- Page 1 TECHN ICAL MANUAL - 2 WHEE L S R EMOVAL AND REFITTIN G WH EEL FRO N T H UB ( CUP-CON E BEAR IN G S) C A M PA G N O L O. CO M...
- Page 2 WARNING! Always wear protective gloves and glasses while working on the bicycle. THIS TECHNICAL MANUAL IS INTENDED FOR USE BY PROFESSIONAL MECHANICS. Anyone who is not a qualified professional for bicycle assembly must not attempt to install and operate on the components independently due to the risk of carrying out incorrect operations which could cause the components to malfunction, resulting in accidents, physical injury or even death.
-
Page 3: Maintenance
2*: Phase 9 to 74 and 82-83 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. Bullet Ghibli™... - Page 4 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. The indication that the adjustment ring nut will be Holding the axle stationary, rotate the adjustment ring nut...
- Page 5 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. The cup pulling tool consists of two items. A specific Insert the stripper inside the cup the cup that needs to be Once inserted correctly the stripper remains still without stripper for road cups and a punch.
- Page 6 2*: Phase 9 to 74 and 82-83 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. CUP HOUSING GREASE SHIELD HOUSING inspect the housing of the grease shield and of the cup If damaged, replace the grease shield.
- Page 7 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. Insert the tool inside the body of the hub. Make sure you Place the second cup on the second adaptor.
- Page 8 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. Insert the bearing retaining ring inside the cups body of Ensure that the bearing retaining ring is inserted into the The hub shield must be undamaged.
- Page 9 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. Check the cone is mates correctly into the bearing Insert the adjustment cone onto the axle mating into the Manipulate it into position by using a small screwdriver.
- Page 10 PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED MAINTENANCE Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. Using a plastic hammer gently tap on both sides of the ►To adjust the hub see OPERATION 001 Technical Manual 1 hub pin.
- Page 11 REMOVAL AND REFITTING WHEEL FRONT HUB (CUP-CONE BEARINGS) PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. • Refer to the video tutorial: “Removing the front •...
- Page 12 REMOVAL AND REFITTING WHEEL FRONT HUB (CUP-CONE BEARINGS) PRODUCTS ON WHICH THE PROCEDURE SHOULD BE APPLIED Refer to the “Table of Technical Manuals for Wheels”, available at www.campagnolo.com / section “Technical Documentation – Technical Manuals”. Using a flat screwdriver, remove the right-hand The ring nut is loose when the crack of the joint Using a 2.5mm Allen wrench, loosen the screw that...
