections for the M‑2270B are shown in Figure 3 through Figure...

  • Page 14: Paralleling

    M‑2270B Application Guide Apply "Wetting Voltage" from TB2 28 Voltage Reduction Setpoint: Multiplier Range to Terminal # Voltage Reduction Setpoint #1: 0 to 10% TB1‑7 Voltage Reduction Setpoint #2: 0 to 10% TB1‑2 Voltage Reduction Setpoint #3: 0 to 10% TB1‑7 and TB1‑2 Table 1 Multi-Step Voltage Reduction External Connections Paralleling...
  • Page 15 M‑2270B Application Guide (Front Panel Inputs) Test M‑2001 Terminal Meter External Fuse 3 A Power Voltage Input Non-Sequential / Auto (Polarity) Tapchange Inhibit Input Load Current Voltage Reduction (Return) Step #2 Input Circulating Current Neutral (Return) Load Current Circulating Current (Polarity) (Polarity) Circulating Current...
  • Page 16 M‑2270B Application Guide (Front Panel Inputs) Test M‑2001 Terminal Meter External Fuse 3 A Power Voltage Input Non-Sequential / Auto (Polarity) Tapchange Inhibit Input Load Current Voltage Reduction (Return) Step #2 Input Circulating Current Neutral (Return) Load Current Circulating Current (Polarity) (Polarity) Circulating Current...
  • Page 17 M‑2270B Application Guide Non-Sequential / Auto Non-Sequential / Auto Tapchange Tapchange Inhibit Input Inhibit Contact (Note #1) Voltage Reduction Voltage Reduction Step #2 Input Step #2 Contact Circulating Current (Return) To Paralleling Unit (Note #2) Circulating Current (Polarity) Tapchanger Raise Output Tapchanger Lower Motor...
  • Page 18 M‑2270B Application Guide Up (Neutral) Down (Hot) 13 12 11 10 23 22 ® See Figure 3 for External Connections Figure 4 M-2270B Wiring Harness with Standard Auto/Off/Manual Toggle Switch, Optional Voltage Reduction and SCADA Cutout Switches –8–...
  • Page 19 M‑2270B Application Guide Up (Neutral) Down (Hot) 13 12 11 10 23 22 ® See Figure 3 for External Connections Figure 5 M-2270B Wiring Harness with Optional SCAMP™ Auto/Manual Pushbutton, Voltage Reduction and SCADA Cutout Switches –9–...

  • Page 20: Installation

    M‑2270B Application Guide MOTOR SUPPLY Tapchanger Control M-0329 LTC Backup Control TB1-11 120 V ac LOWER Raise Power TB1-12 TB1-6 Common Voltage RAISE TB1-7 Lower TB1-9 Alarm LOWER TB1-10 Limit switcher, auxiliary contacts as required in motor control circuits. 84R - Raise Motor Auxiliary Relay 84L - Lower Motor Auxiliary Relay NOTE: NOTE:...

  • Page 21: Lightning Protection

    M‑2270B Application Guide Lightning Protection Lightning Protection It has been determined that transient voltages in excess of 1500 Vac rms can exist on the "ground" lead normally tied to TB1-8 on the printed circuit board. In the Tapchanger Controls, these voltages are suppressed by varistors which still permit the unit to pass a 1500 Vac Hi Pot test for one minute with a leakage current of approximately 15 mA, all terminals to ground.
  • Page 22 M‑2270B Application Guide 12-1/2 (31.8) 11-1/2 (29.2) 10-1/2 (26.7) C C L L 12-1/4 (30.4) (20.3) (31.1) Inches (Centimeters) 9/32 (0.71) DIA. – 4 Places Figure 8 M-2270B Panel Cutout Dimensions –12–...
  • Page 23 M‑2270B Application Guide 19.00 [48.26] 3.75 11.50 [9.53] [29.21] 0.38 [0.97] 10.50 [20.67] Ø .28 (4X) [0.71] 4.00 [10.16] (2X) 12.00 [30.5] 3.00 13.96 8.00 [7.62] [34.46] [20.32] (2X) 4.00 [10.16] (2X) 2.98 [7.57] 4.25 1.48 0.98 0.38 [10.8] [3.76] [2.5] [0.97] (2X)

  • Page 24: M-2001 Tapchanger Control Software Settings

    M‑2270B Application Guide M‑2001 Tapchanger Control Software Settings Adjust the BANDCENTER setting to the nominal voltage desired. Adjust the BANDWIDTH setting to the desired voltage band, centered on the Bandcenter setpoint, that the voltage must exceed before timer and subsequent tapchanger operation occurs. Adjust the TIME DELAY setpoint to a sufficient amount to eliminate excessive tapchanger operations.
  • Page 25 M‑2270B Application Guide Figure 10 M-2270B Test Procedure External Connections –15–...

  • Page 26: Procedure

    M‑2270B Application Guide Procedure Procedure 1. Apply 120.0 Vac from power source. 2. The display of the M‑2001 will automatically advance to the Local Voltage Local Voltage screen. 3. Increase voltage to 121.2. The LOWER LOWER LED should illuminate. 4. Decrease voltage to 118.8. The RAISE RAISE LED should illuminate.

  • Page 27: Drag Hands Reset

    M‑2270B Application Guide Drag Hands Reset Drag Hands Reset Verify that the DRAG HAND RESET DRAG HAND RESET switch works by connecting a lamp or ac relay from TB1‑12 (drag hands reset) to TB1‑8 (neutral) of the adapter panel. When the switch is pressed, the connected indicator should function.

  • Page 28: In-Service Test

    M‑2270B Application Guide In‑Service Test 1. Set the M‑2001 Tapchanger Control to display the Bias Voltage Bias Voltage screen. 2. Press Enter Enter. 3. Use Up Up and Down Down buttons to cause RAISE RAISE and LOWER LOWER outputs. —In-Service Test Complete— —In-Service Test Complete—...

  • Page 29: Voltage Source Switch

    M‑2270B Application Guide Voltage Source Switch Voltage Source Switch The VOLTAGE SOURCE VOLTAGE SOURCE switch will disconnect all power from the unit when in the EXT EXT position with no source connected to the front panel voltage and motor power inputs. CAUTION: CAUTION: Do not reverse the ground and hot wires when connecting an external source.
  • Page 30 The Seller shall not be liable for any property The units described in this manual are covered by damages whatsoever or for any loss or damage U.S. Patents, with other patents pending. arising out of, connected with, or resulting from this Buyer shall hold harmless and indemnify the Seller, contract, or from the performance or breach thereof, its directors, officers, agents, and employees from...
  • Page 32 6190 118th Avenue North • Largo, Florida 33773-3724 U.S.A. 6190 118th Avenue North • Largo, Florida 33773-3724 U.S.A. PHONE (727) 544-2326 PHONE (727) 544-2326 beckwithelectricsupport beckwithelectricsupport hubbell.com hubbell.com www.beckwithelectric.com www.beckwithelectric.com ISO 9001:2015 ISO 9001:2015 © 2006 Beckwith Electric. All Rights Reserved.
